Hisense WFEH1014VJ Manual de usuario
说明书
80g胶版纸
X08060130
X08060130
版本号
设计
审 核
工 艺
标准化
更改单编号
会签
会签
批准
图形识别符号
重 量 比 例
第 张 共 张
B
后附图纸33页
(语言顺序为英语、西班牙语、葡萄牙语)
技术要求
1.材料：80g双胶纸，正反面印刷；
2.印刷为黑白色单色印刷；
3.所有印刷内容正确、清晰，不得有漏印、误印，无印刷缺陷；
4.幅面：（210 ）X（145 ），（单位：mm）；±3±3
5.未注公差按照GB1800(现行).IT15；
6.颜色及整体效果必须经过研发部确认后方能生产，产品检验以封样件为准；
7.符合RoHS现行标准要求和REACH指令。
平度通用
1885442
王希芳 2017.06.26
崔维明 2017.06.26
李帅民 2017.06.26
程木聪 2017.06.26 石伟泽 2017.06.26
刘松 2017.06.26
XECN001244
21
ensure
Ensure
Single inlet -
Dual inlet - and cold
only
Ensure that the ventilation openings in the base of the washing machine
(if available on your model) are not obstructed by a carpet or other material.
NOTE
The manufacturer reserves the right for any modifications on
the product which might be deemed necessary or useful
without informing about it in this IFU.
Thank you for choosing a Hisense washing machine.
Before operating your new washing machine, please read this
instruction carefully, and keep it for future reference. If you have
lost it accidentally, ask customer service for e-copy or hard copy.
Please make sure the socket is grounded securely, the water
source connection is reliable. The manufacturer declines all
liability and warranty for damage to property or injury to
persons or animals due to non-compliance with the directions
given in this instruction.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
The new hose-sets supplied with the appliance are to be used
and that old hose-sets should not be reused.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical. Sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Children of less than 3 years should be kept away unless
continuously supervised.
The maximum permissible inlet water pressure, 1 MPa, for
appliances intended to be connected to the water mains
The minimum permissible inlet water pressure, 0.1 MPa, if
this is necessary for the correct operation of the appliance
For washing machines with ventilation openings in the base,
that a carpet must not obstruct the openings.
The symbol on the product, or on the documents accompanying the product,
indicates that this appliance may not be treated as household waste. Instead it
shall be handed over to the applicable collection point for there cyclingof electrical
and electronic equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed information about
treatment, recovery and recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased
the product.
that
1
5
6
7
3
7
1
4
2
4
2
9 10
unds
Remove siphon in softener slot. (fig.“C”).
Refit the siphon in the detergent drawer and fit the drawer back inside its housing.
Press the release lever in the main wash compartment downward and remove
the drawer(fig.“B”).
BC
Select the “Rinse+Spin” programme,reduce the speed to 1000rpm and strat
2 Insert removal tool like slotted screwdriver into the small opening of bottom
baffle, press the bottom baffle downward with much strength and open it.
1
Before emptying the residual water, switch the appliance off and unplug it
fromthe mains socket. Remove the plinth,place a container beneath it.
DRAINING RESIDUAL WATER
(depends on model)
1 Pull out emergency drain pipe of machine.
2 Put end of emergency drain pipe into a container.
3 Rotate emergency drain pipe plug and remove it after it becomes loose.
4 Until water runs off naturally.
5 Reinstall emergency drain pipe plug.
6 Fill detergent box with 1L water to check
emergency drain pipe.Check if there is
any leakage at connection of pipe plug.
7 Put emergency drain pipe back.
if it fails to perform spin cycles.
Ensure that the water has
We recommend that you check and clean the filter regularly, at least two or three
times a year.
