HIK VISION TURBO HD DS-2CE56D8T-(A)VPIT3Z(E) Manual de usuario

TURBO HD

D8T Series Dome Camera

User Manual

UD05334B

User Manual

Thank you for purchasing our product. If there are any

questions, or requests, do not hesitate to contact the

dealer.

This manual applies to the models below:

Type

Model

Type I Camera

DS-2CE56D8T-(A)VPIT3Z(E)

Type II

Camera

DS-2CE56D8T-(A)ITZ(E)

Type III

Camera

DS-2CE56D8T-VPIT(E)

This manual may contain technical incorrect places or

printing errors, and the content is subject to change

without notice. The updates will be added to the new

version of this manual. We will readily improve or

update the products or procedures described in the

manual.

0100001070415

Regulatory Information

FCC Information

Please take attention that changes or modification not

expressly approved by the party responsible for

compliance could void the user’s authority to operate

the equipment.

FCC compliance: This equipment has been tested and

found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection

against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in

which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,

including interference that may cause undesired

operation.

EU Conformity Statement

This product and - if applicable - the

supplied accessories too are marked with

"CE" and comply therefore with the

applicable harmonized European

standards listed under the Low Voltage Directive

2014/35/EU, the EMC Directive 2014/30/EU.

2012/19/EU (WEEE directive): Products

marked with this symbol cannot be

disposed of as unsorted municipal waste in

the European Union. For proper recycling,

return this product to your local supplier

upon the purchase of equivalent new

equipment, or dispose of it at designated collection

points. For more information see: www.recyclethis.info.

2006/66/EC (battery directive): This product contains a

battery that cannot be disposed of as

unsorted municipal waste in the European

Union. See the product documentation for

specific battery information. The battery is

marked with this symbol, which may

include lettering to indicate cadmium (Cd), lead (Pb), or

mercury (Hg). For proper recycling, return the battery

to your supplier or to a designated collection point. For

more information see: www.recyclethis.info.

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A)

standards requirements.

Safety Instruction

These instructions are intended to ensure that user can

use the product correctly to avoid danger or property

loss.

The precaution measure is divided into “Warnings” and

“Cautions”.

Warnings: Serious injury or death may occur if any of

the warnings are neglected.

Cautions: Injury or equipment damage may occur if any

of the cautions are neglected.

Warnings

In the use of the device, you must be in strict

compliance with the electrical safety regulations of

the nation and region.

Input voltage should meet both the SELV (Safety Extra

Low Voltage) and the Limited Power Source with 12

VDC according to the IEC60950-1 standard. Refer to

technical specifications for detailed information.

Do not connect multiple devices to one power

adapter to avoid over-heating or a fire hazard caused

by overload.

Make sure that the plug is firmly connected to the

power socket.

Make sure that the device is firmly fixed if wall

mounting or ceiling mounting is adopted.

If smoke, odor or noise rise from the device, turn off

the power at once and unplug the power cord, and

then contact the service center.

Never attempt to disassemble the camera by

unprofessional personal.

Cautions

Do not drop the camera or subject it to physical

shock.

Do not touch senor modules with fingers.

If cleaning is necessary, use clean cloth with a bit of

ethanol and wipe it gently.

Do not aim the camera at the sun or extra bright

places.

The sensor may be burned out by a laser beam, so

when any laser equipment is in using, make sure that

the surface of sensor will not be exposed to the laser

beam.

Do not expose the device to high electromagnetic

radiation or extremely hot, cold, dusty or damp

environment.

To avoid heat accumulation, good ventilation is

required for the operating environment.

Keep the camera away from liquid while in use for

non-water-proof device.

While in delivery, the camera shall be packed in its

original packing, or packing of the same texture..

Warnings Follow

these safeguards to

prevent serious injury

or death.

Cautions Follow these

precautions to prevent

potential injury or

material damage.

1Introduction

1.1 Product Features

The camera is applicable for both indoor and outdoor

conditions, and the application scenarios include road,

warehouse, underground parking lot, bar, etc.

The main features are as follows:

High performance CMOS sensor

Low illumination, 0.005 Lux @ (F 1.8, AGC ON), 0 Lux

with IR

IR cut filter with auto switch

OSD menu with configurable parameters

Auto white balance

internal synchronization

SMART IR mode

PoC (with-E)

3-axis adjustment

Note:

Type II camera is applicable to indoor conditions only.

1.2 Overview

Before you start:

The cables of device vary according to different models.

The cables of each type are shown in the figures below,

refer to the actual sample.

You can debug the camera by connecting an auxiliary

HD TVI cable to the auxiliary video output.

