Hi Resolution HRT008IP Manual de usuario
HR0913/ver.1.0 www.hrcctv.com
IP DOME CAMERA
User Manual HRT008IP
User Manual
HRT008IP
pag.2www.hrcctv.com
NORME GENERALI DI SICUREZZA -
General safety recommendations
Sicurezza delle persone - Safety warnings
Leggere e seguire le istruzioni - Tutte le
istruzioni per la sicurezza e per l'operatività
devono essere lette e seguite prima che il
prodotto sia messo in funzione.
Precauzioni particolari - Rispettare
tassativamente l'ordine delle istruzioni di
installazione e collegamento descritte nel
manuale. Verificare le indicazioni riportate sulla targa di
identificazione: esse devono corrispondere alla vostra rete
elettrica di alimentazione ed al consumo elettrico. Conservate le
istruzioni per una consulta futura.
Read and follow the instructions - Read the installation
instructions before connecting the system to its power source.
Follow these guidelines to ensure general safety.
In order to prevent injury, burns or electrical shock to yourself
and others, follow the connection instruction plan carefully.
Sicurezza del prodotto - Product Safety
Non posizionare in prossimità di liquidi oppure in un ambiente ad
umidità eccessiva.
Non lasciare penetrare del liquido o corpi estranei all'interno
dell'apparecchiatura.
Non ostruire le griglie di aerazione.
Non sottoporre all'esposizione dei raggi solari oppure in prossimità
di fonti di calore.
Do not use the product in a wet location.
Never push a foreign object through an opening inside the
product.
Slots and openings are provided for ventilation and should never
be covered.
Do not place under direct sunlight or heat sources.
INFORMAZIONI SULL’AMBIENTE -
ENVIRONMENT INFORMATION
Note per lo smaltimento del prodotto
valide per la Comunità Europea
Questo prodotto è stato progettato e
assemblato con materiali e componenti
di alta qualità che possono essere
riciclati e riutilizzati. Non smaltire il
prodotto come rifiuto solido urbano ma
smaltirlo negli appositi centri di
raccolta. E’ possibile smaltire il
prodotto direttamente dal distributore
dietro l’acquisto di uno nuovo,
equivalente a quello da smaltire. Abbandonando il prodotto
nell’ambiente si potrebbero creare gravi danni all’ambiente
stesso. Nel caso il prodotto contenga delle batterie è
necessario rimuoverle prima di procedere allo smaltimento.
Queste ultime debbono essere smaltite separatamente in
altri contenitori in quanto contenenti sostanze altamente
tossiche.
Il simbolo rappresentato in figura rappresenta il bidone dei
rifiuti urbani ed è tassativamente vietato riporre
l’apparecchio in questi contenitori.
L’immissione sul mercato dopo il 1° luglio 2006 di prodotti
non conformi al DLgs 151 del 25-07-05 (Direttiva RoHS
RAEE) è amministrativamente sanzionato.
Disposal of waste products for European Union
This products was designed to minimize their impact on the
environment by reducing or eliminating hazardous
materials and designing for recyclables.
This product should be handed over to a designated
collection point, e.g., on an authorized one -for-one basis
when you buy a new similar product or to an authorized
collection site for recycling waste electrical and electronic
equipment. Improper handling of this kind of waste could
have a possible negative impact on the environment and
human health due to potentially hazardous substances.
This symbol indicates that this product has not to be
disposed of with your household waste, according to the
WEEE Directive.
For more information about where you can drop off your
waste equipment for recycling, please contact your local
city waste authority, or your household waste disposal
service.
GARANZIA - Warranty
Questa garanzia ha validità di 2 anni a partire dalla data
di acquisto assicurata solo dietro presentazione della
fattura o scontrino rilasciati al cliente dal rivenditore.
L’assistenza gratuita non è prevista per i guasti causati da:
-Uso improprio del prodotto, immagazzinamento
inadeguato, cadute o urti, usura, sporcizia, acqua, sabbia,
manomissione da personale non autorizzato del prodotto
rispetto a quanto previsto nei manuali d’uso inclusi.
-Riparazioni, modifiche o pulizia effettuate da centri
assistenza non autorizzati da HR EUROPE.
-Danni o incidenti le cui cause non possono essere attribuite
alla HR EUROPE, comprendenti e non limitati a fulmini,
eventi naturali, alimentazione e ventilazione inadeguata.
This warranty is valid for 2 years from the date of
purchase obtained only against presentation of the
original invoice/ cash ticket issued to the customer by
the retailer.
Warranty repair service is excluded if damage or defects
have been caused by:
-Improper use, incorrect storage, dropping or shocks,
corrosion, dirt, water, handing or operation of the product
as referred to in the users’ manuals.
User Manual
HRT008IP
www.hrcctv.com pag.3
Sommario
1. Intrduction.............................................................................................................................4
1.1 Part Name and Function............................................................................... 4
1.1.1 Power Indication Light Working Status Illustration.............................................................................4
1.1.2 Network Indication Light Working Status Illustration..........................................................................4
1.1.3 RESET Button Function .............................................................................................................5
1.2 Installation Procedure ................................................................................. 5
1.2.1 Without Bracket .....................................................................................................................5
1.2.2 With Bracket .........................................................................................................................6
1.3 IP Camera Power Cable Connection................................................................. 7
1.4 System Requirement ................................................................................... 8
1.5 Technical Specification................................................................................ 9
1.6 Wire Network ............................................................................................ 10
1.6.1 Connect to LAN via internet port .................................................................................................10
2. Contents of CD-ROM..........................................................................................................10
3. Search for devices on the network...................................................................................10
4. Usage through the web......................................................................................................11
4.1 Network Connection.................................................................................... 11
4.2 Login....................................................................................................... 11
5. Quick guide to the choice of software..............................................................................13
5.1 HR-EPSS BASIC ........................................................................................... 13
5.2 HR-EPSS BUSINESS(trial 90gg) ........................................................................ 13
5.3 HR-MOBILE PSS........................................................................................... 14
User Manual
HRT008IP
pag.4www.hrcctv.com
1. INTRDUCTION
PACKAGE CONTENTS
•IP camera------------------------------1
•Bracket----------------------------------1
•Micelle-----------------------------------1
•Plastic board---------------------------1
•Screws and anchors-----------------4
•Plate screws------------------------2+1
•Network cable-------------------------1
•Power cable----------------------------1
•User Manual----------------------------1
1.1 PART NAME AND FUNCTION
You can refer to the following figure for IP camera part name.
