Product Description

The Digidim 474 is a four-channel ballast controller fitted

with high-inrush relays rated at 16 A per channel, which

handle short, high-peak currents during switch-on of loads.

The outputs can be configured to match common ballast

control loads including 1–10V, DSI®, and DALI-broadcast.

The outputs can be configured independent of, or paired

with, a relay channel.

The unit can operate with either a Helvar Digidim or

Imagine lighting control system and is DIN-rail mounted for

ease of installation.

4-Channel Ballast Controller (474)

Installation and User Guide

Control Panel

Installation

Cable Cable Type

DALI 2-wire mains-rated, 0.5 mm² to 1.5 mm²

Max. length 300 m (with 1.5 mm² cable). Example: Belden 8471.

Mains cable / Dimmed outputs Max. 2.5 mm² stranded (4 mm² solid).

SDIM/DMX Low-loss RS485 Type (multistranded, twisted and shielded). Note: One twisted pair for

A and B (85 Ω to 100 Ω impedance), one core or twisted pair for 0 V, and shield for screen.

Size: 0.22 mm² to 1.5 mm². Core: 3 or 4 + Screen. Max. length 1000 m (low-loss

cable). Example: Belden 8102 or Alpha 6222C.

Override 2-wire, 0.5 mm² to 1.5 mm². Max. cable length 50 m.

• Install the unit horizontally to allow for heat dissipation.

• Any enclosure must provide adequate cooling ventilation.

• Do not connect DALI and SDIM/DMX at the same time.

• Isolate the mains supply before installation.

• The external supply must be protected: 6 A MCB max.

• All DALI and mains cabling must be 230 V mains rated.

Position & Ventilation

Electrical

• For installation in a restricted access location only.

Location

DALI

SDIM/DMX

Override

Mains

Supply

Ballast Outputs

Relay Terminals

‘Status’

Display

It has an intuitive LED segment display and push buttons

known as the ’Control Panel’, for monitoring, manual

configuration and control purposes.

The Control Panel comprises:

• A 3-digit, 7-segment LED display

(normally showing device activity)

• Two buttons (‘up’ and ‘down’) to

the right of the display, to view and

configure parameters

DSI®is a registered trademark of Tridonic GmbH.

Helvar | Data is subject to change without notice. www.helvar.com

Contents

Product Description i

Installation i

Connections 1

Power Up 2

‘Status’ Display 2

Menu 3

Configuration 4

Troubleshooting and Error Messages 5

Important Considerations 5

DALI Physical Selection 6

Quick Start Guide 7

Technical Data 8

1Helvar 474 4-Channel Ballast Controller: Installation and User Guide

Connections

(100–240) VAC

DALI

SDIM/DMX OVERRIDE

Ballast Outputs

Relay Outputs

Mains Supply

DA- DA+

A0VSCBTERM OVR0V C0 C0C0 C0C1 C3C2 C4

L N SC

SDIM/DMX

i = SDIM or DMX data cable (from previous device)

ii = SDIM or DMX data cable (to next device)

iii = Link for termination (if unit is at end of SDIM/DMX cable line)

Note: Keep unscreened wire lengths to a minimum.

OverrideMains Supply & DALI

Notes: Functional earth connection used for DALI/SDIM/DMX

screens only.

Do NOT connect DALI and SDIM/DMX at the same time. Input for override

Note: Maximum cable length = 50 m.

Close switch to

cause level override

DALI

Devices

Screen

(if required)

Mains Supply DALI

ii i

iii

SDIM or DMX

Vin < 1.5 V

Ishort = 1 mA

1–10 V

(+) (+) (+) (+)

(–)

(–) (–) (–) (–)

(–)

(+)

Ballast Outputs

Helvar EL-sc ballast

Helvar iDim

(DALI) ballast

2 Helvar 474 4-Channel Ballast Controller: Installation and User Guide

(100–240) VAC

‘Power’ indicator

The ‘Power’ indicator (top segment of the middle digit) is

always on when the 474 ‘Status’ display is active.

‘SDIM/DMX Activity’ indicator

The ‘SDIM/DMX Activity’ indicator (centre segment of the

middle digit) is normally off, and flashes on intermittently

if any SDIM/DMX activity (communications) is directed to a

channel within the ballast controller.

