Honeywell MIWI350 Instrucciones de funcionamiento

MIWI350 Installation and Operations Guide

FD-610 | Version 4.0 | May 2022

Honeywell Process Solutions | Mercury Instruments

2101 Citywest Boulevard Houston, Tx 77042 USA

855 251-7065 – United States & Canada | 302 669-4253 – Outside the United States

[email protected]

https://process.honeywell.com

Information in this document is subject to change without notice. The software described in this

document is furnished under a license agreement or non-disclosure agreement. The software

may be used or copied only in accordance with the terms of those agreements. No part of this

publication may be reproduced, stored in a retrieval system, or transmitted in any form or any

means electronic or mechanical, including photocopying and recording for any purpose other

than the purchaser's personal use without the written permission of Honeywell Process

Solutions.

Version Changes List

Document Name Document

ID Description Version

Number

Publication

Date

MIWI350 Operating and

Installation Guide FD-600 Initial Draft 1.00 Feb 2018

MIWI350 Operating and

Installation Guide FD-610 R100 release 2.00 Mar 2019

MIWI350 Operating and

Installation Guide FD-610 R110.1 release 2.50 Sep 2020

MIWI350 Operating and

Installation Guide FD-610 R110 release 3.00 Nov 2020

MIWI350 Operating and

Installation Guide FD-610 R120.0 release 4.00 Jan 2022

1 About MIWI350 1

1.1 Product Features 1

1.2 Power Supply Options 1

1.3 Abbreviations 1

1.4 Specifications 2

1.4.1 Power Input Sources and Options 2

1.4.2 Audit Trail 3

1.4.3 Certifications 3

1.4.4 Wiring Guidelines for AC Input 4

1.4.5 Environmental 5

1.4.6 Temperature Measurement 6

1.4.7 Pressure Measurement 6

1.5 Safety Measures 7

1.5.1 Safety and Hazardous Information 7

1.5.2 Conditions of Acceptability 8

1.5.3 Warning-Explosion Hazard/Avertissement - Risque d'explosion 8

1.5.4 Things to Remember 9

1.5.4.1 Usage of MIWI350 in Hazardous Areas 9

1.5.4.2 Installation and Commissioning of MIWI350 in Hazardous

Areas 9

1.5.4.3 Instructions for Installation in Zone 2 Location as per

IECEx Certification 9

1.5.4.4 Service, Maintenance, and Troubleshooting 9

2 Security Control Measures 11

3 Installation 14

3.1 Unpacking 14

3.2 Mounting Options 14

3.2.1 Device Marking 15

3.3 Zone2 installation 16

4 Mechanical Assembly and User Interface 18

4.1 Device Dimensions & Weights 19

4.2 Display Options 21

4.2.1 HMI User Interface 22

4.3 Gland Entries 25

4.3.1 Power Input 25

4.3.2 Temperature Input 26

5 Electrical Assembly 28

5.1 Input or output board 28

5.2 Power Distribution Board 29

5.2.1 Power Distribution Board connections for Solar-Input/AC-DC

input with lead acid battery back up 31

5.2.2 Power Distribution Board jumper settings for Alkaline Battery or

DC input 32

5.2.3 Power Distribution board Output voltage and Jumper settings 33

5.3 MODEM 33

6 Remote Pulser 34

6.1 Pulser to MIWI cable connections 35

7 Internal Wiring 38

7.1 Power Distribution Board and IO Board 38

7.2 Power Distribution Board and Modem 38

7.3 IO Board and MODEM 40

8 Battery Installation 42

8.1 Lead-Acid Battery 42

CONTENTS

8.2 Dual/Quad Alkaline Battery 43

8.3 Battery Life (approximate) 44

9 SLA Alarm Scenarios 45

10 Reference Drawings 47

10.1 MIWI350 with EC350 or ERX350 47

10.1.1 Wiring Dual or Quad Battery 47

10.1.2 Wiring Solar or External DC Power (13.5 to 15V DC) for MIWI35049

10.1.3 Wiring AC-DC Power for DIV2 50

10.1.4 Wiring AC-DC Power for DIV2 51

10.1.5 Wiring AC-DC Power for Zone2 53

10.1.6 Wiring External DC Power 55

10.2 MIWI350 as Power Box 56

10.2.1 Wiring Dual or Quad Battery for MIWIPCB 56

10.2.2 Wiring Solar or External DC (13.5 to 15V DC) Power for

MIWIPCB 58

10.2.3 Wiring AC DC Power for MIWIPCB 59

10.2.4 Wiring External DC Power for MIWIPCB 60

10.3 MIWI350as Power or Communication Box 61

10.3.1 Barrier Connections 61

10.3.1.1 With CloudLink MODEM 61

10.3.1.2 With CloudLink 4G M1 MODEM 62

10.3.1.3 With RV50/RV50X/RV55 MODEM 64

10.3.2 Terminal Block Connections 67

10.3.2.1 With CloudLink MODEM 67

10.3.2.2 With CloudLink 4G M1 MODEM 68

10.3.2.3 With RV50/RV50X/RV55 MODEM 70

11 Configuration Software 72

12 350S Audit Trail Log support for CloudLink MODEM 73

13 As Shipped Configuration Reload Procedure 76

14 Orderable Kits 78

CONTENTS

1 About MIWI350

The MIWI350 is the latest offering in the Honeywell's EVC Product Line. This product line provides a more

competitive, reliable, and easy to use solution. It provides a comprehensive selection of communication

hardware and power supply systems optimized to integrate with the Mercury Instruments precision

measurement instrumentation. It also includes software for Remote Monitoring and Data Acquisition

(RMADA), including alarm handling and notification.

