HIK VISION DS-KH3200-L Manual de usuario

Video Intercom Indoor Station

User Manual

Video Intercom Indoor Station·User Manual

User Manual

This user manual is intended for users of the indoor station (DS-KH3200-L).

It includes instructions on how to use the Product. The software embodied in the

Product is governed by the user license agreement covering that Product.

About this Manual

This Manual is subject to domestic and international copyright protection. Hangzhou

Hikvision Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This

manual cannot be reproduced, changed, translated, or distributed, partially or wholly, by

any means, without the prior written permission of Hikvision.

Trademarks

and other Hikvision marks are the property of Hikvision and are

registered trademarks or the subject of applications for the same by Hikvision and/or its

affiliates. Other trademarks mentioned in this manual are the properties of their

respective owners. No right of license is given to use such trademarks without express

permission.

Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HIKVISION MAKES NO WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL.

HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE

USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR RELIABILITY OF INFORMATION

CONTAINED HEREIN. YOUR USE OF THIS MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE

WHOLLY AT YOUR OWN RISK AND RESPONSIBILITY.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT WILL HIKVISION, ITS

DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL,

CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES

FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, SECURITY BREACHES, OR LOSS OF DATA

OR DOCUMENTATION, IN CONNECTION WITH THE USE OF OR RELIANCE ON THIS MANUAL, EVEN IF

HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY OR CERTAIN

DAMAGES, SO SOME OR ALL OF THE ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU.

Support

Should you have any questions, please do not hesitate to contact your local dealer.

Video Intercom Indoor Station·User Manual

Regulatory Information

FCC Information

Please take attention that changes or modification not expressly approved by the party

responsible for compliance could void the user’s authority to operate the equipment.

FCC compliance: This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference

in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may

cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are

marked with "CE" and comply therefore with the applicable harmonized

European standards listed under the EMC Directive 2014/30/EU, the

RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot

be disposed of as unsorted municipal waste in the European Union. For

proper recycling, return this product to your local supplier upon the

purchase of equivalent new equipment, or dispose of it at designated

collection points. For more information see: www.recyclethis.info

2006/66/EC (battery directive): This product contains a battery that

cannot be disposed of as unsorted municipal waste in the European

Union. See the product documentation for specific battery information.

The battery is marked with this symbol, which may include lettering to

indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling,

return the battery to your supplier or to a designated collection point.

For more information see: www.recyclethis.info

Video Intercom Indoor Station·User Manual

iii

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to

avoid danger or property loss.

The precaution measure is divided into Warnings and Cautions:

Warnings: Neglecting any of the warnings may cause serious injury or death.

Cautions: Neglecting any of the cautions may cause injury or equipment damage.

Warnings

The working temperature of the device is from -10ºC to 55ºC.

All the electronic operation should be strictly compliance with the electrical safety

regulations, fire prevention regulations and other related regulations in your local

region.

Please use the power adapter, which is provided by normal company. The power

consumption cannot be less than the required value.

Do not connect several devices to one power adapter as adapter overload may cause

over-heat or fire hazard.

Please make sure that the power has been disconnected before you wire, install or

dismantle the device.

When the product is installed on wall or ceiling, the device shall be firmly fixed.

If smoke, odors or noise rise from the device, turn off the power at once and unplug

the power cable, and then please contact the service center.

If the product does not work properly, please contact your dealer or the nearest

service center. Never attempt to disassemble the device yourself. (We shall not

assume any responsibility for problems caused by unauthorized repair or

maintenance.)

Indoor station is powered by video/audio distributor(DS-KAD308/DS-KAD312).

Cautions

Do not drop the device or subject it to physical shock, and do not expose it to high

electromagnetism radiation. Avoid the equipment installation on vibrations surface

or places subject to shock (ignorance can cause equipment damage).

Do not place the device in extremely hot (refer to the specification of the device for

the detailed operating temperature), cold, dusty or damp locations, and do not

expose it to high electromagnetic radiation.

Warnings Follow

these safeguards to

prevent serious

injury or death.

Cautions Follow these

precautions to prevent

potential injury or

material damage.

Video Intercom Indoor Station·User Manual

The device cover for indoor use shall be kept from rain and moisture.

Exposing the equipment to direct sun light, low ventilation or heat source such as

heater or radiator is forbidden (ignorance can cause fire danger).

Do not aim the device at the sun or extra bright places. A blooming or smear may

occur otherwise (which is not a malfunction however), and affecting the endurance

of sensor at the same time.

Please use the provided glove when open up the device cover, avoid direct contact

with the device cover, because the acidic sweat of the fingers may erode the surface

coating of the device cover.

Please use a soft and dry cloth when clean inside and outside surfaces of the device

cover, do not use alkaline detergents.

Please keep all wrappers after unpack them for future use. In case of any failure

occurred, you need to return the device to the factory with the original wrapper.

Transportation without the original wrapper may result in damage on the device and

lead to additional costs.

Improper use or replacement of the battery may result in hazard of explosion.

Replace with the same or equivalent type only. Dispose of used batteries according

to the instructions provided by the battery manufacturer.