Output mimics

The output mimics (1, 2, 3 and 4) are illuminated when the

relays/outputs are on, and not illuminated when the relays/

outputs are off.

Key and LED Descriptions:

Power Up

‘Status’ Display

During power up, the following sequence is displayed on the LED Control Panel.

Each display is held for one second. At the end of this sequence, the ‘Status’ display appears.

Start-Up Sequence:

The ’Status’ display is the default view in operation. It is the starting point for navigating and configuring the 474.

1. All segments on 2. Product model 3. Software version

0.5 s 0.5 s 0.5 s

‘Power’

indicator

Output

mimics:

SDIM/DMX

activity indicator

‘Up’

button

‘Down’

button

Hardware

(wired)

override

indicator

‘Software

Override’

indicator

‘DALI

Power/

Activity’

indicator

‘Software Override’ indicator

The decimal point on the left is illuminated to indicate

software override from the 910 / 920 router. The middle

segment of the display will also flash.

‘DALI Power/Activity’ indicator

The DALI indicator (bottom segment of the middle digit)

is off if there is no DALI power, and on if DALI power is

present. If any DALI activity is directed to a channel within

the device, the indicator blinks off.

Hardware (wired) override indicator

The decimal point on the right is illuminated to indicate wired

override. The middle segment of the display will also flash.

4. Normal operation

(‘Status’ display)

3Helvar 474 4-Channel Ballast Controller: Installation and User Guide

Navigate through the 474

menus using the up/down

push buttons located on the

front of the unit.

The ‘Status’ display LEDs on

the front of the unit are lit in

the following way when power

is on:

Navigate the 474 menu to configure the unit.

Navigating the Menu

Back To ‘Status’ Display

Ten seconds of inactivity returns the 474 to the ‘Status’ display

screen.

Tip! You can also return to the ‘Status’ display by cycling through

all the menus.

Cycle through the menu:

1. Press both buttons simultaneously to cycle through the

menus.

Tip! To cycle through the menus quickly, keep holding down both

buttons.

Select the desired channel to modify:

2. At your chosen function, quickly press up or down button

to scroll through the channel destinations. These are the

channels that will be affected by the following settings.

Note: Select ‘ALL’ to alter all channels simultaneously.

Modify function settings:

3. Hold up or down buttons to alter the levels, settings, fade

times, output modes (dependent on function activated).

For more details, see the ‘Configuration’ section on

page4.

Note: LEDs blink if the value has been changed and not yet stored.

Save changes:

4. Hold both buttons together to save the change.

The LEDs will show 888 for one second to confirm setting is

stored.

Back To Previous Menu

To go back to the previous menu, do not

touch the buttons for five seconds.

5 s

10 s

4 Helvar 474 4-Channel Ballast Controller: Installation and User Guide

Configuration

Output Output Type Standard information

t0 0 / 10 V Switched. OFF = 0 V ; ON = 10 V

t1 1–10 sink EN 60929 Annex E, analogue control

t2 0–10 V source ANSI E1.3 analogue control

t3 N/A N/A

t4 N/A N/A

t5 DALI broadcast EN 62386

t6 DSI®Tridonic™ version 2

Various settings can be configured via the control panel.

‘Status’ Display / Set Channel Level

Set Channel Levels (0 % – 100 %) by using the push buttons in the ‘Status’ menu. Select the

channel(s) to change, and then hold the up or down button to alter levels. For more information,

see the ‘Quick Start Guide’ section on page7.

Note: You can access ‘Status Display / Set Channel Level’ mode while the device is in override mode,

but it is not possible to change the channel levels.

Set SDIM/DMX Address

Set the SDIM or DMX address for each channel.

Select bas to set the SDIM or DMX base address.

SDIM: 252 addresses available.

DMX: 512 addresses available.

Note: DMX updates are disabled while using manual control.

Set DALI Address

Set the DALI address for each channel. Select bas to set the DALI base address.

DALI: 64 addresses available.

Enable/Disable DMX

Enable or disable DMX from this menu.

When DMX is enabled (‘On’) it will use the SDIM address.

