Vehicle-Mounted Camera

User Manual

UD09114B-A

User Manual

AboutthisManual

This manual applies to Vehicle-Mounted Camera.

This Manual is subject to domestic and international

Technology Co., Ltd. (“Hikvision”) reserves all rights to

this manual. This manual cannot be reproduced, changed,

translated, or distributed, partially or wholly, by any

means, without the prior written permission of Hikvision.

Trademarks

and other Hikvision marks are the

property of Hikvision and are registered trademarks or

the subject of applications for the same by Hikvision

and/or its affiliates. Other trademarks mentioned in this

manual are the properties of their respective owners. No

right of license is given to use such trademarks without

express permission.

Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE

LAW, HIKVISION MAKES NO WARRANTIES, EXPRESS OR

IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE, REGARDING THIS MANUAL.

HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE

ANY REPRESENTATIONS REGARDING THE USE OF THE

MANUAL, OR THE CORRECTNESS, ACCURACY, OR

RELIABILITY OF INFORMATION CONTAINED HEREIN. YOUR

USE OF THIS MANUAL AND ANY RELIANCE ON THIS

MANUAL SHALL BE WHOLLY AT YOUR OWN RISK AND

RESPONSIBILITY.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE

LAW, IN NO EVENT WILL HIKVISION, ITS DIRECTORS,

OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU

FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR

INDIRECT DAMAGES, INCLUDING, AMONG OTHERS,

DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS

INTERRUPTION, SECURITY BREACHES, OR LOSS OF DATA

OR DOCUMENTATION, IN CONNECTION WITH THE USE OF

OR RELIANCE ON THIS MANUAL, EVEN IF HIKVISION HAS

BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR

LIMITATION OF LIABILITY OR CERTAIN DAMAGES, SO

SOME OR ALL OF THE ABOVE EXCLUSIONS OR

LIMITATIONS MAY NOT APPLY TO YOU.

RegulatoryInformation

FCCInformation

FCCcompliance:Thisequipment has been tested and

found to comply with the limits for a digital device,

pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference when the equipment is operated in

a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction

manual, may cause harmful interference to radio

communications. Operation of this equipment in a

residential area is likely to cause harmful interference in

which case the user will be required to correct the

interference at his own expense.

FCCConditions

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,

including interference that may cause undesired

operation

EUConformity Statement

This product and - if applicable - the

supplied accessories too are marked with

"CE" and comply therefore with the

applicable harmonized European standards listed under

the Low Voltage Directive 2014/35/EC, the EMC Directive

2014/30/EC.

2012/19/EU (WEEE directive): Products

marked with this symbol cannot be

disposed of as unsorted municipal waste in

the European Union. For proper recycling,

return this product to your local supplier

upon the purchase of equivalent new equipment, or

dispose of it at designated collection points. For more

information see: www.recyclethis.info.

2006/66/EC (battery directive): This

product contains a battery that cannot be

disposed of as unsorted municipal waste in

the European Union. See the product

documentation for specific battery information. The

battery is marked with this symbol, which may include

lettering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the battery to your

supplier or to a designated collection point. For more

information see: www.recyclethis.info.

Industry Canada ICES-003Compliance

This device meets the CAN ICES-3 (A)/NMB-3(A)

standards requirements.

Safety Instruction

These instructions are intended to ensure that user can

use the product correctly to avoid danger or property

loss.

The precaution measure is divided into “Warnings” and

“Cautions”

Warnings:Seriousinjury or death may occur if any of the

warnings are neglected.

Cautions:Injuryor equipment damage may occur if any

of the cautions are neglected.

●In the use of the product, you must be in strict

compliance with the electrical safety regulations of

the nation and region.

●Refer to technical specifications for detailed

information.

●Input voltage should meet both the SELV (Safety Extra

Low Voltage) and the Limited Power Source with AC

24V or DC 12V according to the IEC60950-1 standard.

Refer to technical specifications for detailed

information.

●Do not connect several devices to one power adapter

as adapter overload may cause over-heating or a fire

hazard.

●Make sure that the plug is firmly connected to the

power socket.

●When the product is mounted on wall or ceiling, the

device shall be firmly fixed.

●If smoke, odor or noise rise from the device, turn off

the power at once and unplug the power cable, and

then please contact the service center.

●If the product does not work properly, contact your

dealer or the nearest service center. Never attempt to

disassemble the camera by yourself. (We shall not

assume any responsibility for problems caused by

unauthorized repair or maintenance.)

●Make sure the power supply voltage is correct before

using the camera.

●Do not drop the camera or subject it to physical shock.

●Do not touch senor modules with fingers. If cleaning is

necessary, use clean cloth with a bit of ethanol and

wipe it gently. If the camera will not be used for an

extended period, replace the lens cap to protect the

sensor from dirt.

●Do not aim the camera at the sun or extra bright

places. Blooming or smearing may occur otherwise

(which is not a malfunction), and affect the endurance

of sensor at the same time.

●The sensor may be burned out by a laser beam, so

when any laser equipment is in using, make sure that

the surface of sensor will not be exposed to the laser

beam.

●Do not place the camera in extremely hot, cold, dusty

or damp locations, and do not expose it to high

electromagnetic radiation.

●To avoid heat accumulation, good ventilation is

required for operating environment.

