Hisense WFER1014VA Instrucciones de montaje
使用说明书
80g胶版纸
X08060486
X08060486
版本号
设计
审 核
工 艺
标准化
更改单编号
会签
会签
批准
图形识别符号
重 量 比 例
第 张 共 张
A
平度10kg自动投放通用
2033651
王爱军 2019.09.10
崔维明 2019.09.10
刘泽旺 2019.09.10
程木聪 2019.09.10 石伟泽 2019.09.10
1. 材料：80g 双胶纸，正反面印刷；
2. 印刷为黑白色单色印刷；
3. 所有印刷内容正确、清晰，不得有漏印、误印，无印刷缺陷；
4. 幅面：（210±3）X（145±3），（单位：mm）；
5.
未注公差按照GB/T 1804-m ；
6.颜色及整体效果必须经过研发部确认后方能生产，产品检验以封样件为准；
7.符合 RoHS现行标准要求和REACH指令;
技术要求
说明书安全警示语部分大写字母高度大于3mm。
8.
英文
孔祥娟 2019.09.10
2033651-X08060486A
SAFETY INFORMATION
1
The manufacturer reserves the right for any modifications
on the product which might be deemed necessary or
useful without informing about it in this IFU.
Before operating your new washing machine, please read
this instruction carefully, and keep it for future reference. If
you have lost it accidentally, ask customer service for e-
copy or hard copy.
Please make sure the socket is grounded securely, the
water source connection is reliable.
4. This appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
5. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
6. Children should be supervised to ensure that they do not
play with the appliance.
7. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
8. The new hose-sets supplied with the appliance are to be
used and that old hose-sets should not be reused.
SAFETY INFORMATION
1.
2.
3.
ensure
Ensure
Single inlet -
Dual inlet - and cold
only
Ensure that the ventilation openings in the base of the washing machine
(if available on your model) are not obstructed by a carpet or other material.
2 3
9. For appliances with ventilation openings in the base, that a
carpet must not obstruct the openings.
10. Children of less than 3 years should be kept away unless
continuously supervised.
The maximum permissible inlet water pressure, 1 MPa, for
appliances intended to be connected to the water mains.
The minimum permissible inlet water pressure, 0.1 MPa, if
this is necessary for the correct operation of the appliance.
The maximum washing capacity is 10 kg.
For private domestic use only.
This appliance is intended to be used in household and
similar applications such as:
− staff kitchen areas in shops, offices and other working
environments;
− farm houses;
− by clients in hotels, motels and other residential type
environments;
− bed and breakfast type environments;
− areas for communal use in blocks of flats or in
launderettes.
11.
12.
13.
14.
45
that
the
ing
en
the
from the mains supply,
,
615 mm
855 mm
the mains.
The symbol on the product, or on the documents accompanying the product,
indicates that this appliance may not be treated as household waste. Instead it
shall be handed over to the applicable collection point for there cyclingof electrical
and
electronic equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed information about
treatment, recovery and recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased
the product.
that
Control panel layout and appearance will depend on the model.
6 7
Clean the outside of the washing machine with a damp cloth. Do not use abrasive
detergents.
Never open the door forcibly or use it as a step.
1. Sort the laundry according to...
Type of fabric / care label symbol
Cottons, mixed fibres, easy care/synthetics, wool, handwash items.
Colour
Separate coloured and white items. Wash new coloured articles separately.
Loading
Wash items of different sizes in the same load to improve washing efficiency and
distribution in the drum.
Delicates
Wash small items (e.g. nylon stockings, belts etc.) and items with hooks (e.g. bras)
in a cloth bag or pillow case with zip. Always remove curtain rings or wash curtains
with the rings inside a cotton bag.
2. Empty all pockets
Coins, safety pins etc. can damage your laundry as well as the appliance drum and
tub.
3. Fasteners
Close zips and fasten buttons or hooks; loose belts or ribbons should be tied
together.
Stain removal
Blood, milk, eggs etc. are generally removed by the automatic enzyme phase of the
programme.
To remove any residual water used during testing by the manufacturer, we
recommend that you carry out a short wash cycle without laundry.
1 Open the tap.
2 Close the door.
3 Pour a little detergent (about 30 ml) into the middle detergent compartment .
4 Select and start a short programme (see separate quick reference guide).
BEFORE THE FIRST WASH CYCLE
PREPARATION OF THE WASHING
DESCRIPTION OF THE WASHING MACHINE
while the
while the
is
is
can
for
for to be
1
2
4
5
6
3
8 9
U
A
.
Open the door.
Powder detergent compartment（Middle）
When the auto dosing function is cancelled,
please place the detergent into this compartment.
compartment
compartment
compartments
middle compartment
H
M
10 11
unds
Select the “Rinse+Spin” programme,reduce the speed to 1000rpm and strat
2 Insert removal tool like slotted screwdriver into the small opening of bottom
baffle, press the bottom baffle downward with much strength and open it.
1
Before emptying the residual water, switch the appliance off and unplug it
fromthe mains socket. Remove the plinth,place a container beneath it.
DRAINING RESIDUAL WATER
(depends on model)
1 Pull out emergency drain pipe of machine.
2 Put end of emergency drain pipe into a container.
3 Rotate emergency drain pipe plug and remove it after it becomes loose.
4 Until water runs off naturally.
5 Reinstall emergency drain pipe plug.
6 Fill detergent box with 1L water to check
emergency drain pipe.Check if there is
any leakage at connection of pipe plug.
7 Put emergency drain pipe back.
if it fails to perform spin cycles.
Ensure that the water has
We recommend that you check and clean the filter regularly, at least two or three
times a year.
1. While holding down the release lever on the inner
of the drawer, slide open the drawer and remove
it from the machine.
2. Open the lids of both compartments, add water
and shake to loosen/remove soap residue.
Repeat until clear.
3. Clean the cap valves of both compartments with a
soft brush.
4. Clean the drawer components under running
water using a soft brush.
5.Clean the drawer recess within the machine using
a soft brush. Make sure to clean the cap valves to
prevent clogging.
6. Once cleaning is complete, slide the drawer back
into position ensuring it moves freely into its fully
retracted position.
Powder detergent compartment（Middle）
Powder detergent compartment（Middle）
Powder detergent compartment（Middle）
12 13
3 Put a flat container under filter door and then drain with emergency drain pipe
(see [draining residual water] for specific operation methods). Then, loosen
filter anticlockwise and completely unscrew and remove the filter.
Check the supply hose regularly for brittleness and cracks and replace it if
necessary using a new hose of the same type(available from After-Sales Service
or specialist dealer).
4
5
6
7