There is no channel select option; it is a global setting.

Note: DMX is disabled by default.

Output Table Selection

The outputs can be configured to match common ballast control loads via the ‘Output Table

Selection’ ( ) menu.

The following table gives a brief summary of output types.

Minimum Fade Time

Set the minimum fade time for the channels.

Select the minimum fade time for each channel individually or ALL channels simultaneously.

Minimum fade time can be set to: 1.00 second, 0.50 seconds, 0.15 seconds and 0.02 seconds.

5Helvar 474 4-Channel Ballast Controller: Installation and User Guide

Override Level

The override level can be configured for individual relay channels or ALL channels and ranges

from 0 to 100. It can be manually tested via the override test function (‘Ort’)

Note 1: When SDIM/DMX is connected, the override settings in the router (configured using Helvar

Designer software) will take precedence over the device’s override settings unless you

configure the software to use the device override settings.

Note 2: When the unit is running in override, the left decimal point is illuminated and the middle

digit of the screen flashes in the ‘Status’ display.

Channel Pairing

The output and relay channels are paired by default in a simple, one-to-one format.

Configure the pair, or separate (‘SEP’) the channels as required.

Note: Currently it is not possible to set channel pairing using Designer software. All channel pairing

must be manually configured at the device.

Override Test

Test that the override level (set in the previous mode) functions as required, by choosing ON or

OFF. The unit performs as if an override has been caused by the override input connection.

Note 1: By switching this setting to ON, it will not be possible to manually edit the channel levels in

the ‘Status Display / Set Channel Level’ menu.

Note 2: To change the channel levels, ensure that override is switched off.

Restore to Factory Default

Hold the up or down buttons for 10 seconds in this menu.

The decimal points will light up in sequence, and then all LEDs will be on for 1 second to

confirm that factory settings have been restored.

Note: Restore to Factory Default will permanently delete all the existing manually configured

settings.

Communications Error (SDIM/DMX only)

ErCindicates a problem with the SDIM or DMX communications. Check wiring and

terminations. Make sure no two channels have the same addresses on the network, and that

the SDIM/DMX mode is selected correctly.

Outputs Error

Er0indicates a problem with the output stages. Please contact Helvar Support for assistance.

Troubleshooting and Error Messages

If an error occurs, please contact Helvar Support (see www.helvar.com for details).

These details may be of assistance should an error message be displayed:

• Do not connect DALI and SDIM/DMX at the same time.

• If DMX does not work, make sure that it has been switched on in the dMX menu.

Important Considerations

6 Helvar 474 4-Channel Ballast Controller: Installation and User Guide

Note 1: Use the Helvar remote control unit with a Digidim control device to put the device into ‘Physical Selection’ mode. Refer

to the ‘ Digidim Lighting Control – Designing, Specifying and Installing’ System Manual.

Note 2: The ‘Physical Selection’ display is identical to the ‘Status Display / Set Channel Level’ display, except for the decimal

point flashing.

1. Put the device into physical selection mode.

The centre decimal point on the display screen will flash to indicate that the device has entered ‘Physical

Selection’mode.

2. From the control panel, repeatedly press ‘up’ or ‘down’ button to scroll between channels.

The selected channel mimic (s) will flash.

3. To physically select the channel, hold the ‘up’ or ‘down’ button.

The centre decimal point will stop flashing for two seconds to indicate a successful programming.

4. Repeat step 2 and 3 for each channel, as necessary.

5 End ‘Physical Selection’ mode (at the device).

The ‘Status’ display will appear.

DALI Physical Selection

Physical selection mode is activated using a Helvar remote control unit. It allows loads and controls to be grouped together

without the use of programming software. Refer to the equipment instructions for details.

Follow these steps to use the module to identify a piece of equipment using physical selection mode.

7Helvar 474 4-Channel Ballast Controller: Installation and User Guide

Quick Start Guide

474 Power On

Navigation

Notes

Back to ‘Status’ display

Output table

Select ALL channels

Variable level notice

Separate channel

Set DALI or SDIM/DMX base addresses

Status /

Set Channel

Level

Set SDIM

or DMX

Address

Set DALI

Address

Enable

DMX

Output mode

selection

Fade Time

Channel

pairing

Override

Level

Override

Test

Restore to

Factory

Default

Return to

Status

Mode

10 seconds

All LEDs flash.

