Thor™ VM2

Vehicle-Mount Computer

Quick Start Guide

VM2-QS Rev A

10/12

Setting up the Thor VM2

Please have the following Information available before

setting up your Thor VM2:

lNetwork ID (SSID) of the Access Point

lWEP key or LEAP authentication credentials

1. Connect the Thor VM2 to an external power

source.

2. Press the Power button.

3. It may be desirable to attach a USB keyboard

during the setup process.

4. Accept the EULA.

5. Calibrate the touch screen.

6. Set the date and time.

7. Edit the radio parameters.

8. Edit the RFTerm Terminal Emulation

parameters (optional).

9. Perform a reboot.

Bluetooth and Thor VM2

Please refer to the Thor VM2 Reference Guide for

information when using the Thor VM2 with Bluetooth.

ActiveSync (CE 6.0 only)

Installing ActiveSync on Desktop/Laptop

ActiveSync (version 4.5 or higher for Windows XP

desktop/laptop computers) must be resident on the

host (desktop/laptop) computer. Windows Mobile

Device Center is required for a Windows

Vista/Windows 7 desktop/laptop computer. ActiveSync

and Windows Mobile Device Center for the PC are

available from the Microsoft website. Follow Microsoft's

instructions to locate, download and install ActiveSync

or Windows Mobile Device Center on your

desktop/laptop.

ActiveSync using USB-Client Connection

The only connection type is USB Client.

1. Connect the Thor VM2 end of the USB cable to

the USB port on the back of the Thor VM2 Quick

Mount Smart Dock.

2. Connect the USB type A connector on the I/O

cable to a USB port on a PC or laptop.

ActiveSync starts automatically when the USB cable is

connected.

When the Thor VM2 loses connection (e.g., enters

Suspend Mode), the connection to ActiveSync will be

temporarily lost. When the Thor VM2 resumes, the

ActiveSync session will automatically re-connect.

Please refer to the Thor VM2 Reference Guide for

ActiveSync information.

Setting Up the Radio

If the access point uses an authentication protocol

(WEP, LEAP, etc.), your radio must use the same

authentication. Please contact your IT department for

WEP keys or LEAP credentials. Please refer to the

Thor VM2 Reference Guide for information on using

WPA.

1. Tap Start > Programs > Summit > SCU OR

tap the Summit Client Utility icon on the

desktop.

2. Tap the Admin Login button and enter the

password (default = SUMMIT).

3. Tap the Profile tab and make sure the Default

profile is selected.

4. Select SSID and enter your SSID value.

5. If the access point is using WEP, select WEP

from the Encryption pull down list.

6. Tap the WEP keys/PSKs button and enter the

WEP Key(s) and tap OK. Skip to step 12.

7. If the access point is using LEAP, select LEAP

from the EAP Type pull down list.

8. Select WEP EAP from the Encryption pull down

list.

9. If the Cisco/CCS certified AP is configured for

open authentication, set the Auth Type radio

parameter to Open.

10. If the AP is configured for network EAP only, set

the Auth Type radio parameter to LEAP.

11. Tap the Credentials button and enter the User

Name and Password.

12. Tap the Commit button to save the radio

configuration.

13. Tap the Main tab. Wait for a radio connected

message.

14. Tap the Admin Logout button when finished.

15. Reboot the Thor VM2.

Please refer to the Radio Mode parameter in the Thor

VM2 Reference Guide. It is important that this

parameter setting corresponds to the Access Point to

which the Thor VM2 connects.

Setting Up AppLock (CE 6.0 only)

Thor VM2 devices are shipped to boot in

Administration mode. In this mode, the user has full

access to the device and no password is needed. After

the administrator completes the process below, the

Thor VM2 switches to end-user mode and restricts

access to only the specified application(s).

1. Tap Start > Settings > Control Panel >

Administration icon.

2. Assign application(s) on the Application tab

screen.

3. Assign a password on the Security tab screen.

4. Select a view level on the Status tab screen, if

desired.

5. Tap OK.

6. Press the hotkey (Ctrl +Shift +A) sequence to

launch AppLock and lock the configured

application(s).

7. The device is now in end-user mode.

Connecting Using RFTerm

Before you make a host connection, you will, at a

minimum, need to know:

lthe alias name or IP address (Host Address)

and

lthe port number (Telnet Port) of the host system

to properly set up your host session.

1. Make sure the mobile client network settings

are properly configured. If you are connecting

via WLAN (802.11x), make sure your Thor VM2

is connected to the network.

2. Launch RFTerm by tapping the RFTerm icon

on the desktop.

3. Select Session > Configure from the

application menu and select the host type. This

is dependent on the host system to which you

are connecting; i.e., 3270 mainframe, AS/400

5250 server or VT host.

4. Enter the Host Address of the system. This

may either be a DNS name or an IP address of

the host system.

5. Update the telnet port number if your host

application is configured to listen on a specific

port. If not, use the default telnet port.

6. Select OK.

7. Select Session > Connect from the application

menu or tap the Connect button on the Tool

Bar.

8. Upon a successful connection, the host

application screen is displayed.

To change options (e.g., Display, Colors, Cursor,

Barcode), please refer to the RFTerm Reference Guide

for descriptions of these and other features.

Rebooting the Thor VM2

To warmboot the Thor VM2 with Windows CE 6.0:

1. Select Start > Settings > Control Panel >

Registry.

2. Tap the Warmboot button.

To reboot the VM1 Thor with Windows Embedded

Standard:

1. Select Start > Shutdown >Restart to reboot.

When the Thor VM2 is booting, there may be small

delays while the wireless client connects, applications

launch, remote management completes and Bluetooth

devices connect.
