Hi-Touch Imaging Technologies S400 Manual de usuario
Photo Printer
L300/S300/S400
User Manual
E
ENGLISH
Check the Package Content
Before using HiTi photo printer, please check the printer package content for the following items:
HiTi Photo Printer x 1
LCD Controller x 1 (only standard on S series photo printers)
Power Cord x 1
USB Cable x 1 (for the connection between the photo printer and the computer)
Paper Cassette x 1
Printer User Manual
PhotoDesiree Deluxe User Manual
HiTi Bag x 1 (including following items…)
Quick Guide x 1
Notice Sheet x 1
Warranty Card x 1
Master CD x1 (Includes the driver and PhotoDesiree Deluxe)
* The package content varies according to different areas.
Table of Content
Get To Know HiTi Photo Printer
LCD controller
Front view
Rear view
Installing Your HiTi Photo Printer
Installing the LCD controller
Installing ribbon cartridge
Loading dedicated photo papers
Powering up the printer
Functional Instruction
Home Menu Introduction
COLLAGE
INDEX
STICKER
SETUP
IMAGE DEVICE
Printing Photos Without a PC
Distinguishing type of memory card
Insert memory card
Standalone printing
Special Function
I2O
Matte
Date print
Signature
Language
Print position
Color setting
LCD adjustment
Wallpaper and Color theme
Signature
Sepia and Border
ColorWizard
Image device
Advanced image editing
Cleaning mode
PC-Link Printing
Installing printer driver
Connecting to a computer
Troubleshooting
Indicator blinking
Others
Specification
Optional consumables and accessories
Contact Us
Online support
Global sites
Get To Know HiTi Photo Printer
To ensure proper printer operation, please read the following instructions thoroughly before using the photo printer.
LCD controller
1. LCD panel
2. I2O ON/OFF
3. Matte ON/OFF
4. Date Print ON/OFF
5. Signature ON/OFF
6. [ESC]
7. [OK]
8. Directional button
9. [EDIT]
10. [HOME]
11. [PRINT]
Front
1. Ribbon Door Button
2. Ribbon Door
3. Indicator
4. MMC/SD/SM/MS Memory Card Slot
5. CF I/CF II Memory Card Slot
6. USB Host Slot
7. Paper Cassette Door
Rear
1. Hatchback
2. Heat Ventilation
3. Power Switch
4. Power Cord Socket
5. Controller Socket
6. USB Port
Installing Your HiTi Photo Printer
Please follow the instructions below to install your photo printer.
Installing the LCD controller
Connect the LCD controller to the photo printer
* Please connect the controller to the printer by matching the shapes of the connector to the socket
before insertion.
LCD controller installation is complete.
Installing Your HiTi Photo Printer
Please follow the instructions below to install your photo printer.
Installing ribbon cartridge: For more information about ribbon cartridge installation, please refer to the
instruction marked outside the packing for detail.
Push the ribbon door button to open the ribbon door.
Install the ribbon cartridge inserting the left (indicated by the arrow) side of the
ribbon first followed by the right side.
The ribbon has to be installed in the printer properly.
Close the ribbon door to complete the ribbon installation.
Installing Your HiTi Photo Printer
Please follow the instructions below to install your photo printer.
Loading dedicated photo papers
Follow the demonstration to correctly remove photo papers from the packaging.
Open the paper cassette cover.
Load photo papers into the paper cassette and then close the cover.
Open the paper cassette door on the printer and insert the paper cassette.
►For information on the other compatible consumable products, please refer to the Optional Consumables and
Accessories for detail.
►Please hold the side of photo paper and avoid touching the surface when taking them out from the packing.
Installing Your HiTi Photo Printer
Please follow the instructions below to install your photo printer.
Powering up the printer
Plug the power cord into the power cord socket at the back of the printer.
Turn on the power.
Functional Instruction
This instruction will help you to comprehend the photo printer.
Home Menu Introduction
①Image source from SD/SM/MMC/MS/MS Pro memory card
②Image source from CF I/CF II/Microdrive memory card
③Image source from USB host slot
④Quick Print
⑤Border ON/OFF
⑥Sepia ON/OFF
⑦Printing control by HiTi photo printer
⑧Printing control by DSC
⑨Mode: ‘Landscape’
⑩Mode: ‘Portrait’
⑪Functional Menu
►The selected image source will be shown in red color as in ( )
►QUICK: Applying this function will directly bring you to the image preview screen, prompting you to select an image
and print.
