Hisense LCT33D6ABE Manual de usuario
Owner’ s manual
Compact Double Door Refrigerator
Model: LCT33D6ABE
LCT33D6ASE
LCT33T6AVE
© 2015 Hisense Company Ltd. All Rights Reserved.
All material in this Owner's Manual is the property of Hisense
Company Ltd. and its subsidiaries, and is protected under US and
in any manner, electronic, print, or otherwise, without the prior
or distributed, in whole or in part, in any manner, electronic or
Requests for permission to store, reproduce, transmit or distribute
materials may be made to the following address:
PO Box 3289
Suwanee, GA 30024
Hisense, and any and all other Hisense product names, logos, slogans
or marks are registered trademarks of Hisense Company Ltd. and its
holders.
COPYRIGHT STATEMENT
appliance, unless they are of the type recommended by the manufacturer.
21. WARNING: Do not use electrical appliances inside the food storage compartments of the
20. WARNING: Do not damage the refrigerant circuit.
clear of obstruction.
19. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure,
1
This appliance is not intended for use by persons (including children) with
reduced physical,sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure their do not play with the appliance
pertaining to the installation, handing, servicing
For compression-type appliances which use flammable refrigerants, instructions
shall include information
4
6
22
2
22. WARNING: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
Appliances which use flammable insulation blowing gases instructions shall include
information regarding disposal of the appliance
Instructions shall contain the substance of the following;
Do not use extension cords or ungrounded (two prong) adapters
This product should not be disposed with other household wastes.
To prevent possible harm to the environment or human health from uncontrolled waste
disposal recycles it responsibly to promote the sustainable reuse of material resources.
To return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmental safe recycling
WARNING! Refrigerators contain refrigerant and gases in the insulation.
Refrigerant and gases must be disposed of professionally as they may cause eye
injuries or ignition Ensure that tubing of the refrigerant circuit is not
damage prior to proper disposal.
Do not use extension cords or ungrounded(two
prong) adapters.
3
4
5
6
7
The side at which the door opens can be
changed from the right side (as supplied) to
the left side, if the installation site requires.
Tools you will need:
.8mm socket driver(1PCS)
.
Note: Before this step, you should lay the refrigerator
on it’s back in order to gain access to the base, you
should rest it on soft foam packaging or similar
material to avoid damaging the cooling pipes at the
rear of the refrigerator.
.
2. open the screw hole cove and the upper
hinge cover which is at the top right corner of
the refrigerator. upper hinge
cover (right)
1. Stand the refrigerator, open the upper
door and remove the things in the door and
close it.
3.Unscrew the special flange self-tapping
screws which are used for fixing the right
upper hinge part by a 8mm socket driver
or a spanner(please support the upper
door with your hand when doing it ).
right upper hinge part
special flange
selftapping screws
5.Remove upper door and place it on
smooth surface with panel upwards.
6. Loose screws used to fix middle hinge
and remove middle hinge. Then turn middle
hinge by 180. Take washer on axis and put
it on another end. Place it well for use.
7. Remove lower door and place panel
upwards on smooth surface.
8. Change screw hole covers on middle
cover plate from left to right (as shown in
figure below).
Front foot fixed board
Self tapping screws
Adjustable bottom feet part
Lower hinge part right
4.Remove the right upper hinge part and
, thescrew hole cover place them on
smooth surface.
screw hole cover
.7mm wrench(1PCS)
Caution
To avoid to injury yourself and/or property,
we recommend someone assist you during
the door reversal process.
.Ensure the Appliance is unplugged and
empty.
.Following
steps
are
generally
recommended
Changing the door from the right side to the left.
8
phillips screwdrivers(1PCS)
Putty Knife(1PCS) or slotted srewdrivers(1PCS)
Parts you will need ,parts are from the package of manual
door stopper(1PCS) door stop(1PCS)
