HIK VISION 8 Series Manual de usuario

Video Intercom Demo Case

User Manual

Video Intercom Demo Case·User Manual

Quick Start Guide

This user manual is intended for users of the video intercom demo case.

About this Manual

This Manual is subject to domestic and international copyright protection. Hangzhou

Hikvision Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This

manual cannot be reproduced, changed, translated, or distributed, partially or wholly, by

any means, without the prior written permission of Hikvision.

Trademarks

and other Hikvision marks are the property of Hikvision and are

registered trademarks or the subject of applications for the same by Hikvision and/or its

affiliates. Other trademarks mentioned in this manual are the properties of their

respective owners. No right of license is given to use such trademarks without express

permission.

Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HIKVISION MAKES NO WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL.

HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE

USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR RELIABILITY OF INFORMATION

CONTAINED HEREIN. YOUR USE OF THIS MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE

WHOLLY AT YOUR OWN RISK AND RESPONSIBILITY.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT WILL HIKVISION, ITS

DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL,

CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES

FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, SECURITY BREACHES, OR LOSS OF DATA

OR DOCUMENTATION, IN CONNECTION WITH THE USE OF OR RELIANCE ON THIS MANUAL, EVEN IF

HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY OR CERTAIN

DAMAGES, SO SOME OR ALL OF THE ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU.

Support

Should you have any questions, please do not hesitate to contact your local dealer.

Video Intercom Demo Case·User Manual

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to

avoid danger or property loss.

The precaution measure is divided into Warnings and Cautions:

Warnings: Neglecting any of the warnings may cause serious injury or death.

Cautions: Neglecting any of the cautions may cause injury or equipment damage.

Warnings

The working temperature of the device is from -10ºC to 55ºC.

All the electronic operation should be strictly compliance with the electrical safety

regulations, fire prevention regulations and other related regulations in your local

region.

Please use the power adapter, which is provided by normal company. The power

consumption cannot be less than the required value.

Do not connect several devices to one power adapter as adapter overload may cause

over-heat or fire hazard.

Please make sure that the power has been disconnected before you wire, install or

dismantle the device.

When the product is installed on wall or ceiling, the device shall be firmly fixed.

If smoke, odors or noise rise from the device, turn off the power at once and unplug

the power cable, and then please contact the service center.

If the product does not work properly, please contact your dealer or the nearest

service center. Never attempt to disassemble the device yourself. (We shall not

assume any responsibility for problems caused by unauthorized repair or

maintenance.)

Cautions

Do not drop the device or subject it to physical shock, and do not expose it to high

electromagnetism radiation. Avoid the equipment installation on vibrations surface

or places subject to shock (ignorance can cause equipment damage).

Do not place the device in extremely hot (refer to the specification of the device for

the detailed operating temperature), cold, dusty or damp locations, and do not

expose it to high electromagnetic radiation.

The device cover for indoor use shall be kept from rain and moisture.

Warnings Follow

these safeguards to

prevent serious

injury or death.

Cautions Follow these

precautions to prevent

potential injury or

material damage.

Video Intercom Demo Case·User Manual

iii

Exposing the equipment to direct sun light, low ventilation or heat source such as

heater or radiator is forbidden (ignorance can cause fire danger).

Do not aim the device at the sun or extra bright places. A blooming or smear may

occur otherwise (which is not a malfunction however), and affecting the endurance

of sensor at the same time.

Please use the provided glove when open up the device cover, avoid direct contact

with the device cover, because the acidic sweat of the fingers may erode the surface

coating of the device cover.

Please use a soft and dry cloth when clean inside and outside surfaces of the device

cover, do not use alkaline detergents.

Please keep all wrappers after unpack them for future use. In case of any failure

occurred, you need to return the device to the factory with the original wrapper.

Transportation without the original wrapper may result in damage on the device and

lead to additional costs.

Improper use or replacement of the battery may result in hazard of explosion.

Replace with the same or equivalent type only. Dispose of used batteries according

to the instructions provided by the battery manufacturer.

