HIK VISION DS-2CD7153-E Manual de usuario

Hikvision Technical Manual

Network Camera

Technical Manual

Hikvision Technical Manual

Notices

The information in this documentation is subject to change without notice and does not represent any

commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data

that may appear in this documentation. The product(s) described in this documentation are furnished

subject to a license and may only be used in accordance with the terms and conditions of such license.

This documentation is issued in strict confidence and is to be used only for the purposes for

which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or

be used for any other purpose without prior written consent of HIKVISION and then only on the

condition that this notice is included in any such reproduction. No information as to the contents or

subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,

shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party

being an individual, firm, or company or any employee thereof without the prior written consent of

HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use

this product. HIKVISION reserves the right to make changes to its products as circumstances may

warrant, without notice.

This documentation is provided “as-is,” without warranty of any kind.

Please send any comments regarding the documentation to:

overseabusiness@hikvision.com

Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual

DS-2CD7153-E

Key Features

Up to 2 megapixel (1600 × 1200) resolution

Standard video compression with high compression ratio

Progressive scan CMOS, capture motion video without incised margin

Support e-PTZ function

Support dual stream, and the sub-stream for mobile surveillance

PoE (Power over Ethernet)

3-axis (pan/tilt/rotation) positioning allows adjustment for optimum camera rotation and position

Ingress Protection level: IP66

Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up to IK10

Specification

Model

Parameter

DS-2CD7153-E

2 megapixel CMOS Weather-proof Vandal-proof Network Mini Dome

Camera

Image Sensor

1/3”Progressive Scan CMOS

Min.

Illumination

0.5 Lux @ (F1.2, AGC ON), 0.1 Lux @ (F1.2, AGC ON, sensitivity × 5)

1.1 Lux @ (F1.8, AGC ON), 0.2 Lux @ (F1.8, AGC ON, sensitivity × 5)

Shutter Speed

1/25 s to 1/100,000 s

Lens

4 mm @ F1.8 (2.8, 6, 8 mm optional)

Angle of view: 68°

Lens Mount

M12

Angle

Adjustment

Pan: ± 15°, Tilt: 0 - 90°, Rotation: ± 15°

Day & Night

Electronic

Compression Standard

Hikvision Technical Manual

Video

Compression

H.264/MPEG4/MJPEG

Video Bit Rate

32 Kbps –16 Mbps

Dual Stream

Yes


Max. Resolution

1600 x 1200

Frame Rate

50 Hz: 12.5 fps (1600 × 1200), 12.5 fps (1600 × 912), 25 fps (1280 × 960), 25

fps (1280 × 720)

60 Hz: 15 fps (1600 × 1200), 15 fps (1600 × 912), 25 fps (1280 × 960), 30 fps

(1280 × 720)

Image Setting

Saturation, Brightness, Contrast adjustable by client software or web

browser

Network

Network Storage

NAS (iSCSI optional)

Alarm Trigger

Motion detection, Tampering alarm

Protocols

TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP,UPnP,

ICMP,IGMP,SNMP, FTP, 802.1x, QoS, HTTPS ( SIP,SRTP,IPv6 optional )

Security

User Authentication, Watermark

Standard

ONVIF, PSIA, CGI

Interface

Communication

Interface

1 RJ45 10M/100M Ethernet port

Reset Button

Yes

General

Operating

Conditions

-25 °C –60 °C (-13 °F –140 °F)

Humidity 95% or less (non-condensing)

Power Supply

12 V DC ± 10%

PoE (802.3af)

Power

Consumption

Max. 4 W

Impact

Protection

IEC60068-275Eh, 50J; EN50102, up to IK10

Ingress

Protection level

IP66

Dimensions

99.9 × 97.5 × 46.5 mm (3.93” × 3.84” × 1.83”)

Weight

250 g (0.55 lbs)

Order Models

DS-2CD7153-E

Hikvision Technical Manual

Dimensions

Unit: mm