1.2.1 Overview of Type I Camera

Bubble

Auxiliary

Video Output

Lens

Back Box

Menu Button

Video Cable

Power Cord

24 VAC/12 VDC

Cables

Video Cable

Power Cord

12 VDC

Model I Cables

Model II Cables

Figure 1-1 Overview of Type I Camera

1.2.2 Overview of Type II Camera

Bubble

Auxiliary

Video Output

Lens

Back Box

Menu Button

Video Cable

Power Cord

24 VAC/12 VDC

Cables

Video Cable

Power Cord 12 VDC

Model I Cables

Model II Cables

Base Plate

Figure 1-2 Overview of Type II Camera

1.2.3 Overview of Type III Camera

Mounting

Base

Tilt Adjusting

Screw

Bubble

Power Cord

12 VDC

Video Cable TVI

IR LED

Photoresistor

Black Liner

Safty Rope

Figure 1-3 Overview of Type III Camera

2Installation

Before you start:

Make sure that the device in the package is in good

condition and all the assembly parts are included.

Make sure that all the related equipment is

power-off during the installation.

Check the specification of the products for the

installation environment.

Check whether the power supply is matched with

your power output to avoid the damage.

Make sure the wall is strong enough to withstand

three times the weight of the camera and the

bracket.

If the wall is cement, insert expansion bolts before

installing the camera. If the wall is wooden, use

self-tapping screws to secure the camera.

If the product does not function properly, contact

your dealer or the nearest service center. Do NOT

disassemble the camera for repair or maintenance

by yourself.

2.1 Ceiling Mounting of Type I Camera and Type II

Camera

Before you start:

Both wall mounting and ceiling mounting are suitable

for the dome camera. Ceiling mounting will be taken as

an example in this section. And you can take steps of

ceiling mounting as a reference for wall mounting.

Steps:

1. Paste the drill template to the celling.

2. Drill screw holes and the cable hole (optional) on

the ceiling according to the supplied drill template.

Note:

Drill the cable hole when adopting the ceiling outlet

to route the cable.

Type I Camera

Type II Camera

Figure 2-1 The Drill Template

3. Loosen the screws on the bubble of the dome

camera to remove the bubble and the black liner.

4. Attach the back box of type I camera/base plate of

type II camera to the ceiling and secure them with

supplied screws.

Type I Camera

Type II Camera

Figure 2-2 Attach the Back Box/Base Plate

Note:

The supplied screw package contains self-tapping

screws, and expansion bolts.

For cement wall, expansion bolts are required to fix

the camera. For wooden wall, self-tapping screws

are required.

5. Route the cables through the cable hole, or the side

opening.

6. Align the camera with the back box/base plate, and

tighten the screws to secure the camera with the

back box/base plate.

Type I Camera

Type II Camera

Figure 2-3 Fix the camera to the Ceiling

7. Connect the corresponding cables, such as power

cord, and video cable.

8. Power on the camera to check whether the image

on the monitor is gotten from the optimum angle. If

not, adjust the camera according to the figure below

to get an optimum angle.

Type I Camera

0°to 355°

0°to 75°

0°to 355°

0°to 75°

Type II Camera

Figure 2-4 3-Axis Adjustment

9. Fit the black liner back to the camera and tighten

the screws on the bubble of the dome camera to

finish the installation.

2.2 Ceiling Mounting of Type III Camera

Steps:

1. Paste the dill template to the ceiling.

2. Drill the screw holes and cable hole (optional) in the

ceiling according to the drill template.

Note:

Cable hole is required, when adopting the ceiling

outlet to route cables.

Drill Template

Hole A: for cables routed through the ceiling

screw hole 1: for Mounting Base

Figure 2-5 Drill Template

3. Loosen the set screws with a hex wrench (supplied)

to remove the bubble.

Figure 2-6 Remove the Bubble

4. Fix the mounting base on the ceiling with supplied

screws.

Figure 2-7 Fix the Mounting Base

5. Route the cables through the cable hole, or the side

opening.

6. Connect the corresponding cables, such as power

cord, and network cable.

7. Power on the camera to check whether the image

on the monitor is gotten from the optimum angle. If

not, adjust the camera according to the figure below

to get an optimum angle

Adjusting Screw

0° to 355°

0° to 75° 0° to 355°

Figure 2-8 Type I Camera 2-Axis Adjustment

1) Loosen the tilt adjusting screw to adjust the tilt

position [0°to 75°].

2) Hold the black liner to adjust the pan position [0°

to 355°].

3) Hold the camera body to adjust the rotation

position [0°to 355°]

8. Reinstall the bubble, and tighten the screws.

Figure 2-9 Bubble Reinstallation

2.3 Wall Mounting of Type I Camera and Type II

Camera

Before you start:

You need to purchase a wall mounting bracket

separately.

Steps:

1. Drill four screw holes in the wall according to the

holes of the bracket.

2. Attach the bracket to the wall by aligning the four

screw holes of the bracket with expansion screws on

the wall.