●Keep the camera away from liquid while in use.

●While in delivery, the camera shall be packed in its

original packing, or packing of the same texture.

Symbol Conventions

The symbols that may be found in this document are

defined as follows.

Symbol Description

Provides additional information to

emphasize or supplement important

points of the main text.

Indicates a potentially hazardous

situation, which if not avoided, could

result in equipment damage, data loss,

performance degradation, or

unexpected results.

Indicates a hazard with a high level of

risk, which if not avoided, will result in

death or serious injury.

Introduction

1.1 Product Features

This series of camera adopts new generation sensor with

high sensitivity and advanced circuit design technology. It

features high resolution, low image distortion and low

noise, etc., which makes it suitable for surveillance system

and image processing system.

The main features are as follows:

●High performance CMOS sensor and high resolution

bring high-quality image.

●AGC (Auto Gain Control).

●Aviation plug output, shock proof.

●IP68.

1.2 Overview

1.2.1 Overview of Vehicle-Mounted Camera

The overview of the camera is shown below.

4-Pin Aviation Plug

Lens

Bracket

Cover

Overview

1.2.2 Aviation Plug Interfaces

There are 2 types for the aviation plug interfaces, as

shown in below.

Video Interface

GND Power Supply

GND Video Interface

GND

Power Supply

GND

Type A Type B

Interfaces of Aviation Plug

Installation

Beforeyou start:

●Please make sure that the device in the package is in

good condition and all the assembly parts are

included.

●Make sure that all the related equipment is power-off

during the installation.

●Check the specification of the products for the

installation environment.

●Check whether the power supply is matched with your

power output to avoid damage.

●Be sure that there is enough space to install the

camera and accessories.

●Make sure the part, which is used to install the camera,

is strong enough to withstand four times the weight of

the camera and the mounting.

●If the product does not function properly, please

contact your dealer or the nearest service center. Do

not disassemble the camera for repair or maintenance

by yourself.

●Do not pull and drag the camera cables hard.

Steps:

Paste the drill template to the vehicle wall.

Drill the screw holes according to the drill

template.

Drill Template

Loosen 4 crews (M2.5 x 7) on the cover.

Set Screws

M 2.5 × 7

Loosen Screws

Align the holes on the bracket with the installation

holes on the drill template.

Use 3 crews (PA4 x 25) to secure the bracket to the

template.

Holes for Fixing

Bracket

Secure Bracket

Route camera’s cables through the cable hole of

the bracket.

Seal Ring

Fixing Hole

Route the Cable

Secure the seal ring near the cable hole.

Adjust the camera main body with UP upward as

the figure below.

Adjust Camera

(Optional) If the installation site of the camera

needs to be sealed, please wipe silica gel on the screw

position and the cable hole, and seal them.

Align the cover with the crew holes on the bracket,

and insert 4 set crews (M2.5 x 7).

4 M2.5 x 7 Srews

Insert Screws

Connect the camera’s cables to the corresponding

4-pin aviation plug.

Adjust the camera according to the figure below to

get an optimum angle, and fasten 4 set crews (M2.5 x

7).

Tighten Screws

Pan

-8° to 16°

Tilt：-8° to 8°

Tighten Screws and Adjust Camera

Tear the protective film on the lens off.

Tabla de contenidos

Otros manuales de Cámara de seguridad de HIK VISION

HIK VISION

HIK VISION DS-2XE Series Manual de usuario

HIK VISION

HIK VISION UD04285B Manual de usuario

HIK VISION

HIK VISION DS-2AE7232TI-A Manual de usuario

HIK VISION

HIK VISION DS-2XE6825G0-IZHS Manual de usuario

HIK VISION

HIK VISION DS-2CD5526G0-IZHS Manual de usuario

HIK VISION

HIK VISION DS-2CD2563G0-IS Manual de usuario

HIK VISION

HIK VISION PTZ Ultra Series Manual de usuario

HIK VISION

HIK VISION NETWORK CAMERA Manual de usuario

HIK VISION

HIK VISION PanoVu Mini Manual de usuario

HIK VISION

HIK VISION DS-2DF1-574D Manual de usuario

HIK VISION

HIK VISION DS-2CE16H5T-IT Manual de usuario

HIK VISION

HIK VISION DS?2CC5173P(N)?VP(IR)(?H) Manual de usuario

HIK VISION

HIK VISION NETWORK CAMERA Manual de usuario

HIK VISION

HIK VISION DS-2CE56D8T-IT1 Manual de usuario

HIK VISION

HIK VISION DS-2DF1-713B Manual de usuario

HIK VISION

HIK VISION DS-2XM6825G0/C-IVSM Manual de usuario

HIK VISION

HIK VISION DS-2CD883F-E series Manual de usuario

HIK VISION

HIK VISION DS-2CE5512P(N) Manual de usuario

HIK VISION

HIK VISION DS-2TD2628-7/QA/GLT Manual de usuario

HIK VISION

HIK VISION UD06695B Manual de usuario

HIK VISION

HIK VISION DS-2CE17H0T-IT3F Manual de usuario

HIK VISION

HIK VISION DS-2XE62 2F-IS Series Manual de usuario

HIK VISION

HIK VISION TURBO HD H0T PIR Series Manual de usuario

HIK VISION

HIK VISION DS-2CE1512PN-IR Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