Video Intercom Indoor Station·User Manual
v


Table of Contents
Overview......................................................................................................1
1 Introduction............................................................................................................. 1
2 Main Features.......................................................................................................... 1
3 Typical Application................................................................................................... 2
Appearance ..................................................................................................3
1 Front Panel .............................................................................................................. 3
2 Rear Panel................................................................................................................ 4
Terminals and Wiring ...................................................................................5
1 Terminal Description................................................................................................ 5
2 Wiring Description................................................................................................... 5
Installation ...................................................................................................7
1 Installation Accessory Description ........................................................................... 7
2 Wall Mounting with Junction Box............................................................................ 7
Local Operation ............................................................................................9
Appendix ...................................................................................................... 11
Installation Notice ....................................................................................................... 11

Video Intercom Indoor Station·User Manual

1Overview

1.1 Introduction

The indoor station supports video intercom, resident-to-resident video call and zone

alarm, etc. It provides smart and convenient visiting calling and security service.

The video intercom indoor station is mainly applied to community.

1.2 Main Features

Video intercom function: communicate with door station, master station, client or

center

Monitoring the door station

TFT LCD that support power-saving mode

Remote unlocking function

Voice prompt

Volume adjustment

4-ch zone alarm

Video Intercom Indoor Station·User Manual

1.3 Typical Application

22F

23F

Resident 2 Resident 1

Building

Door Station Outer Door Station

Video/Audio

Distributor

Video/Audio

Distributor

Video/Audio

Distributor

Video/Audio

Distributor

Client Software (PC)

Center Master Station

Network Cable

Figure 1-1 Typical Application of Indoor Station

Configure the room number before build the system on the video/audio distributor.

See the Video/Audio Distributor User Manual for detailed DIP rules.

The indoor station, door station and video/audio distributor are connected via

network cable transferring analog signal.

The door station, outer door station and master station should all connect to the

same LAN via network cable transferring digital signal.

Video Intercom Indoor Station·User Manual

2Appearance

2.1 Front Panel

Figure 2-1 Front Panel

Table 2-1 Components Description

No.

Description

Volume Wheel

Power Supply Indicator

Alarm Indicator

Answer/Decline Key

Unlock Key

Live View Key

Management Center Key

LCD Display Screen

Microphone

Arm/Disarm Key

The Unlock key is valid only when does the indoor station speak with the door station or

open the live view of the door station.

Video Intercom Indoor Station·User Manual

2.2 Rear Panel

Figure 2-2 Rear Panel

Table 2-2 Components Description

No.

Description

Network Interface(24 VDC)

Reserved

Loudspeaker

Terminals

Tabla de contenidos

Otros manuales de Sistema de intercomunicación de HIK VISION

HIK VISION

HIK VISION DS-KH6320-WTDE1 Manual de usuario

HIK VISION

HIK VISION DS-KM9503 Manual de usuario

HIK VISION

HIK VISION DS-KH9510-WTE1 Manual de usuario

HIK VISION

HIK VISION DS-KIS703-P Manual de usuario

HIK VISION

HIK VISION 9 Series Manual de usuario

HIK VISION

HIK VISION DS-KB2411-IM Manual de usuario

HIK VISION

HIK VISION DS-KV6113 Series Manual de usuario

HIK VISION

HIK VISION DS-KIS701 Manual de usuario

HIK VISION

HIK VISION DS-KH6320-WTE1-W Manual de usuario

HIK VISION

HIK VISION DS-KH6320-WTE1 Manual de usuario

HIK VISION

HIK VISION D Series Manual de usuario

HIK VISION

HIK VISION DS-KD8003-IME1 Manual de usuario

HIK VISION

HIK VISION DS-KH6350-WTE1/Europe BV Manual de usuario

HIK VISION

HIK VISION DS-PEA4H-10 Manual de usuario

HIK VISION

HIK VISION DS-KIS101-P/FLUSH Manual de usuario

HIK VISION

HIK VISION DS-KH8520-WTE1 Manual de usuario

HIK VISION

HIK VISION DS-KV6113-PE1 Manual de usuario

HIK VISION

HIK VISION DS-KH6320-WTDE1 Manual de usuario

HIK VISION

HIK VISION DS-KH6320-WTE1 Manual de usuario

HIK VISION

HIK VISION KD8023E6 Series Manual de usuario

HIK VISION

HIK VISION DS-KIS202T Manual de usuario

HIK VISION

HIK VISION DS-KV8103Y-IMPE2 Manual de usuario

HIK VISION

HIK VISION DS-KH9510- WTE1B Manual de usuario

HIK VISION

HIK VISION DS-KIS603-P(B) Manual de usuario

Manuales populares de Sistema de intercomunicación de otras marcas

Bticino

Bticino LINEA 3000 Manual de usuario

MSI

MSI MSI-140 Manual de usuario

golmar

golmar Stadio Plus Manual de usuario

CyberData

CyberData 011211 series Manual

Vidos

Vidos duo M1021 Manual de usuario

Vimar

Vimar ELVOX 7539/E Manual de usuario

SSS Siedle

SSS Siedle BTSV 850-03 Manual de usuario

Dahua

Dahua VTO Series Manual de usuario

Elvox

Elvox 5651 Manual de usuario

Videx

Videx VIDEOKIT Series Manual de usuario

Rocom

Rocom Doortello Business FW T2.05W2.04 Manual de usuario

Viking

Viking E-35-EWP Manual de usuario

Safeguard Supply

Safeguard Supply LRA-EX1000 Manual de usuario

SSS Siedle

SSS Siedle BFCV 850 Series Manual de usuario

GRD

GRD MAX V2 Manual de usuario

Alecto

Alecto ADI-250 Manual de usuario

Aiphone

Aiphone IE-8MD Manual de usuario

Perel

Perel EDB4 Manual de usuario