The MIWI350 device typically includes:

• An integrated Electronic Volume Corrector or Electronic Recorder (using electronics from the

Honeywell EC350/ERX350

• An integrated electronic cellular MODEM

1.1 Product Features

• IECEx Class1 Zone2 Group IIB Certification

• CSA C/US Class 1, Division 2, Group C & D certification

• Compatible with MasterLink and PowerSpring software

• Available in UMB (Universal Mounting Bracket), Wall, Pipe, and Portable mounting options

• Internal or External Mounted Display

• MODEM Power Control through Power Distribution Board

• Optional Backup Battery for Uninterrupted EVC Functionality

• Pressure Expansion (PE) Board for Third Pressure, P3

1.2 Power Supply Options

• AC/DC or External 12V DC Power Supply (For Quick Start Guide Refer FD-611)

• Solar Power with rechargeable Sealed Lead-Acid Battery (For Quick Start Guide Refer FD-612

• Battery - Alkaline Packs (Dual/Quad) (For Quick Start Guide Refer FD-613)

• Power - Communication box (For Quick Start Guide Refer FD-614)

1.3 Abbreviations

AC Alternating Current

AT Audit Trail

CL CloudLink

CLR100 CloudLink 4G MODEM

CLR110 CloudLink 4G M1 MODEM

CORR.VOL Corrected Volume

CSA Canadian Standards Association

DC Direct Current

DoS Denial-of-Service

ELV Extra Low Voltage

1 About MIWI350

EVC/EC Electronic Volume Corrector / Electronic Corrector

FCC Federal Communications Commission

HMI Human Machine Interface

I/O Input/Output

IOB Input/Output Board

LAN Local Area Network

LED Light emitting diode

MC Metrological Configuration

MDM Mobile Device Management

MIWI350 MI Wireless with Gas Volume Correction functionality

MIWIPCB MIWI Power and Communication Box

MPC MODEM Power Control

MSG Model Selection Guide

PD Board Power Distribution Board

RF Radio Frequency

SLA Sealed Lead Acid

UMB Universal Mounting Bracket

PE Pressure Expansion

PWA Printed Wiring assembly

SELV Safety Extra Low Voltage

TAC Tower Area Code

TCP Transmission Control Protocol

UDP User Datagram Protocol

UL Underwriters Laboratories

VPN Virtual Private Network

1.4 Specifications

1.4.1 Power Input Sources and Options

Configuration Source/Battery

Type

Voltage

(VDC)

Battery

Backup Type

Backup

Battery

Voltage

(VDC)

Ampere

Hours

(Ah)

Battery

Power

usage

*Dual pack with

Supercap Alkaline 18 EVC &

MODEM

1 About MIWI350

Configuration Source/Battery

Type

Voltage

(VDC)

Battery

Backup Type

Backup

Battery

Voltage

(VDC)

Ampere

Hours

(Ah)

Battery

Power

usage

*Quad pack with

Supercap Alkaline 18 EVC &

MODEM

Backup Battery Alkaline 6 Yes Alkaline 6 EVC only as

backup

Solar with SLA

Battery Solar Panel 15 Yes Lead-Acid 12 7/21 EVC &

MODEM

AC/DC with SLA

Battery AC Input 15 Yes Lead-Acid 7/21 EVC &

MODEM

External 12V DC DC Input 12 Yes Alkaline 6 EVC only as

backup

Note: For more details on EC350 specifications refer User Manual and Datasheet.

Note: For Dual pack with Supercap and Quad pack with Supercap, power source is not supported for

MIWI350 Zone 2 variant.

Warning: Ensure that Alkaline battery type is selected while configuring SLA External Supply input

through MasterLink software.

1.4.2 Audit Trail

2MB memory is reserved for AT logs.

The device supports five AT logs. A maximum of 20 items can be configured in one AT log.

1.4.3 Certifications

Metrology

Measurement Canada (approval pending)

Haz Loc Certifications

CSA C/US Class I, Division 2, Groups C and D, T3C

IECEx Class I, Zone 2 Group IIB (approval pending)

Wireless Certification (IC & FCC)

Max RF POWER of the MODEM

CLR100: 25dBm/316mW ; CLR110: 23dBm/200mW

RV50/RV55 MODEM: 32dBm/1600mW ; RV50X MODEM: 23dBm/200mW

Industry Canada: IC ICES-003

FCC: Part 15 B Class-A Digital device

1 About MIWI350

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and;

2. This device must accept any interference received, including interference that may cause undesired

operation.

Note: This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates—and can radiate—

radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will

not occur in a particular installation.

