iHand55 Handheld Controller User Manual
Manual Revision
Revision Date Revision Level Description
November, 2021 1 iHand55 Handheld Controller
User Guide A1
iHand55 Handheld Controller User Manual
iHand55
Handheld Controller User Manual
iHand55 Handheld Controller User Manual
1
Preface
Introduction
Welcome to the Hi-Target iHand55 handheld controller. This introduction describes how to use this
product.
Experience Requirement
In order to help you use Hi-Target series products better, Hi-Target suggests you carefully read the
instructions. If you are unfamiliar with the products, please refer to http://www.hi-target.com.cn/.
Tips for Safe Uses
Notice: The contents here are special operations and need your special
attention. Please read them carefully.
Warning: The contents here generally are very important. Wrong operation
may damage the machine, lose data, even break the system and endanger your
safety.
Exclusions
Before using the product, please read these operating instructions carefully, they will help you to use it
better. Hi-Target Surveying Instrument Co., Ltd assumes no responsibility if you fail to operate the
product according to the instructions, or operate wrongly due to misunderstanding the instructions.
Hi-Target is committed to constantly perfecting product functions and performance, improving service
quality and reserves the rights to change these operating instructions without notice.
We have checked the contents of the instructions and the software & hardware, without eliminating the
possibility of deviation. The pictures in the operating instructions are for reference only. In case of non-
conformity with products, the products shall prevail.
iHand55 Handheld Controller User Manual
2
Technology and Service
If you have any technical issues, please call Hi-Target technology department for help, we will answer
your question.
Relevant Information
You can obtain this introduction by:
1. After purchasing Hi-Target products, you will find this manual in the instrument container to guide
you on operating the instrument.
2. Log onto the Hi-Target official website, download the electronic version introduction at
Partners →Partner Center.
Advice
information will help us to improve the product and service.
iHand55 Handheld Controller User Manual
3
\
Chapter 1
iHand55HandheldController
This chapter contains:
- Introduction
- Appearance
- Controller accessories
- Operation
- Application
iHand55 Handheld Controller User Manual
4
1.1 Introduction
1.1.1 Foreword
The iHand55 controller is a professional data collector, based on the Android system. Using a
combination of physical buttons and touch screen to operate, the default input languages are Chinese
and English, and it supports multiple languages. The industrial-standard design can withstand 1.2
meters drop to a cement floor, is IP67 waterproof and dustproof standard to adapt to a complex
operating environment. At the same time, the super capacity lithium battery can handle all weather
requirements.
The iHand55 controller configures 5.5 inches 720*1280 highlighted LCD; 2.0 GHZ, eight-core 64-bit
CPU; and 16GB ROM +2 GB RAM memory. It has a built-in Micro SD card slot, and maximum support
128GB expansion card (it only supports FAT32 format SD card, the NTFS format SD card cannot be
supported); dual card dual stand-by, and supports the entire 4G network. With the Android 10.0
operating system, the interface is optimized and easy to use.
1.1.2 Features
1. Industrial-standard design, with IP67 it can withstand 1.2 meters drop to a cement floor and adapt to
a complex operating environment.
2. Highlighted LCD, the LCD screen is normally readable under strong sunlight.
3. Supports Bluetooth, Wi-Fi and 4G，which is convenient to carry out a variety of wireless data
transmissions with the receiver. Wi-Fi and 4G can be used at the same time. Refer to the Hi-Survey
Road Software User's Guide for more details.
4. Internal 13-million-pixel camera: for field collection of image information.
5. Internal removable large capacity lithium battery for more than 14 hours of work.
6. Internal NFC chip, supports NFC data transmission for a rapid connection between the RTK and
hand-held controller.
7. Fast charge technology: for a rapid battery charge.
8. Full keyboard input method.
9. Local online upgrade to facilitate quick changes.
1.1.3 Caution
Although the iHand55 hand-held controller is made with chemical and impact resistant materials, it
needs to be carefully used and maintained, and should be kept in a dry environment. In order to
improve the stability and usage cycle of the iHand55 hand-held controller, please avoid exposing it to
extreme environments, such as humidity, high temperatures, low temperatures, corrosive liquids or
gases, etc.
iHand55 Handheld Controller User Manual
5
Notice:The iHand55 hand-held controller must be used within the temperature
range from -20℃ to 60℃
1.2 Appearance
1.2.1 Front of the controller
The front of the iHand55 controller includes a touch screen, keyboard microphone and indictor light.
Figure1‐2‐1iHand55controller
- Touch screen: multipoint capacitive touch screen with touch pen (open the touch pen function:
Settings - Accessibility - Handwriting pen), which supports Chinese and English input.
- Keyboard: direction control, switch between Chinese and English, data collection, volume control,
power on, power off and other functions.
- Microphone: the internal microphone can be used for field collection of voice messages.
2
1
1- Indictor light 2- Microphone 3- Touch screen 4- Keyboard
3
4
iHand55 Handheld Controller User Manual
6
1.2.2 Reverse side of the controller
There is a camera, belt, NFC, trumpet, etc. on the reverse of the controller.
Figure1‐2‐2thebacksideoftheiHand55
- Camera: used for field collection of images.
- Belt hole: connect the belt to prevent it sliding down.
- Trumpet: conduct real-time voice broadcasts for instrument operation and status.
- NFC: supports NFC data transmission to achieve rapid connection between RTK and the hand-held
controller.
4
1
2
3
1- Camera2- NFC3-Trumpet 4- Belt hole
iHand55 Handheld Controller User Manual
7
1.2.3 Side of the controller
Figure1‐2‐3theportofiHand55
- Type-C port: for connecting the USB data line and the controller.
Notice:When not using Mini USB, please close the rubber cover to make it
waterproof and dustproof.
1.3 Controller accessories
1.3.1 Data cable
Figure1‐3‐1Datacable
USB data cable: connect to the USB port of a computer, for download of data; connect to the Type-C
port of the charger for charging the controller.
1- Waterproof & dustproof rubber cover2- Type-C port
1
2
