HIK VISION DS2CD726F-PT(W) Manual de usuario
Hikvision Technical Manual
Network Camera
Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
1
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2010 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
Find out more about HIKVISION at www.hikvision.com
Hikvision Technical Manual
DS‐2CD726F‐PT(W)DS‐2CD727/728PF‐PT(W)
Cost‐effectivenetworkCamera
DS‐2CD726F‐PT(W)DS‐2CD727/728PF‐PT(W)
KeyFeatures
200Presets
20°/sPanandTiltPresetSpeed
0.3‐20°/sPanandTiltManualSpeed
EmbeddedLinuxOS
H.264videocompression
1channelAudioCompression
Support4CIF/DCIF/2CIF/CIF/QCIFRealTimeCompression
SupportSDCardforLocalRecording
SupportDualStreamCompression
SupportMotionDetection,andNotificationonPCClient
SupportbothVariableBitRateandVariableFrameRate
SupportTCP/IP,HTTP,DHCP,DNS,RTP/RTCP,PPPoE,etc.
SupportIEforNetworkPreview
SupportSensorAlarmInputandRelayOutput
SupportNetworkVoiceTalkFunction
CompatiblewithCurrentHIKVISIONDVR/DVSSDKandClientSoftware
©2006 – 2010 by HIKVISION. All rights reserved.
3
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
4
Specification
DS‐2CD726F‐PT(W)DS‐2CD727PF‐PT(W)DS‐2CD728PF‐PT(W)
Model
Parameter
4CIF1/4 " CMOS
IRCost‐effectiveDay&Night
networkCamera
4CIF1/3 " CCD
IRCost‐effectiveDay&Night
networkCamera
4CIF1/3 " CCD
IRCost‐effectiveDay&Night
networkCamera
Camera
ImageSensor1/4 " CMOS1/3"SONYCCD
SignalSystem ‐‐ PAL
Min.Illumination0.4Lux@(F1.2,AGCON)0.1Lux@(F1.2,AGCON),0LuxwithIR
LensmountM12
LensAngleofview:70.6°
Day&NightElectronic
InfraredFunction ‐‐ Support
Compressionstandard
Video
CompressionH.264
VideoOutput32K‐8M
Audio
CompressionOggVorbis
MaxImage
Resolution704×576,640×480,528×384,704×288,352×288,176×144
FrameRate25fps(704×576)
ImageSettings Saturation,Brightness,Contrast,Hueadjustablethroughclientsoftwareorwebbrowser
Network
ProtocolsTCP/IP,HTTP,DHCP,DNS,RTP/RTCP,PPPoE(FTP,SMTP,NTP,SNMPaddible)
SecurityPasswordProtection
PrivacyProtectionPreventPreviewingthroughNetwork,justPreviewontheMonitor.
ScanModeCamerascontrolledbytheclientsoftwareorremotecontrolcanscan≤170°range
PanandTilt
Range
Pan:0‐170°;
Tilt:0‐90°
HorizontalSpeed0.3‐20°/s(adjustable)
VerticalSpeed0.3‐20°/s(adjustable)
PanandTilt
PresetSpeed20°/s
RS‐485ProtocolsHIKVISION,PELCO‐P/D(addible)
NumberofPreset200
MenuLanguageChineseandEnglish,10characters
Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
5
MouseControl SupportMouseDragwhileselectHIKVISIONprotocolinClientSoftware
MotionDetectSupport
DualStream Support
SDCardLocal
RecordingSupport
HeartbeatSupport
Interface
VoiceInput2channels,1channel3.5mmaudiointerface(2.0‐2.4Vp‐p,1kΩ)andMICinternal
channel.
VoiceOutput1channel3.5mmaudiointerface(Linelevel,600Ω)
Communication1RJ4510M/100Mself‐adaptiveEthernetport,1RS‐485interface(802.11gWLAN
optional,IRRemoteroptional)
AlarmInput2channelssignalinput
AlarmOutput1channelrelayoutput
VideoOutputTestMonitorOUT1Vp‐pCompositeOutput(75Ω/BNC)
General
Operating
Conditions‐10℃‐60℃(14°F‐140°F),Humidity90%orless(non‐condensing)
PowerSupply12VDC,±10%
Power
Consumption9WMAX
Dimensionφ125×136.5mm()
Weight450g()
OrderModel
DS‐2CD726F‐PTDS‐2CD726F‐PTW
DS‐2CD727PF‐PTDS‐2CD727PF‐PTW
DS‐2CD728PF‐PTDS‐2CD728PF‐PTW
Hikvision Technical Manual
Dimension
©2006 – 2010 by HIKVISION. All rights reserved.
6