Video Intercom Demo Case·User Manual
iv


Table of Contents
Demo Case Overview ...................................................................................1
1 Devices Overview ..................................................................................................................... 1
2 Default Parameters................................................................................................................... 1
Getting Started............................................................................................. 3
1 Activate Indoor Station............................................................................................................. 3
2 Quick Operation ....................................................................................................................... 3
3 Configure Sub Module Address ................................................................................................ 5
Video Intercom Function.............................................................................. 7
1 Video Intercom Function of Group 1 and Group 2 ................................................................... 7
2 Video Intercom Function of Group 3........................................................................................ 8
2.1 Call Resident ...................................................................................................................... 8
2.2 Issue Card .......................................................................................................................... 9
2.3 Unlock Door....................................................................................................................... 9
3 Video Intercom Function Among Indoor Stations .................................................................. 10
Live View.................................................................................................... 12
Remote Operation via Mobile Client .......................................................... 14
1 Set Up Mobile Client............................................................................................................... 14
2 Add Device ............................................................................................................................. 14
2.1 Add Device to APP via QR Code....................................................................................... 14
2.2 Add Device to Mobile client via Serial No........................................................................ 15

Video Intercom Demo Case·User Manual

1Demo Case Overview

1.1 Devices Overview

The demo case displays 3 groups of indoor station and door station.

See Figure 1-1 for the default calling relationship among these video intercom devices.

Figure 1-1 Intercom Application Diagram

1.2 Default Parameters

In the demo case, video intercom devices are divided into 3 groups by default.

The default configuration password for network indoor stations is 888999.

The default activation password of network video intercom devices in the demo

case is hik12345.

For DS-KH8350-WTE1 indoor station, the default Microphone volume, Prompt

Sound Volume and Call Volume are 70%.

For DS-KH6320-WTE1 indoor station, the default Microphone volume, Prompt

Sound Volume and Call Volume are 70%.

Refer to Table 1-1 to see the default parameters for each device.

Table 1-1 Device Information

Group No.

Device Type

Device Model

Room No.

Indoor Station

DS-KH8350-WTE1

192.0.0.65

Video Intercom Demo Case·User Manual

Door Station

DS-KD8003-IME1/

Surface

192.0.0.64

Nametag Module

DS-KD-KK

Indicator Module

DS-KD-IN

Indoor Station

DS-KH6320-WTE1

192.0.0.66

Door Station

DS-KD8003-IME1/

Surface

192.0.0.64

Nametag Module

DS-KD-KK

Indicator Module

DS-KD-IN

Door Station

DS-KD8003-IME1/

Surface

192.0.0.65

Nametag Module

DS-KD-KK

Indicator Module

DS-KD-IN

Keypad Module

DS-KD-KP

Card Reader

Module

DS-KD-M

Video Intercom Demo Case·User Manual

2Getting Started

2.1 Activate Indoor Station

You can only configure and operation the device after creating a password for the device

activation.

Steps:

1. Power on the device. It will enter the activation page automatically.

2. Create a password and confirm it.

3. Tap OK to activate the indoor station.

We highly recommend you to create a strong password of your own choosing

(using a minimum of 8 characters, including at least three kinds of following

categories: upper case letters, lower case letters, numbers, and special characters)

in order to increase the security of your product. And we recommend you reset

your password regularly, especially in the high security system, resetting the

password monthly or weekly can better protect your product.

2.2 Quick Operation

For DS-KH8350-WTE1 and DS-KH6320-WTE1, after device activation, the wizard page

will pop up.

Steps:

1. Choose language and tap Next.

Figure 2-1 Wizard-Language Settings

2. Set network parameters and tap Next.

Video Intercom Demo Case·User Manual

Figure 2-2 Wizard-Network Settings

1). Edit Local IP, Subnet Mask and Gateway parameters.

2). Enable DHCP, the device will get network parameters automatically.

3. Configure the indoor station and tap Next.

Figure 2-3 Wizard-Settings page

1). Choose Indoor station type.

2). Edit Floor and Room No.

4. Linked related devices and tap Next. If the device and the indoor station are in the

same LAN, the device will be displayed in the list. Tap the device or enter the serial

No. to link.