3. Secure the bracket with four hex nuts and washers.

Type I Camera

Type II Camera

Figure 2-10 Install Wall Mounting Bracket

4. Refer to step 3 of 2.1 Ceiling Mounting of Type I

Camera and Type II Camera to remove dome

camera’s bubble and the black liner.

5. Attach the back box/base plate of the dome camera

to the wall mounting bracket, and secure them with

supplied screws.

Type I Camera

Type II Camera

Figure 2-11 Attach the Back Box/Base Plate to the

Bracket

6. Route the cables through the bracket.

7. Repeat steps 6 to 9 of the 2.1 Ceiling Mounting of

Type I Camera and Type II Camera to complete the

installation.

2.4 In-Ceiling Mounting

Befor you start:

You need to purchase an in-ceiling mounting bracket

separately.

Steps:

1. Attach the in-ceiling mounting bracket on the wall

and mark the screw holes, and cable holes on the

wall.

2. Drill the screw holes and the cable hole.

3. Screw the bolts through the in-ceiling mounting

bracket by aligning with the two screw holes, and fit

the toggles onto the bolts.

4. Push the two bolts in the ceiling, and rotate the bolt

till the toggle holds the ceiling tightly.

Figure 2-12 Install the In-Ceiling Mounting Bracket

5. Route the cables through the cable hole.

6. Fix the camera to the in-ceiling mounting bracket

with the supplied screws.

Type I Camera

Type II Camera

Figure 2-13 Fix the Camera to the Mount

7. Connect the corresponding cables, such as power

cord, and video cable.

8. Repeat steps 8 to 9 of the 2.1 Ceiling Mounting of

Type I Camera and Type II Camera to complete the

installation.

2.5 Mounting with Inclined Base of Type I Camera

Steps:

1. Attach inclined base on the wall and mark the screw

holes, and cable holes on the wall.

2. Drill the screw holes and the cable hole.

3. Install the inclined base to the ceiling with supplied

screws, as shown in Figure 2-9.

Figure 2-14 Fix the Inclined Base

4. Route the cables through the cable hole, or the side

opening of the inclined base.

5. Fix the camera to the inclined base with the

supplied screws.

Figure 2-15 Fix the Camera to the Base

6. Repeat the steps 7 to 9 of the 2.1 Ceiling Mounting

of Type I Camera and Type II Camera section to

complete the installation.

3Menu Description

Purpose:

Call the menu by clicking button on the PTZ interface,

or call preset No.95.

Steps:

1. Connect the camera with the TVI DVR, and the

monitor shown as the Figure 3-1.

Camera

TVI DVR

Monitor

Figure 3-1 Connection

2. Power on the analog camera, TVI DVR, and the

monitor to view the image on the monitor.

3. Click PTZ Control to enter the PTZ Control interface.

4. Call the camera menu by clicking button, or call

preset No. 95.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de HIK VISION

HIK VISION

HIK VISION E-series Manual de usuario

HIK VISION

HIK VISION DS-2CD2012-I Manual de usuario

HIK VISION

HIK VISION DS-2DE2A204IW-DE3(C0)(S6) Manual de usuario

HIK VISION

HIK VISION UD04357B Manual de usuario

HIK VISION

HIK VISION DS-2CE12D0T-PIRXF Manual de usuario

HIK VISION

HIK VISION DS-2CC502P-DG1 Manual de usuario

HIK VISION

HIK VISION iDS-2CD70C5G0/H-AP Manual de usuario

HIK VISION

HIK VISION DS-2CC102PN-IRA Manual de usuario

HIK VISION

HIK VISION DS-2TD2528T-10/Q Manual de usuario

HIK VISION

HIK VISION DS-2CD2722FWD-IS Manual de usuario

HIK VISION

HIK VISION DS-2CE56D8T-IT1 Manual de usuario

HIK VISION

HIK VISION P07Z35LW4T30 Manual de usuario

HIK VISION

HIK VISION DS-2DE2C200SCG-E Manual de usuario

HIK VISION

HIK VISION CT-AC303-MB-3-6mm Manual de usuario

HIK VISION

HIK VISION DS-2DE7A232IW-AEB Manual de usuario

HIK VISION

HIK VISION DS?2CD753F?E Manual de usuario

HIK VISION

HIK VISION TURBO HD H8T Series Manual de usuario

HIK VISION

HIK VISION DS-2CV2046G0-IDW Manual de usuario

HIK VISION

HIK VISION DS-2CE12DFT-PIRXOF28 Manual de usuario

HIK VISION

HIK VISION DS-2DF7C445IXR-AEL(T5) Manual de usuario

HIK VISION

HIK VISION DS-2CC5192P(N) Manual de usuario

HIK VISION

HIK VISION DS-2XC6142FWD-IS Manual de usuario

HIK VISION

HIK VISION DS-2DF1-401E Manual de usuario

HIK VISION

HIK VISION DS-2DF6A436X-AEL Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
