HITWAY BK5 Manual de usuario

Electrically Assisted Bicycle

Model: BK5

User's Manual

V2022.0.2

HOW TO CONTACT US ON AMAZON?

Step 1: Log in to your Amazon account.

Step 2: Go to Your Orders. Select

Problem with order in the list.

Step 3: Click the "Ask a Question" button.

Choose your topic from list displayed.

Step 4: Select Contact seller.

*If you purchased HITWAY products by other platforms or channels, please

also find the corresponding seller contact support. Thanks for your

support and patience!

LANGUAGE LIST

EN........................1

DE........................8

FR........................15

ES........................22

IT.........................29

NL........................36

PL........................43

ATTENTIONSBattery And Charging：Charge af Oc~45℃, discharge at -20℃~60℃. keep the battery dry. Do not put the battery in acidic or alkaline liquid. Avoid rain and keep away from ﬁre, heat and high temperature environment. It is strictly forbidden to connect the positive and negative poles of the battery reversely. It is strictly forbidden to damage, insert the battery or cause short-circuit. Please use the speciﬁc original charger for charging, with charging time no more than 6 hours and thecharging current no larger than 2 A. When not in use for a long time, please store the battery in a cool and dry place, and charge the battery for ﬁve hours every month. The user must follow the instructions for use when charging, otherwise the consequences will be at his own risk. Pay attention to the battery type and applicable voltage that the charger can charge, and it is strictly forbidden to mix usage. When charging, it should be placed in a ventilated environment. It is strictly forbidden to charge in residential buildings, conﬁned spaces, or in hot sun and hightemperature environments. When charging, plug in the battery ﬁrst, then connect to power supply socket; after charging enough, cut oﬀ the mains ﬁrst, and then unplug the battery. When the green light is on, the power supplyshould be cut oﬀ in time, and it is forbidden to connect the charger to the AC power supply without load for a long time without charging. During the charging process, if the indicator light is abnormal, there is a peculiar smell, or the charger casing is overheated, stop charging immediately, and repair or replace the charger. During the use and storage of the charger, pay attention to avoid foreign objects entering, especially avoid entering water or other liquids, so as not to cause a short circuit inside the charger. The charger should not be carried with the car as much as possible. If it is necessary to carry it, it should be placed in the toolbox after the shock absorption treatment is done. Do not disassemble or replace the accessories in the charger by yourself.Ride：Do not use it until you read the instructions carefully and understand the performance of the product; do not lend it to people who can't manipulate the product for riding. Before riding the bicycle, check whether the brakes are working. When you brake, please activate the rear brake ﬁrstly, and then the front brake. Pay attention to the brake tightness. If the brake is too loose, use an Allen key to tighten it. Pay attention to increasing the braking distance when riding in rain or snow. Suitable age:Riding between 16 and 65 years old.Please be sure to wear a safety helmet when riding a bicycle, follow the traﬃc rules, and do not drive on motorized lanes and roads with many pedestrians. Please check the tire pressure before riding. The recommended tire pressure is 35～42 PSI.When riding on downhill and non-paved roads, make sure the speed do not exceed 15 KM/h.When using the motor, please be careful not to hit it vigorously and keep the rotating shaft lubricated. It is not allowed to ride with more than the maximum load of the body (the maximum load is 120 KG)After use, the car can not be parked in the building hall, evacuation stairs, safety exits, and must be parked correctly in accordance with the safety rules.One-handed riding is prohibited!Liability Statemen ：After riding, please store the bike in a place without sunlight and rain, not in a residential building; Regularly check the motor and brake;Regularly check the various screws of the car and the places that need to be tightened, and tighten them regularly.Recommended torque: (unit: kgf. cm) horizontal screws 60-80, stem screws 175 ~200, seat cushion screws 175 ~ 200, wheel screws 320 ~ 450;The front and rear wheels of the vehicle should be located in the center of the front fork or frame;Always check the rotation for scratches, cracks or excessive wear. The inner tube and valve should be perpendicular to the wheel hub and not crooked. Damaged or excessive; worn tires need to be replaced immediately, please ﬁnd a professional technician to replace your tires, if your tires accidentally puncture and leak, please contact a professional technician for repair or replacement.Maintenance:The product models, speciﬁcations or related information mentioned in this manual are reserved by the company with the right to modify and ﬁnal interpretation; the functions of a speciﬁc modelmentioned in this manual are only applicable to that speciﬁc model;The product models, speciﬁcations or related information mentioned in this manual are subject to any modiﬁcation or change without notice;Without the prior written permission of the company, it is not allowed to copy, modify, reprint,disseminate or publish the contents of the user manual in any form. Please read this user manual carefully before using the product, and operate in accordance with the manual,otherwise the product may be caused by improper use or error, and Our company is not liable for damages or personal or property losses.(1)

English / German / French / Spanish / ltalian / Dutch / Polish

(Model:BK5) Product Function Diagram

1. Display

2. Handlebar

3. Brake lever

4. Front reflector

5. Vertical pipe adjustment

quick release

6. Handlebar tube

7. Tube folding quick release

8. Headlight

9. Front fender

10. Front fork

11. Tire

12. Disc brake

13. Wheel hub

14. Wheel reflector

15. Disc brake system

16. Frame folding quick release

17. Sprocket

18. Battery

19. Folding pedal

20. Chain

21. Motor

22. Rear fender

23. Rear bracket

24. Taillight

25. Rear seat panel

26. Charging port

27. Seat tube adjustmeng quick

release

28. Seat tube

29. Saddle

Function Introduction:(2)

