Hisense HR6BF47 Instrucciones de montaje

Contents

Important Safety Instruction ------------------------------------------------------------------3

Remove transport packaging------------------------------------------------------------------6

Installation --------------------------------------------------------------------------------------- 6

Positioning ----------------------------------------------------------------------------------------6

Description of the appliance ---------------------------------------------------------------- 7

Reversing the door-----------------------------------------------------------------------------8

Starting up and temperature regulation----------------------------------------------------9

Interior Accessories----------------------------------------------------------------------------10

Defrosting---------------------------------------------------------------------------------------11

Cleaning and Care ----------------------------------------------------------------------------12

Energy Saving Tips-----------------------------------------------------------------------------13

Troubleshooting------------------------------------------------------------------------------- -13

Disposal of the appliance---------------------------------------------------------------------15

Important safety instructions

These warnings are provided in the interests of your safety. Ensure you fully

understand them before installing or using the appliance.

Your safety is paramount importance. If you are unsure about the meaning of these

warnings contact the Customer Care Department for assistance.

Intended use

The refrigerator is intended for use in the home. It is suitable for the storage of food

at low temperature. If the appliance is used for purposes other than those intended

or used incorrectly, no liability can be accepted by the manufacturer for any damage

that may be caused.

Alterations or changes to the refrigerator are not permitted for reasons of safety.

If you use the refrigerator in a commercial application or for purposes other than the

cooling of foods, the manufacturer accepts no liability for any damages that may

occur.

Prior to initial start-up

Check the appliance for transport damage. Under no circumstances should a

damaged appliance be plugged in. In the event of damage, please contact your

supplier.

Refrigerant

The refrigerant isobutene (R600a) is contained within the refrigerant circuit of the

appliance, a natural gas with a high level of environmental compatibility, which is

nevertheless flammable. During transportation and installation of the appliance,

ensure that none of the components of the refrigerant circuit becomes damaged.

The refrigerant (R600a) is flammable.

Caution: risk of fire

If the refrigerant circuit should become damaged:

zAvoid open flames and sources of ignition.

zThoroughly ventilate the room in which the appliance is situated.

The instructions shall include the warnings:

WARNING!—Keep ventilation openings, in the appliance enclosure or in the built-in

structure, clear of obstruction.

WARNING!—Do not use mechanical devices or other means to accelerate the

defrosting process, other than those recommended by the manufacturer.

WARNING!—Do not damage the refrigerant circuit.

WARNING!—Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type recommended by the

manufacturer.

WARNING!—This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning use

of the appliance by a person responsible for their safety

WARNING!—Young children should be supervised to ensure that they do not play

with the appliance

WARNING!—The cord should be neither lengthened nor folded into coil during

operation. Moreover, it is forbidden that cord is kept close onto the compressor at

the back of the refrigerator, the surface temperature of which is quite high when

operating. Touching with it would deactivate the insulation or cause leakage for

electricity. Extension cord is not recommended to use. If the supply cord is damaged,

it must be replaced by the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

WARNING!—When disposing of the appliance, do so only at an authorized waste

disposal centre. Do not expose to flame.

WARNING!—Please keep the appliance away from substance, which can cause

ignition.

WARNING!—Before obtaining access to terminals, all supply circuits must be

disconnected.

WARNING!—Please remove the door before you dispose your refrigerator.

WARNING!—The fridge is only applied with power supply of single phase

alternating current of 220~240V/50Hz. If fluctuation of voltage in the district of

user is so large that the voltage exceeds the above scope, for safety sake, be sure

to apply A.C. Automatic voltage regulator to the fridge. The fridge must employ a

special power socket instead of common one with other electric appliances. Its plug

must match the socket with ground wire.

WARNING!— Do not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

WARNING!— This appliance is intended to be used in household and similar

applications such as

-staff kitchen areas in shops, offices and other working environments;

-farm houses and by clients in hotels, motels and other residential type

environments;

-bed and breakfast type environments;

-catering and similar non-retail applications.