Warning: Changes or modifications to this unit not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

Caution: This equipment has been tested. It complies with Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential installation.

This device generates, uses and radiates radio frequency energy. If this device is not installed and used

in accordance with the instructions, it can cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in installation.

Note: The radiated output power of the device is far below the exposure limits. Nevertheless, use the

device in such a manner that the potential for human contact during normal operation is minimal.

1.4.4 Wiring Guidelines for AC Input

Over current protection

It is required to install an input fuse in-order to protect the equipment from Over current and short circuit.

Recommended Fuse is as below:

INPUT FUSE RATING VOLTAGE RATING

230VAC 1A 250VAC Slow blow fuse

120VAC 1.5A 250VAC Slow blow fuse

12VDC 2A 250VAC Slow blow fuse

230/120AC Input Cable Specification

It is required to use a UL/CSA approved cable with working voltage spec of min 300V. Cable shall be

protected with an outer sheath.

Warning: For AC Input variant, readily accessible two-poled disconnect device must be incorporated in

the fixed wiring.

1 About MIWI350

1.4.5 Environmental

Maximum Operating Temperature Range (see listed configurations below):

-40 °F to +140 °F (-40 °C to +60 °C).

For your reference, the Operating Temperature Range for different assemblies are as below:

Ambient Temperature vs Assembly Code Table

Assembly code

(ACXX)1Ambient

Temperature

Range (°F)

Ambient Temperature

Range (°C) Assembly Description2

AC01 -4 to 113 -20 to 45 EVC, Modem, Barrier, and 21Ah SLA

Battery

AC02 5 to 113 -15 to 45 EVC, Battery, Barrier, and 7Ah

SLABattery

AC03 -4 to 131 -20 to 55 EVC, Modem, and Barrier3

AC04 -22 to 140 -30 to 60 EVC, RV50/RV50X/RV55 Modem3

AC05 -40 to 140 -40 to 60 EVC and CL4G Modem3

AC06 -14 to 113 -10 to 45 EVC, Modem, Barrier, and 21Ah SLA

Battery and AC-DC

1. The assembly code (ACXX) is also mentioned on the product Label for cross reference.

2. The assembly description indicates the max configuration supported for each assembly code.

3. Indicates the part which constraints the temperature range for each code.

Humidity: 0-95% Non-Condensing

Type of Installation: Out Door Unit

Altitude: Less than 2000m

Zone 2 Ambient Temperature vs Assembly Code Table

Assembly

code

(ExACXX)1

Ambient

Temperature

Range (°F)

Ambient

Temperature

Range (°C)

Assembly Description2

ExAC01 -4 to 113 -20 to 45 EVC, Modem, Barrier, and 21Ah SLA Battery

ExAC02 5 to 113 -15 to 45 EVC, Battery, Barrier, and 7Ah SLABattery

ExAC03 S-4 to 131 -20 to 55 EVC, Modem, and Barrier3

ExAC04 -22 to 140 -30 to 60 EVC, RV50/RV50X/RV55 Modem3

ExAC05 -40 to 140 -40 to 60 EVC

ExAC06 -14 to 113 -10 to 45 EVC, Modem, Barrier, 21Ah SLA Battery, and

AC-DC

1. The assembly code (ACXX) is also mentioned on the product Label for cross reference.

2. The assembly description indicates the max configuration supported for each assembly code.

3. Indicates the part which constraints the temperature range for each code.

1 About MIWI350

Otros manuales para MIWI350

Tabla de contenidos

Otros manuales de Controladores de Honeywell

Honeywell

Honeywell S9201A1010 Manual de usuario

Honeywell

Honeywell CIPer 50 Manual de instalación y operación

Honeywell

Honeywell ML7284 Manual de operación

Honeywell

Honeywell 11280S Manual de usuario

Honeywell

Honeywell MS7510A2008 Manual de usuario

Honeywell

Honeywell epc T5068A Manual de usuario

Honeywell

Honeywell PRO 2000 Series Manual del propietario

Honeywell

Honeywell ML7421A1032 Manual de operación

Honeywell

Honeywell LCBS Connect Instrucciones de uso

Honeywell

Honeywell Spyder 5 WEB-RxxN Series Manual de usuario

Honeywell

Honeywell UDC3300 Manual de usuario

Honeywell

Honeywell Lyric Manual de usuario

Honeywell

Honeywell ML9185 Manual de usuario

Honeywell

Honeywell Spyder BACnet PUB1012S Manual de usuario

Honeywell

Honeywell UDC3500 Manual de usuario

Honeywell

Honeywell CIPer 50 Manual de instalación y operación

Honeywell

Honeywell UDC 2300 Manual de usuario

Honeywell

Honeywell HR 10 F Manual de usuario

Honeywell

Honeywell Ex-Or MLS2000DALIHBW Manual de instalación y operación

Honeywell

Honeywell 4000 Series Manual de operación

Honeywell

Honeywell C7150B Manual de operación

Honeywell

Honeywell 190887-EET Manual de usuario

Honeywell

Honeywell VU443A Manual de operación

Honeywell

Honeywell V4055A Manual de operación

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
