Holux GR-213USB Manual de usuario

GR-213USB GPS Receiver

 Features:

 SiRFstarIII chipset with embedded ARM7TDMI CPU available for customi ed applications

in firmware

 High performance receiver tracks up to 20 satellites while providing first fast fix and low

power consumption.

 Compact design ideal for applications with minimal space.

 A rechargeable battery sustains internal clock and memory. The battery is recharged during

normal operation.

 Users can adjust power-saving percentage (20%~80%), which achieves the best power

efficiency.

 User initiali ation is not required.

 LED display status: The LED provides users visible positioning status. LED “ON” when

power connected and “BLINKING” when GR-213U got positioned.



Water proof design for industry standard.

 Specifications

 Tracks up to 20 satellites.

 Receiver: L1, C/A code

 Max update rate: 1 HZ.

 Acquisition time

Reacquisition 0.1sec.averaged

Hot start 1 sec., averaged

Warm start 38 sec., averaged

Cold start 42 sec., averaged

 Position accuracy：

 Non DGPS (Differential GPS)

Position 5-25 m CEP without SA

Velocity 0.1 m/sec, without SA

Time 1 usec sync GPS Time

 EGNOS/WAAS：

Position

< 2.2 m, hori ontal 95% of time

< 5 m, vertical 95% of time

 Dynamic Conditions:

Altitude 18,000 meters

(60,000 feet ) max

Velocity 515 meters / second

(700 knots) max

Acceleration 4 G, max

Jerk 20 meters/second, max

 Antenna Type: Built in Patch Antenna

 Minimum signal tracked: -159dBm

 Dimension: 2.54 × 1.65 × 0.7 Inch

 Weight : < 84g

 LED function:

Power On/Off and Navigation

Update Indication

 Operating temperature:

-10 to +60

 Storage temperature:

-20 to +70

 Operating humidity:

5% to 95% No condensing.

 Power consumption

< 80mA at 4.5- 5.5V input

 Protocol and interface:

 NMEA output protocol: V.2.2

Standard:

Baud rate: 4800 bps

Data bit: 8

Parity: N

Stop bit: 1

Format: GGA,GSA,GSV, RMC.

Optional:

Baud rate: 9600,19200,38400

Format: GLL,VTG, ZDA, SiRF

binary

 Interface:

USB interface

 Physical Dimension：

：：

：

 Output terminal and definition

Output terminal:

USB connector

Pin definition:

Signal Name

1 +5V

2 D +

3 D -

4 Ground
