Honeywell HVC0001 Manual de usuario
Owner’s Guide
Guide du propriétaire
Guía del usuario
HVC0001 / HVC0002
Digital Bath Fan Control
Contrôleur de ventilateur numérique
Controlador digital de ventilador
400-305-000-A (69-2316EFS-01).book Page 1 Tuesday, March 24, 2009 1:53 PM
Read and save these instructions.
® U.S. Registered Trademark. Patents pending.
© 2009 Honeywell International Inc. All rights reserved.
Veuillez lire ce guide et le conserver en lieu sûr.
® Marque de commerce enregistrée aux États-Unis. Brevets en instance.
© 2009 Honeywell International Inc. Tous droits réservés.
Estas instrucciones deben leerse y conservarse
® Marca registrada en los EE. UU. Patentes en trámite.
© 2009, Honeywell International Inc. Todos los derechos reservados.
400-305-000-A (69-2316EFS-01).book Page 2 Tuesday, March 24, 2009 1:53 PM
Owner’s Guide 400-305-000-EFS
ENGLISH
Overview
About your digital bath fan control....2
Quick reference................................3
Installation
2-wire installation..............................4
4-wire installation..............................5
Setup
ASHRAE parameters .......................6
Time and date ..................................7
Backlight mode.................................8
Daylight saving time.........................9
Operation
Manual mode..................................10
Daily on/off program mode..............11
Customized cycle program mode ...12
ASHRAE 62.2 program mode.........13
Countdown mode............................ 14
Appendices
Customer assistance ......................15
5-year limited warranty ..................16
Table of contents
400-305-000-A (69-2316EFS-01).book Page 1 Tuesday, March 24, 2009 1:53 PM
Owner’s Guide 400-305-000-EFS
2
ENGLISH
The HVC0001/HVC0002 controller has been designed to control a single-speed bath fan. To suit the
user’s preference and lifestyle, it can be programmed in any the following modes of operation:
• Manual Mode (see page 10)
• Daily On/Off Program Mode (see page 11)
• Customized Cycle Program Mode (see page 12)
• ASHRAE 62.2 Program Mode (see page 13)
Unlike the four programmable modes mentioned above, the Countdown Mode can easily be
activated by simply pressing a button. In this mode, the fan is always On. At the end of the
countdown, set by the user, the controller returns to the programmed mode (see page 14).
This
controller cannot be used with a load lower than 0.1 A or higher than 2.5 A.
The controller can be used to control a bath fan’s built-in light or a separate light fixture
connected to the bath fan control circuit. However, the light cannot be independently
controlled and will turn On or Off at the same time as the fan.
About your digital bath fan control
400-305-000-A (69-2316EFS-01).book Page 2 Tuesday, March 24, 2009 1:53 PM
HVC0001/HVC0002
3
ENGLISH
Quick reference
The LED illuminates
when the bath fan is On.
Press the main button to turn the
bath fan On or Off. (Press for 3
seconds to enter the setup menus.)
Press either button to place in
Countdown Mode. Then press the
left button to decrease the
countdown time or the right button
to increase the time.
Setup menu
Clock
The bath fan is On The bath fan is Off
Programmable modes
Countdown time
If the controller is also used to control
lights, pull out before replacing the light
bulb. Push back in after the light bulb is
replaced.
CountdownMode
(see page 14)
400-305-000-A (69-2316EFS-01).book Page 3 Tuesday, March 24, 2009 1:53 PM
Owner’s Guide 400-305-000-EFS
4
ENGLISH
nCut power at the main electrical panel to avoid electric shock.
oRemove the existing switch if applicable.
pInstall the bath fan controller.
qApply power at the circuit breaker.
2-wire installation
black
white
black (LINE)
black (LOAD)
green (GND)
120
VAC black
white
For installationin wet locations, protect the circuit
with a ground fault circuit interrupter (GFCI).
400-305-000-A (69-2316EFS-01).book Page 4 Tuesday, March 24, 2009 1:53 PM
HVC0001/HVC0002
5
ENGLISH
nCut power at the main electrical panel to avoid electric shock.
oRemove the existing switch if applicable.
pInstall the bath fan controller.
qApply power at the circuit breaker.
4-wire installation
120
VAC black
white
black
white black (LINE)
black (LOAD)
green (GND)
For installation in wet locations, protect the circuit
with a ground fault circuit interrupter (GFCI).
400-305-000-A (69-2316EFS-01).book Page 5 Tuesday, March 24, 2009 1:53 PM
Owner’s Guide 400-305-000-EFS
6
ENGLISH
NOTE: Set the ASHRAE parameters before using the controller in ASHRAE mode.
When you power the controller for the first time, you will be prompted to set the following ASHRAE
parameters:
• Measurement units selection (US or metric)
• No. of bedrooms (1, 2, ..., 6)
• Floor space (1000, 1100, ..., 5000 sq. ft. or 100, 110, ..., 500 m2)
• Fan capacity (30, 40, ..., 200 CFM or 15, 20, ..., 100 LPS)
If you do not touch any button, the controller goes to normal display after 60 seconds and you will be
prompted to set the ASHRAE parameters again the next time the controller is powered down and back
up. The ASHRAE parameters can also be accessed at any time.
NOTE: Refer to the ASHRAE parameter flowchart sheet on how to set the parameters.
After you have set the ASHRAE parameters, the controller will indicate whether you pass or fail to meet
ASHRAE 62.2 standards and will also indicate the percentage of time the fan will run based on your
ASHRAE settings. If this value exceeds 100%, the controller will indicate Fail; this usually means the fan
capacity is insufficient for your house.
Set the ASHRAE parameters
400-305-000-A (69-2316EFS-01).book Page 6 Tuesday, March 24, 2009 1:53 PM
HVC0001/HVC0002
7
ENGLISH
The time display flashes on the screen when the time has not yet been set or after a power
outage of more than 4 hours. To set the clock, you need to perform the following:
• Select the time format (24-hour/12-hour)
• Set the time (hour and minutes)
• Set the date (year, month and day)
NOTE: Refer to the
menu flowchart
sheet on how to set the clock.
Set the time and date
400-305-000-A (69-2316EFS-01).book Page 7 Tuesday, March 24, 2009 1:53 PM
Owner’s Guide 400-305-000-EFS
8
ENGLISH
The controller provides 3 backlight modes. Depending on the mode selected, when you do
not press any button, the screen behaves as follows:
•Scrn Off: The screen is not lit.
•Scrn On HI: The screen is lit at high intensity.
•Scrn On LO: The screen is lit at low intensity (default mode).
When you press any button, the screen is lit at high intensity for 8 seconds.
NOTE: Refer to the
menu flowchart
sheet on how to set the backlight mode.
Set the Backlight mode
400-305-000-A (69-2316EFS-01).book Page 8 Tuesday, March 24, 2009 1:53 PM
