HIK VISION DS?2CD763PF?E Manual de usuario

NetworkDomeCamera

InstallationManual

V3.0.0

HangzhouHikvisionDigitalTechnologyCo.,Ltd.

http://www.hikvision.com

2010‐04



Thankyouforpurchasingourproduct.Ifthereareanyquestions,orrequests,please

donothesitatetocontactthedealer.

ThismanualappliestoDS‐2CD763PF(NF)‐E(I),DS‐2CD753F‐E(I),

DS‐2CD793PF(NF)‐E(I),DS‐2CD793PFWD(NFWD)‐E(I)andDS‐2CD733F‐E(I)Network

Camera.

Thismanualmaycontainseveraltechnicalincorrectplacesorprintingerrors,andthe

contentissubjecttochangewithoutnotice.Theupdateswillbeaddedtothenew

versionofthismanual.Wewillreadilyimproveorupdatetheproductsorprocedures

describedinthemanual.

DISCLAIMERSTATEMENT

“UnderwritersLaboratoriesInc.(“UL”)hasnottestedtheperformanceorreliabilityof

thesecurityorsignalingaspectsofthisproduct.ULhasonlytestedforfire,shockor

casualtyhazardsasoutlinedinUL’sStandard(s)forSafety,UL60950‐1.UL

Certificationdoesnotcovertheperformanceorreliabilityofthesecurityorsignaling

aspectsofthisproduct.ULMAKESNOREPRESENTATIONS,WARRANTIESOR

CERTIFICATIONSWHATSOEVERREGARDINGTHEPERFORMANCEORRELIABILITYOF

ANYSECURITYORSIGNALINGRELATEDFUNCTIONSOFTHISPRODUCT.”

InstallationManualofNetworkDomeCamera

SafetyInstruction

Theseinstructionsareintendedtoensurethattheusercanusetheproductcorrectlytoavoid

dangerorpropertyloss.

Theprecautionmeasureisdividedinto‘Warnings’and‘Cautions’:

Warnings:Seriousinjuryordeathmaybecausedifanyofthesewarningsareneglected.

Cautions:Injuryorequipmentdamagemaybecausedifanyofthesecautionsareneglected.

 

WarningsFollowthesesafeguardsto

preventseriousinjuryordeath.

CautionsFollowtheseprecautionsto

preventpotentialinjuryormaterial

damage.

Warnings:

1. Intheuseoftheproduct,youmuststrictlycomplywiththeelectricalsafetyregulationsofthe

nationandregion.

2. SourcewithDC12VorAC24VaccordingtotheIEC60950‐1standard.Pleaserefertotechnical

specificationsformoredetails.

3. Donotconnectseveraldevicestoonepoweradapterasanadapteroverloadmaycause

over‐heatingandcanbeafirehazard.IfusethePOEasthepowersupply,pleasemakesurethat

thePOESwitchhavethesufficientpower.

4. Pleasemakesurethattheplugisfirmlyinsertedintothepowersocket.

5. Whentheproductisinstalledonawallorceiling,thedeviceshouldbefirmlyfixed.

6. Ifsmoke,odor,ornoiserisefromthedevice,turnoffthepoweratonceandunplugthepower

cable,thencontacttheservicecenter.

7. Iftheproductdoesnotworkproperly,pleasecontactyourdealerorthenearestservicecenter.

Neverattempttodisassemblethecamerayourself.(Weshallnotassumeanyresponsibilityfor

problemscausedbyunauthorizedrepairormaintenance.)

InstallationManualofNetworkDomeCamera

Notice:

1. Makesurethepowersupplyvoltageiscorrectbeforeusingthecamera.

2. Donotdropthecameraorsubjectittophysicalshock.

3. Donottouchsensormoduleswithfingers.Ifcleaningisnecessary,useacleanclothwithabit

ofethanolandwipeitgently.Ifthecamerawillnotbeusedforanextendedperiodoftime,put

onthelenscaptoprotectthesensorfromdirt.

4. Donotaimthecameraatthesunorextrabrightplaces.Abloomingorsmearmayoccur

otherwise(whichisnotamalfunctionhowever),andaffectingtheenduranceofsensoratthe

sametime.

5. Thesensormaybeburnedoutbyalaserbeam,sowhenanylaserequipmentisbeingused,

makesurethatthesurfaceofthesensorwillnotbeexposedtothelaserbeam.

6. Donotplacethecamerainextremelyhotorcoldtemperatures(theoperatingtemperature

shouldbebetween‐10°C~+60°C,dustyordamplocations,anddonotexposeittohigh

electromagneticradiation.

7. Toavoidheataccumulation,goodventilationisrequiredforaproperoperatingenvironment.

8. Whileshipping,thecamerashouldbepackedinitsoriginalpacking,orpackingofthesame

texture.

9. Regularpartreplacement:afewparts(e.g.electrolyticcapacitor)oftheequipmentshouldbe

replacedregularlyaccordingtotheiraveragelifetime.Theaveragetimevariesbecauseof

differencesbetweenoperatingenvironmentandusagehistory,soregularcheckingis

recommendedforallusers.Pleasecontactwithyourdealerformoredetails.

