Hitachi WJ-0001S Manual de usuario

Printed in Japan(H)SM-E265 1109

Designed for excellent performance and user friendliness

Pursuing the Ideal Compact Inverter

Series

Pursuing the Ideal Compact Inverter

Hitachi Solar Water Pump

Inverter System

Hitachi Solar Water Pump

Inverter System

KHKSCO GROUP

Objective of this Manual:

The objective of this manual is to educate the user for proper installation and for putting the system into

use.

Scope Statement:

The scope of this manual covers only installation, commissioning and general operations of the

Solar Water Pump Inverter

How-ever, some information on primary maintenance can be found in this manual.

Operation Manual

Table of Contents:

Chapter

Page

About the System

Overview

1-1

Solar Power and Irrigation

1-1

Safety

Definitions And Symbols

2-1

General Warnings and Cautions

2-2

UL Cautions, Warnings And Instructions

2-3

Installation Preparation & Requirements

Terminal Screw and Wire size

3-1

Fuse Size

3-2

Mounting Location

3-3

Electrical Wiring

3-4

Connection to Solar Water Pump

System

Power Wire For Solar Inverter

4-1

Control Wiring For Solar Inverter

2-8

2-9

Keypad Description

2-10

Key and Indicator Legend

2-11

Operating Principle And Hardware

Principle of Solar Water Pump Inverter

5-1

MPPT Over view

5-2

Motor Requirement

5-3

System Start-Up

Parameter Settings

6-1

Steps for setting Inverter for System

6-4

Fault Code

6-5

Monitoring System Data

6-6

PC Tools for Monitoring

6-9

Maintenance And Inspection

Modbus Network Communication

Introduction

8-1

Connecting Inverter to Modbus Network

8-2

Modbus Parameter Setting

8-3

Common Fault and Remedies

Contacts

About the System 1

In this chapter…

Page

About the System

Over View

1-1

Solar Power and Irrigation

1-1

For the purpose of this manual and the product the following symbols are used.

Overview:

The system operates on power generated using solar PV (photovoltaic) system. The

photovoltaic array converts the solar energy into electricity, which is used for running

the motor pump set. The pumping system draws water from the open well, bore well,

stream, pond, canal etc.

The system requires a shadow-free area for installation of the Solar Panel.

Of all the ways solar electricity benefits the people on Earth, none makes as much

difference in the daily lives as pumping water. By providing water for irrigation or

potable water have obvious benefits for people in rural areas and especially for those

in developing nations. The proper choice is determined by application specific factors

like how much water is required and whether the water should be available at night

or just during high sun hours.

Solar Power and Irrigation:

Irrigation is best utilisation of Solar power

Usually area which require more water have high solar irradiation

During summer time when more water is require, there is more sun light

Water need not be available at night

Maintenance facilities are lacking, Solar pump run maintenance free.

Solar tracking can use.

Safety 2

In this chapter…

Page

Introduction

2-1

Definition and Symbol

2-3

General warning and Cautions

2-3

UL Cautions, Warning and Instructions

2-1 Safety Information

Definitions and Symbols

HAZARDOUS HIGH VOLTAGE: Motor control equipment and electronic

controllers are connected to hazardous line voltages. When servicing drives and

electronic controllers, there may be exposed components with housing or protrusions at

or above line potential. Extreme care should be taken to protect against shock. Stand on

an insulating pad and make it a habit to use only one hand when checking components.

Always work with another person in case an emergency occurs. Disconnect power before

checking controllers or performing maintenance. Be sure equipment is properly

grounded. Wear safety glasses whenever working on electronic controllers or rotating

machinery.

WARNING: This equipment should be installed, adjusted, and serviced by qualified

electrical maintenance personnel familiar with the construction and operation of the

equipment and the hazards involved. Failure to observe this precaution could result in

bodily injury.

WARNING: For equipment protection, install a ground leakage type breaker with a

fast response circuit capable of handling large currents. The ground fault protection

circuit is not designed to protect against personal injury.

WARNING: HAZARDOUS OF ELECTRICAL SHOCK. DISCONNECT INCOMING

POWER BEFORE WORKING ON THIS CONTROL.

WARNING: Wait at least five (5) minutes after turning OFF the input power supply

before performing maintenance or an inspection. Otherwise, there is the danger of

electric shock.

CAUTION: Proper grounds, disconnecting devices and other safety devices and

their location are the responsibility of the user and are not provided by Hitachi Industrial

Equipment Systems Co., Ltd.

HIGH VOLTAGE: Dangerous voltage exists until power light is OFF. Wait at least

five (5) minutes after input power is disconnected before performing maintenance

WARNING: This equipment has high leakage current and must be permanently

(fixed) hard-wire to earth ground via two independent cables.

WARNING: Rotating shafts and above-ground electrical potentials can be

hazardous. Therefore, it is strongly recommended that all electrical work conform to

the National Electrical Codes and local regulations. Installation, alignment and

maintenance should be performed only by qualified personnel.

CAUTION:



b) Any motor used must be of a suitable rating.

c) Motors may have hazardous moving path. In this event suitable protection must be

provided.

CAUTION: Hazardous (main) terminals for any interconnection (motor, contact

breaker, filter, etc.) must be inaccessible in the final installation.

CAUTION: This equipment should be installed in IP54 or equivalent enclosure.

CAUTION: Connection to field wiring terminals must be reliably fixed having

two independent means of mechanical support. Use a termination with cable support

(figure below), or strain relief, cable clamp, etc.

General Warnings and Cautions

WARNING: Never modify the unit. Otherwise, there is a danger of electric shock and/or injury.

CAUTION: Withstand voltage test and insulation resistance tests (HIPOT) are executed before

the units are shipped, so there is no need to conduct these tests before operation.

CAUTION: Do not attach or remove wiring or connectors when power is applied. Also, do not

check signals during operation.

CAUTION: Be sure to connect the grounding terminal to earth ground.

CAUTION: When inspecting the unit, be sure to wait five minutes after turning OFF the power

supply before opening the cover.

UL Cautions, Warnings and Instructions

Warnings and Cautions for Troubleshooting and Maintenance The warnings and instructions in

this section summarizes the procedures necessary to ensure an inverter installation complies with

delines.

-001L, -002L, -004L, -007L, -015S, -

022S, -004H, -007H, -015H, -022H and -030H)

WARNING: Use 75 -001S, -002S, -004S, -007S, -015L, -

022L, -037L, -055L, -075L, -110L, -150L, -040H, -055H, -075H, -110H and -150H) WARNING: Suitable

for use on a circuit capable of delivering not more than 100,000 rms Symmetrical Amperes, 240 or

480V maximum.

WARNING: When protected by CC, G, J, or R class Fuses, or when Protected By A Circuit

Breaker Having An Interrupting Rating Not Less Than 100,000 rms Symmetrical Amperes, 240 or 480

Volts Maximum.

WARNING: Install device in pollution degree 2 environment.



WARNING: Solid state motor overload protection is provided in each model

WARNING: Integral solid state short circuit protection does not provide branch circuit protection.

Branch circuit protection must be provided in accordance with the National Electric Code and any

additional local codes
