HELGI HMIMITBPRO Manual de programación
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
100 kg
700
700
1050
1350
1350
850
34 - 95”
1
HMIMITBPRO
ASSEMBLING MANUAL
ALLEN M8
ALLEN M6
CONTENIDO/CONTENTS/CONTENUTO/SISÄLLYS/CONTENU:
HERRAMIENTAS NECESARIAS/TOOLS NEEDED/ATTREZZI
NECESSARI/TARPEELLISET TYÖKALUT/OUTILS NÉCESSAIRES:
Spanner M10
Chiave M10
TENTE M10 (x4)
DIN 125 D10 + D8 (x16)
DIN 912 M6x20 (x12)
DIN 912 M8x25 (x4)
DIN 7380 M8 (x2)
2
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
ASSEMBLING MANUAL
HMIMITBPRO
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
1
2
x4
TENTE HEX M10
Spanner M10
Chiave M10
3
HMIMITBPRO
ASSEMBLING MANUAL
3
4
ALLEN M6
x12
4xM8x25mm DIN 912+washer/rondella M8
8xM6x20mm DIN 912+washer/rondella M6
ALLEN M8
ALLEN M6
x12
12xM6x20mm DIN 912+washer/rondella M6
HMIMITBPRO
ASSEMBLING MANUAL
4
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
6
1 2 3
SOLTAR Y AFLOJAR
RELEASE AND SLACKEN
RILASCIARE E RALLENTARE
VAPAUTA JA AVAA
RELÂCHER ET RELÂCHER
PRESIONAR
PUSH/SPINGI
TYÖNNÄ/POUSSER
MANTENER PRESIONADO
HOLD/TIENI
PIDÄ/MAINTENIR
5BOTTOM POSITION / ALTEZZA MINIMA
HOLD 2
SECONDS
CALIBRATING
CALIBRAZIONE:
TENERE PREMUTO
PER 2 SEC.
Table conguration/Tavolo
5
HMIMITBPRO
ASSEMBLING MANUAL
7
8
600,00
400,00
620,0 0
900,00
800,00
400,00
600,00
800,00
x12
4xM8 or 4xM6
ALLEN M8
ALLEN M6
Computer
Display Wi-Fi Access Point
HMIMITBPRO
ASSEMBLING MANUAL
6
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
DIAGRAMA ELÉCTRICO DEL MOTOR / ELECTRICAL DIAGRAM OF THE LIFTING SYSTEM / DIAGRAMMA DELL’IMPI-
ANTO ELETTRICO DI SOLLEVAMENTO / NOSTOJÄRJESTELMÄN TEKNINEN KAAVA
/ SCHÉMA ÉLÉCTRIQUE DU SYSTÈME DE REHAUSSE.
Input: AC 100V-240V, 1.500mA;
50/60Hz
Output: DC29V - 2A
Max. Load: 6.000N; IP44
Power Rating 24 DVC, Max: 2AMP
10
optional
x2
2xM8x30 DIN912 + Washer + Nut
2xM8x30 DIN912 + Rondella + Dado
x4
4xM6x20 DIN912 + Washer + Nut
4xM6x20 DIN912 + Rondella + Dado
ALLEN M6
ALLEN M8
9
7
HMIMITBPRO
ASSEMBLING MANUAL