InstallationManualofNetworkDomeCamera

Index

Chapter1Introduction.................................................................................................. 1

1.1NetworkcameraFunctionsandFeatures.......................................................... 1

1.2Applications....................................................................................................... 1

Chapter2Installation.................................................................................................... 3

2.1CameraDescriptionandConnection................................................................. 3

2.2HardwareInstallation ........................................................................................ 5

AppendixProductSpecification ................................................................................. 7

DS‐2CD763PF(NF)‐E(I) ............................................................................................. 7

Specification ...................................................................................................... 7

Dimensions........................................................................................................ 8

DS‐2CD753F‐E(I) ...................................................................................................... 9

Specification ...................................................................................................... 9

Dimensions...................................................................................................... 10

DS‐2CD793PF(NF)‐E(I) ........................................................................................... 11

Specification .................................................................................................... 11

Dimensions...................................................................................................... 12

DS‐2CD793PFWD(NFWD)‐E(I) ............................................................................... 13

Specification .................................................................................................... 13

Dimensions...................................................................................................... 14

DS‐2CD733F‐E(I).................................................................................................... 15

Specification .................................................................................................... 15

InstallationManualofNetworkDomeCamera

Dimensions...................................................................................................... 16

InstallationManualofNetworkDomeCamera

Chapter1Introduction

Networkcameraisakindofembeddeddigitalsurveillanceproductthatcombinesthefeatures

ofbothtraditionalanalogcameraandnetDVS(DigitalVideoServer).DuetotheembeddedLinux

operationsystemandthelatestDavincihardwareplatformofTI,thesystemoperateswithhigh

schedulingefficiency.Furthermore,thefirmwareisburnedintheflash,whichmakestheproduct

small,reliableandhighlystable.

1.1NetworkcameraFunctionsandFeatures

Functions:

NetworkFunction:SupporttheTCP/IPprotocolsandIEbrowsing.

HeartbeatFunction:Theservercanacquirerealtimeoperatingperformanceofthenetwork

camerathroughtheheartbeatfunction.

AlarmFunction:Theproductincludes2channelofalarmsignalinputand2channelofalarm

on/offoutput,andsupportsmotiondetection,videoloss,NetworkBroken,IPaddressconflict,

Storageexception.

VoiceTalking:Supportbidirectionalvoicetalking.

UserManagement:Supportmultilevelrightmanagement.Theadministratorcancreateupto

15separateuserswithdifferentrightlevels,whichhighlyimprovesthesystemsecurity.

CompressionFunctions:

Support1channelvideosignalandstandardH.264encodingcompression,whichsupportsboth

variablebitrateandvariableframerate;besides,youcanself‐defineboththevideoqualityand

itscompressedbitrate.

RemoteControl:

Theproductoffersa10M/100Mself‐adaptiveEthernetinterface.

SupportTCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,SMTP,NTPprotocols.

Settheparameters,browserealtimevideosorcheckthecameraperformancethrough

softwareorIE,andstorethecompressedbitratethroughnetwork.

Supportremoteupgradesandmaintenance.

1.2Applications

Thiscameraisidealforremotecontrolnetworkapplications.E.g.:

1. Networksurveillanceforbankcounters,supermarketsandfactories.

2. Remotesurveillancefornursinghomes,kindergartensandschools.

3. AIjanitors.

InstallationManualofNetworkDomeCamera

4. AIbuilding/districtmanagementsystems.

5. Self‐servicesystemsofpowerplants.

6. Pipeliningandwarehousemonitoring.

7. Surveillanceforairdrome,railwaystation,busstopetc.

InstallationManualofNetworkDomeCamera

Chapter2Installation

NOTE:

1. Pleasecheckifalltheitemsonthepackagelisthavebeenincludedwithyourcamera.

2. Readthefollowingcontentscarefullybeforetheinstallation.

3. Makesurethatalltherelatedequipmentispower‐offduringtheinstallation.

4. Checkthepowersupplytopreventanydamagecausedbymismatchingproblems.

5. Iftheproductdoesnotoperateproperly,pleasecontactyourdealerorthenearestservice

center.Neverattempttodisassemblethecamerayourself.Usersareresponsibleforany

problemcausedbymodificationorrepairingwithoutauthorization.

2.1CameraDescriptionandConnection

Cameradescription:

CameraConnection:



InstallationManualofNetworkDomeCamera

SerialNO.Description

1LAN(PoE):10M/100Mself‐adaptiveEthernetinterface

2INITIALSET:Resetallparameterstofactorydefaultsettings.

3AUDIOOUT:Audiooutputinterface

4MICIN:Audioinputinterface

5D+,D‐:RS‐485interface

61A1B,2A2B:Alarmoutputinterface

7IN1GND,IN2GND:Alarminputinterface

8Powersupply

9SDcardslot

10Videooutputinterface

11PowerLEDindicator,whichturnsredwhenpowerisappliedtotheunit

NOTE:

Whenthecameraispowerup,pressthe“INITIALSET”buttonforabout10seconds,thenall

parameters,includingusername,password,IPaddress,portnumber,etc.,willberesettothe

factorydefaultsettings.



ThealarminputisaNO/NCrelay.IftheinputisnotaNO/NCrelay,followtheconnection

diagrambelow:

ToconnecttoanAC/DCload,usethefollowingdiagram:

Thealarmoutputisanon/offoutputthatrequiresexternalpowersupplyonconnection.The

externalpowersupplyshallbe12VDC/30mA,oruseACwithexternalrelays.Equipmentdamageor