1.1.1Power Indication Light Working Status Illustration
When connect power to the IP camera, the red light becomes flash and then green light becomes on. Now
the program is running properly, you can log in via network.
The indication light turns off when you reboot the IP camera via software.
1.1.2Network Indication Light Working Status Illustration
The network indication light becomes red when you connect the IP camera to the wire network.
User Manual
HRT008IP
www.hrcctv.com pag.5
1.1.3RESET Button Function
You can click this button to restore factory default setup. After the power indication light became green,
press this button for at least five seconds, you can see the system automatically reboot. After rebooting, the
system restored factory default setup
1.2 INSTALLATION PROCEDURE
This series IP camera can be installed on the table, wall or ceiling
1.2.1Without Bracket
You can use the fixed board to install the IP camera on the wall or the ceiling.
•Use screws to fix the IP camera on the plastic board.
•Dig four holes in the wall in accordance with the holes in the metal board. Insert the micelle into the
holes. Fix the screws to the firm the metal board and then hang up the IP camera on the wall.
User Manual
HRT008IP
pag.6www.hrcctv.com
1.2.2With Bracket
•You can install the IP camera with the bracket together on the wall or ceiling.
Connect the bracket to the IP camera and then lock firmly. You can adjust the IP camera to the
corresponding angle and then lock the button firmly.
•Place the IP camera with the bracket on the table. Or you can follow the steps in c 1.2.1
User Manual
HRT008IP
www.hrcctv.com pag.7
1.3 IP CAMERA POWER CABLE CONNECTION
Connect the power adapter to the IP camera power port. You can see the power indication light becomes
on.
Connect network cable to the network port
Note: This series IP cameras has built-in micro phone. You can also connect to external micro phone or
speaker (optional).
User Manual
HRT008IP
pag.8www.hrcctv.com
1.4 SYSTEM REQUIREMENT
This series IP cameras has the following system requirement.
•Processor
Pentium 800MB or higher（Pentium 4, 2.4 GHz or higher recommended ）
•RAM
256 MB or higher
•Display card resolution
1024×768 or higher/16-bit color or higher/16M display memory or higher/DirectX9.0c or higher
•OS
Microsoft Windows 2000, Windows XP,Vista.
•Network Browser
Internet Explorer 5.X or 6.X. DirectX 8.1 or higher.
•Network protocol
TCP/IP
•Network port
10/100Mbps internet.
User Manual
HRT008IP
www.hrcctv.com pag.9
1.5 TECHNICAL SPECIFICATION
Model
Parameter
HRT008IP
CCD 1/6” CMOS
Pixel 300000 pixels
Resolution 380 TV line
Lens spec Fixed focus: 2.9mm/F2.0
Angle: 51°
Illumination 1 Lux/F2.0
S/N 50dB
Gamma Correction 0.45
Gain control Auto
BLC Auto
Electronic shutter Auto 1 / 25 ~ 1 / 15000
Video compression H.264
Video compression resolution VGA / CIF / QVGA / QCIF / QQVGA
Video frame rate Max 25f/s (adjustable)
Video Bit rate 32K~ 1Mbps (Adjustable)
Video motion detection 22x18, six levels
Audio compression G. 711 / PCM
Audio bit rate 64Kbps / 32Kbps / 10.2Kbps
Audio Built-in MIC and speaker
Cable network 1-ch 10/100Mbps internet
PTZ Pan 0 ~ 130° / tilt : 0 ~ 70°
Power compensation 5 VDC
Power consumption 3 W
Working environment Temperature: 0~ +50°C; humidity: 20~80%
Dimension 110 Øx110mm
Weight 330g
Installation Support various installation such as mount or rack mount
Main processor Embedded SOC media processor
OS Embedded linux
Network browser access Built-in web server
Safety Passwork protection. Support multiple-level user and group management
Max access amount Support max 10 users to visit at the same time.
User Manual
HRT008IP
pag.10 www.hrcctv.com
1.6 WIRE NETWORK
1.6.1Connect to LAN via internet port
You can connect the IP camera to the LAN via hub or switcher.
2. CONTENTS OF CD-ROM
•HR-EPSS BASIC: central management software basic version.
•HR-EPSS BUSINESS: central management software server / client version business with
smartphone compatibility.
•HR-MOBILE PSS: software for smartphone and PDA phones.
•HR-PLAYER: playback and AVI converter software.
•ITA manual – ENG manual.
•ENG manual for HR-ENG EPSS BASIC.
•ENG manual for HR-ENG EPSS BUSINESS.
•Web browser internet explorer.
•AUTOSEARCH: software for detection of IP devices.
3. SEARCH FOR DEVICES ON THE NETWORK
Can start the software “AUTOSEARCH” in support , to immediately detect the IP address of IP devices
installed. If necessary, to change the IP address entering the user name (default: admin) and password
(default: admin) .
Tabla de contenidos
