Honeywell LC13-510 Manual de usuario

Dual Node Module

Service

LC13-510

LCN Service - 2

Dual Node Module

Service

LC13-510

Release 500

CE Compliant

9/95

Revision 01 – September 15 ,1995

While this information is presented in good faith and believed to be accurate,

Honeywell disclaims the implied warranties of merchantability and fitness for a

particular purpose and makes no express warranties except as may be stated in its

written agreement with and for its customer.

In no event is Honeywell liable to anyone for any indirect, special or consequential

damages. The information and specifications in this document are subject to

change without notice.

Dual Node Module Service 9/95

About This Publication

This publication provides instructions for use by system service personnel to service the

Dual Node Module. It helps you to determine how to perform service required on a Dual

Node Module, identifies spare parts, and provides disassembly/assembly instructions for

replacing the required part.

This publication is used to support the service of all nodes that reside in a Dual Node

Module, including those in a Universal Station.

This revision supports Release R500 and CE Compliance.

Any equipment designated as "CE Compliant" complies with the European Union

EMC and Health and Safety Directives. All equipment shipping into European Union

countries after January 1, 1996 requires this type of compliance—denoted by the "CE

Mark."

Change bars are used to indicate paragraphs, tables, or illustrations containing changes

that have been made to this manual effective with Release 500 and CE compliancy.

Pages revised only to correct minor typographical errors contain no change bars.

Dual Node Module Service 9/95

Standard Symbols

Scope The following defines standard symbols used in this publication.

ATTENTION Notes inform the reader about information that is required, but not

immediately evident.

CAUTION Cautions tell the user that damage may occur to equipment if

proper care is not exercised.

WARNING Warnings tell the reader that potential personal harm or serious

economic loss may happen if instructions are not followed.

53893

OR Ground connection to building safety ground

53894

Ground stake for building safety ground

53895

DANGER

SHOCK HAZARD

Electrical Shock Hazard—can be lethal

53896

DANGER

HIGH VOLTAGE

Electrical Shock Hazard—can be lethal

53897

Rotating Fan—can cause personal injury

Table of Contents

Dual Node Module Service i6/95

1 INTRODUCTION

1.1 Overview

1.2 Related Publications

2 MODULE DESCRIPTION

2.1 General Description

2.2 Basic Module Configurations

2.3 Specific Node Configurations

2.4 Front Panel

2.5 Rear Panel Assembly

2.6 Logic and Chassis Ground

2.7 Field Adjustments

2.8 LCN Network Grounding

2.9 Precision Clock Pinning (Power Supply Replacement)

2.10 NIM Modem Board Pinning

2.11 Power Supply Loading in LCNE2 Host Node

3 TEST/TROUBLESHOOTING

3.1 Tests

3.2 Test Procedures

3.2.1 Power-On Test

3.2.2 Reset Test

3.2.3 Quality Logic Test

3.3 Troubleshooting

3.3.1 Power Supply/Fan

3.3.2 Controller Boards

3.3.3 PLCI Board

3.3.4 Processor Board (K2LCN)

3.3.5 EPDG Board

3.3.6 EPNI Board

3.3.7 Fiber Optic Extender Boards

3.3.8 RS-485 to LCN Converter Boards (KLCNA, KLCNB)

3.3.9 NGI Board

4 DISASSEMBLY/ASSEMBLY

4.1 Disassembly

4.2 Assembly

5 SPARE PARTS

5.1 Introduction

Table of Contents

Dual Node Module Service ii 6/95

6 STARTUP

6.1 Visual Checks

6.2 Initialize Node

APPENDIX A

Alphanumeric Displays

INDEX

Dual Node Module Service 1-1 9/95

INTRODUCTION

Section 1

1.1 OVERVIEW

This publication provides detailed instructions for maintenance, test, troubleshooting and

repair of the Dual Node Module (part of the TDC 3000Xsystem) shown in Figure 1-1.

The troubleshooting, disassembly, and assembly procedures are effective down to the

optimum replaceable-unit (ORU) level. An ORU parts list is included and is keyed to a

module exploded view that is also used with the disassembly and assembly procedures.

Figure 1-1 — Dual Node Module 4121

1.2 RELATED PUBLICATIONS

The following publications should be referred to as required:

Title Binder

Maintenance Test Operations LCN Service - 1

System Maintenance Guide LCN Service - 1

History Module Service LCN Service - 2

LCN System Installation LCN Installation

LCN System Checkout LCN Installation

Universal Station Service LCN Service - 1

Universal Station (Ergonomic) Service LCN Service - 1

Universal StationXService Universal StationX

Universal StationX(Ergonomic)Service Universal StationX

Universal Workstation Installation, Operation

and Service LCN Service-2

Dual Node Module Service 1-2 9/95
