TW-800-EXS
1
■General outline
This instruction manual describes "TW-800R-EXS" (hereinafter referred to as "receiver").
"TW-800R-EXS" is a receiver with RS-232C serial output specification of TW-800 series.
The RS-232C output extension unit is mounted to "TW-800R". Also, the receiver can communicate with
multiple TW-800T (hereinafter referred to as transmitter).
This instruction manual mainly describes the functions of the extension unit. For details about the functio
ns of "TW-800R" and "TW-800T", please refer to the "TW-800R Instruction Manual".
<Feature>
◆The receiver can communicate with multiple transmitters by doing “pairing”.
The number of transmitters which can register pairing to one set of a receiver does not have restriction.
Receiver doesn’t remember ID number of transmitter. (It cannot read from a receiver ID of the transmitter which is
registered pairing, and how many set pairing is registered.)
◆Receiver outputs the RS-232C data receiving from transmitter for special protocol.
Receiver sounds a buzzer simultaneously, when doing RS-232C output and it turns on a relay output.
(Buzzer sounds or not and relay out time is set by DIP switch)
◆The RS-232C output from a receiver is performed by effluence. A flow control (RTS/CTS) is performed with
connection apparatus.
*"Pairing" used within this operation manual means the work which registers a transmitter and a receiver.