Video Intercom Demo Case·User Manual

Figure 2-4 Wizard-Related Devices Settings

1). Tap the door station in the list to link.

If the door station is inactive, the system will pop up the dialog to activate the

door station.

2). Tap to pop up the Network Settings page.

3). Edit the network parameters of the door station manually or enable DHCP to get

the network parameters automatically.

4). Tap OK to save the settings.

5. Tap Finish to save the settings.

2.3 Configure Sub Module Address

You need to set the sub module address via DIP before installation.

Steps:

1. Remove the rubber cover on the sub module rear panel to expose the DIP switch.

2. Set the sub module address according to the DIP rules, and install the rubber cover

back.

Digit 1, 2, 3, 4 are used to coding the sub module address; Digit 5, 6, 7 are reserved;

Digit 8 is a resistance (120Ω) is you set it as on.

Valid sub module address range is 1 to 8. The No. should be unique for sub modules

that connected to the same main unit.

Otros manuales para 8 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de intercomunicación de HIK VISION

HIK VISION

HIK VISION Door Station Manual de usuario

HIK VISION

HIK VISION DS-KV6113 Series Manual de usuario

HIK VISION

HIK VISION DS-KIS212 Manual de usuario

HIK VISION

HIK VISION DS-KH6310-W Manual de usuario

HIK VISION

HIK VISION DS-KD9613-FE6 Manual de usuario

HIK VISION

HIK VISION Villa 6 Series Manual de usuario

HIK VISION

HIK VISION DS-KD9403-E6 Manual de usuario

HIK VISION

HIK VISION DS-KH6320-WTE1 Manual de usuario

HIK VISION

HIK VISION DS-KB8113-IME1(B) Series Manual de usuario

HIK VISION

HIK VISION KD8023E6 Series Manual de usuario

HIK VISION

HIK VISION KB8113 Manual de usuario

HIK VISION

HIK VISION DS-KD8003-IME2 Manual de usuario

HIK VISION

HIK VISION Villa IP Instrucciones de uso

HIK VISION

HIK VISION DS-KH6350-TE1 Manual de usuario

HIK VISION

HIK VISION DS-KIS603-P(B) Manual de usuario

HIK VISION

HIK VISION DS-KV8102-IM Manual de usuario

HIK VISION

HIK VISION DS-KIS603-P Manual de usuario

HIK VISION

HIK VISION DS-KD9403-E6 Manual de usuario

HIK VISION

HIK VISION ADS-24S-12 1224GPCN Manual de usuario

HIK VISION

HIK VISION DS-KH9310-WTE1B Manual de usuario

HIK VISION

HIK VISION DS-KH6320-LE1 Manual de usuario

HIK VISION

HIK VISION DS-KH6320-LE1 Manual de usuario

HIK VISION

HIK VISION DS-KH9510-WTE1 Manual de usuario

HIK VISION

HIK VISION DS-KV8102-1A Manual de usuario

Manuales populares de Sistema de intercomunicación de otras marcas

Bticino

Bticino LINEA 3000 Manual de usuario

MSI

MSI MSI-140 Manual de usuario

golmar

golmar Stadio Plus Manual de usuario

CyberData

CyberData 011211 series Manual

Vidos

Vidos duo M1021 Manual de usuario

Vimar

Vimar ELVOX 7539/E Manual de usuario

SSS Siedle

SSS Siedle BTSV 850-03 Manual de usuario

Dahua

Dahua VTO Series Manual de usuario

Elvox

Elvox 5651 Manual de usuario

Videx

Videx VIDEOKIT Series Manual de usuario

Rocom

Rocom Doortello Business FW T2.05W2.04 Manual de usuario

Viking

Viking E-35-EWP Manual de usuario

Safeguard Supply

Safeguard Supply LRA-EX1000 Manual de usuario

SSS Siedle

SSS Siedle BFCV 850 Series Manual de usuario

GRD

GRD MAX V2 Manual de usuario

Alecto

Alecto ADI-250 Manual de usuario

Aiphone

Aiphone IE-8MD Manual de usuario

Perel

Perel EDB4 Manual de usuario