Reset complete.

See ‘Output table’ (on this page)

When the desired level has been set, wait one second

for the ‘Status’ display to reappear.

Press both buttons at the same time to

cycle through the menu.

Press up or down button to scroll

through the channel destinations.

Hold up or down button to alter the

levels, settings, fade times, output

modes (dependent on active mode).

Hold both buttons together to store the

setting.

Where available, select ‘ALL’ to set all

available channels.

A UArlevel notice occurs in certain

modes if you are changing levels for ALL

channels (via the ALL function) but the

individual channel levels vary.

In ChP, select SEP to separate the

selected paired channel

From the Add menu, select bAS to

set the DALI base address.

From the AdSmenu, select bAS to

set the SDIM or DMX base address.

Output Output type

t 0

0–10 V [Switched. OFF = 0 V ; ON = 10 V]

t 11–10 V sink

t 20–10 V source

t 3N/A

t 4N/A

t 5DALI broadcast

t 6DSI®

8 Helvar 474 4-Channel Ballast Controller: Installation and User Guide

Dimensions

160

(100–240) VAC

Technical Data

Doc. 7860244,

issue 9, 2022-02-24

Connections

Mains/relay/output: Solid core: up to4 mm²

Stranded: 2.5 mm²

DALI: 0.5 mm² – 1.5 mm²

Max.length: 300 m

@1.5mm²

SDIM/DMX: 0.22 mm² – 1.5 mm² low-loss

RS485 type (multistranded,

twisted and shielded).

Max.length: 1000m (low-loss

cable). Examples: Belden8102

or Alpha6222C.

Note: One twisted pair for A

andB (85Ω to 100Ω impedance),

one core or twisted pair for 0V,

and shield for screen.

Power

Mains supply: 100 VAC – 240 VAC (nominal)

85 VAC – 264 VAC (absolute)

45 Hz – 65 Hz

Power consumption: 2.4 W (minimum) to 11 W

(alloutputs fully loaded)

External protection: The mains supply must be

protected at 6 A maximum.

The relays must be

protected by a 16 A Type C

MCB maximum.

DALI consumption: 2 mA

Inputs

Communication: DALI, SDIM and DMX

Override: Wired override input

User interface: 2 push buttons for

configuration

Outputs

0–10 V: Source 10 mA

1–10 V: Sink 100 mA

DALI/DSI®: (50 ballasts) Source 100 mA

Relays

Channels: 4

Relay contacts: High inrush (800A at 200 µs),

single pole normally open (SPNO)

Max. load per contact: 16 A resistive/incandescent;

10AHID (cosy=0.6).

For ballasts, quantity is

limited by MCB: refer to the

manufacturer’s data.

Operating and storage conditions

Ambient temperature: 0 °C to +40 °C

Relative humidity: Max. 90 %, noncondensing

Storage temperature: –10 °C to +70 °C

Mechanical data

Dimensions: 160 mm × 90 mm × 58 mm

Housing: DIN-rail case; 9U

Weight: 280 g

Mounting: DIN rail (installation in

switchgear/controlgear cabinet)

IP code: IP30 (IP00 at terminals)

Conformity and standards

EMC emission: EN 55015

EMC immunity: EN 61547

Safety: EN 61347-2-11

DALI: According to DALI standard IEC

62386, with Helvar additions

SDIM: According to Helvar SDIM

protocol

DMX: DMX512-A protocol

(max.refresh rate: 33Hz)

Isolation: All connectors are isolated

from each other, except for

SDIM/DMX to Override, and

ballast output 1–2 to ballast

output3–4.

Environment: Complies with WEEE and

RoHS directives.

Otros manuales para 474

Tabla de contenidos

Otros manuales de Controladores de HELVAR

HELVAR

HELVAR INTELLIGENT LCM-478 Manual de usuario

HELVAR

HELVAR digidim 478 Manual de usuario

HELVAR

HELVAR 478 Manual de usuario

HELVAR

HELVAR 474 Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