English / German / French / Spanish / ltalian / Dutch / Polish

1. Charging: Unscrew the plastic cover on the battery (Picture 1), connect the charger to start charging, when the battery is full and the indicator light of the charger changes from red to green, it means it is fully charged.(Picture 1)

(3)

English / German / French / Spanish / ltalian / Dutch / Polish

(Picture2) (Picture 3)

2. Power on: refer to Picture 2, turn on the battery switch; refer to Picture 3, press and hold button to turn on/oﬀ .3. Power display: After powering on, the dashboard lights up to display the power, and the power is divided into 5 grids, corresponding to high, medium and low power.4. Headlights: refer to Picture 3, long press the button to turn on/oﬀ the headlights.5. Start: power-assisted riding, short press to adjust to 1st gear after power on, step on the bicycle sprocket, start the motor to assist. If motor assistance is not required, turn oﬀ the power or turn oﬀ the battery or set the gear to 0.

PRODUCT PARAMETER(4)

English / German / French / Spanish / ltalian / Dutch / Polish

Outlook &

Dimension

Performance

Parameters

Parameter

Body Material

Color

Unfolding Size

Folding Size

Hub Form

Wheel Size

Standard Version

Q195 carbon structural steel

Matte Black

1390mm*530mm*1040mm

800mm*500mm*680mm

Integrated wheel

16 inches

Net

Maximum Load

Maximum Speed

Mileage

Maximum Climbing Angle

Proper Temperature

Waterproof Level

22.5kgs

120kg

25Km/h

35KM-70KM(At 75kg and 25°C,

the pure electric mileage can

reach 35KM, and the moped

mileage depends on the load

and riding style)

25 degree

-10～45℃IP54

Electrical

Specifications

Battery Type

Battery Capacity

Battery Rated Voltage

Motor Rated Power

Motor Form

Motor Type

Motor Rated No-Load Speed

Charger Output

Charger Input

Undervoltage Protection

Value

Overcurrent Protection Value

Charging Time

18650 lithium ion power battery

8.4AH

36V

250W

Assist mode

16 inch/high speed gear/

Integrated wheel brushless motor

480±10r/min

42V 2.0A

100~240V 50/60Hz 3.0A

29V

15A±1A

4-5 hours

Remarks: The factors, including Battery power capacity, load, tire pressure, road environment,chain and wheel axle lubrication, etc., will aﬀect the maximum speed; the cruising distance indicatedin this manual ﬁle is the test result from the riding test conducted uninterruptedly with load of 60kg,at the speed of 15-25km/h, and on the ﬂat and hardened road surface, from full charge to full powerconsumption.; Driving habits, temperature, load, tire pressure, road environment and other factorswill aﬀect the actual cruising distance.Overview:LCD Display and GripInstruction Manual(5)

English / German / French / Spanish / ltalian / Dutch / Polish

Features

Instrument Display

Front Lighting

Braking Method

Tire Specifications

Multifunctional LCD screen

YES

Front disc brake +

Rear disc brake

Pneumatic tires

Tire: 16×2.125

Valve: American air valve(AV )

LCDMode switchOn/Oﬀ

Display Interface:Instructions:

-On/oﬀPress the power button to turn on and oﬀ the machine, press the button, the lockedposition is the power on state, press again, the button bounces out position is oﬀ.-Switch gearsShort press (<1 second) the function button to switch the speed gears. There are 3gears (MODE 1:1, MODE 2:2,MODE 3: 3 gears).-Switch the display content of the mileage areaThe single mileage is displayed by default after power-on. Long press (>3 seconds)the function button to cycle through the display content of the mileage area.Single mileage (TRIP) -> accumulated mileage (ODO) -> fault code (ERR) -> batteryvoltage (UXX.X).Note: Each time you turn oﬀ the machine and turn it on again, the single mileage willbe reset to zero, and the accumulated mileage will continue to accumulate.-Fault code displayWhen a fault is detected, the "ERR" icon will be displayed. At this time, press andhold the function button (>3 seconds) to switch the check.Look at the current fault code, please refer to the attached table for the meaning ofthe fault code.

(6)

English / German / French / Spanish / ltalian / Dutch / Polish

List of fault codes:Cod 000NormalBrake Lever FailureBattery Under-voltageMotor FailureHandlebar FailureController FailureInstrument Communication/Receiving failureController communication/ receiving failure002006007008009010011Meaning(7)

English / German / French / Spanish / ltalian / Dutch / Polish

Note: 1. Due to the upgrade of the company's products, the display content of the product you get may be diﬀerent from the manual, but it will not aﬀect your normal use. Everything is subject to the real object, and the company reserves the right of ﬁnal interpretation. 2. The parameter settings of the instrument have been set at the factory. Please operate according to the instructions in the manual, and do not change the original settings of the instrument. The company is not responsible for any abnormal function or function damage caused by not following the instructions in the manual.3. Do not immerse the instrument in water, or use a water jet to clean the meter. When cleaning, wipe with a soft cloth dampened with water. Do not wipe with any cleaning agent. 4. Do not dispose of the instrument or any other E-bike accessories as resident waste. Please comply with local laws and regulations and dispose of or recycle Ebike accesso-ries in an environmentally friendly manner.