WARNING!— Keep burning candles,lamps and other items with naked flames away

from the appliance so that do not set the appliance on fire.

Safety of children

Packaging (e.g. wraps, polystyrene) can be dangerous for children.

There is a risk of suffocation! Keep packaging material away from children!

Make old appliances unusable prior to disposal. Pull out the mains plug, cut off the

mains cable, break or remove spring or bolt catches, if fitted. By doing this you

ensure that children cannot lock themselves in the appliance when playing (there is

risk of suffocation!) or get themselves into other dangerous situations.

Often children cannot recognize the hazards present in household appliances. It is

therefore important that you ensure adequate supervision and never let children

play with the appliance!

Daily Operation

Containers with flammable gases or liquids can leak at low temperatures. There is a

risk of an explosion! Do not store any containers with flammable materials such as

spray cans, fire extinguisher refill cartridges etc in the refrigerator and/or freezer.

Do not operate any electrical appliances in the refrigerator and/or freezer (e.g.

electric ice cream makers, mixers etc.).

Before cleaning the appliance, always switch off the appliance and unplug it, or pull

the house fuse or switch off the circuit breaker.

When unplugging always pull the plug from the mains socket, do not pull on the

cable.

In case of malfunction

If a malfunction occurs on the appliance, please look first in the “Troubleshooting”

section of these instructions. If the information given there does not help, please do

not perform any further repairs yourself.

Under no circumstance should you attempt to repair the appliance yourself. Repairs

carried out by inexperienced persons may cause injury or serious malfunctioning.

Contact your local Service Force Center.

Remove transport packaging

The appliance and the interior fittings are protected for transportation. Pull off the

adhesive tape on the left and right side of the door. You can remove any remnants of

adhesive using white spirit. Remove all adhesive tape and packing pieces from the

interior of the appliance.

Installation

Installation Location

Before installing, carefully read the instruction in order to avoid a certain number of

problems.

Positioning

Position the appliance away from sources of heat such as stoves, radiators, direct

sunlight etc. Maximum performance and safety are guaranteed by maintaining the

correct indoor temperature for the class of unit concerned, as specified on the

rating plate. This application perform well from N to ST. The Appliance may not

work properly if it is left for a longer period at a temperature above or below the

indicated range.

IMPORTANT!—There is a need of good ventilation around the fridge for easy

dissipation of heat, high efficiency of refrigeration and low power consumption. For

this purpose, sufficient clear space should be available around the fridge. It is

advisable for there to be 75mm separating the back of the fridge to the wall, at

least 100mm of space at its two sides, height of over 100mm from its top and a

clear space upfront to allow the doors to open 160°.

Climate classification Ambient temperature

SN 10~32°C

N 16~32°C

ST 16~38°C

T 16~43°C

Appliances must not be exposed to rain. Sufficient air must be allowed to circulate

in the lower rear section of appliances, as poor air circulation can affect

performance. Built-in appliances should be positioned away from heat sources such

as heaters and direct sunlight.

Description of the appliance

1. Ice Cube Tray

2. Temperature Control Knob

3. Drip Tray

4. Removable Shelf

5. Freezer Compartment

6. Dairy Rack

7. Bottle Rack

8. Adjustable Leg

Reversing the door

The side at which the door opens can be changed from the right side (as supplied)

to the left side, if the installation site requires.

Tools you will need

1、8mm socket driver 2、cross-shaped screwdriver

3、Putty knife or thin-blade screwdriver

①

⑨

⑧

⑦

⑥

⑤

④

③

②

1. Remove the upper hinge cap (1).

2. Using a sharp object, pry out the plug buttons(5).

3. Remove the two Phillips screws(2) that connect the upper hinge(3) on the right

side of the cabinet top.

4. Carefully lift the door and place it on a padded surface to prevent it from
