Headwall Nano-Hyperspec Instrucciones de funcionamiento
NANO
NANO-HYPERSPEC®
Installation and Operation Guide
NANO
2
Reproduction and Copyright Information
This document contains information which is Proprietary and Confidential. Any reproductions, adaptations, or
translations without prior written permission from Headwall Photonics, Inc. is strictly prohibited. All information
provided in this manual is believed to be accurate and reliable. No responsibility is assumed by Headwall Photonics, Inc.
for its use. Headwall Photonics, Inc. reserves the right to make changes to this information without notice.
Contact Headwall Photonics, Inc. for associated software license information on: Hyperspec© application software, Nokia
QT libraries, and LGPL Public License.
Contact information
Headwall Photonics
601 River Street
Fitchburg, MA 01420
TEL (978) 353-4100
FAX (978) 348-1864
e-mail: support@headwallphotonics.com
NANO
1
Nano-Hyperspec®Components ............................................................................ 3
Nano-Hyperspec®Airborne Package ..................................................................3
Nano-Hyperspec®Field Scanning Kit ................................................................3
Nano-Hyperspec®UAV packages ......................................................................3
Nano-Hyperspec®Options .................................................................................... 4
Lenses: .................................................................................................................4
Cables: .................................................................................................................4
Nano Power Connector Pin Out ..........................................................................4
Hyperspec®III Installation................................................................................... 7
System Requirements: .........................................................................................7
Disable Windows Functions and Services ..........................................................7
Drive Indexing .....................................................................................................................7
Disable Windows Defender .................................................................................................8
Windows Performance ........................................................................................................11
Windows Firewall ................................................................................................................11
Disable Services ...................................................................................................................12
Hyperspec® III Installation .................................................................................14
PIXCI(R) Driver ..................................................................................................................16
MT Software Suite ...............................................................................................................17
Microsoft Visual C++ .......................................................................................................20
MT SDK ........................................................................................................................... 21
Magnetic Field Mapper .....................................................................................................22
Xeneth Component Installation ........................................................................................23
Xeva Camera Installation .................................................................................................24
NovAtel USB Driver Installation .......................................................................................26
WinPcap Installation ...........................................................................................................27
Certificate of Compliance ...................................................................................................28
Firmware Upgrade ..............................................................................................29
Hyperspec®III Configuration - Nano................................................................. 33
Nano / Computer Connection .............................................................................33
Hyperspec®III Configuration .............................................................................36
NANO
2
Hardware Configuration. ...................................................................................................36
Button Dock Operation ......................................................................................38
Settings Configuration ........................................................................................................ 38
Settings_ Capture Tab .......................................................................................................39
Settings_Waterfall Tab .....................................................................................................39
Settings_Spectrograph Tab ...............................................................................................40
Settings_Post Grab Tab ....................................................................................................41
Settings_Sensor Tab ......................................................................................................... 42
Calibration ...........................................................................................................................42
Live Video .............................................................................................................................43
GPS. ......................................................................................................................................43
Hyperspec®III Operation.................................................................................... 45
Log Dock ............................................................................................................45
Button Dock Controls: .......................................................................................46
Live Video .............................................................................................................................46
Live Video Control Buttons: ............................................................................................ 47
Motion ...................................................................................................................................47
Calibration ...........................................................................................................................48
Capture .................................................................................................................................49
Manual Capture ................................................................................................................49
Automatic Capture ............................................................................................................ 49
File Transfer .........................................................................................................................49
NANO
1-3
Chapter 1 Nano-Hyperspec®Components
Nano-Hyperspec®units can be made with a variety of lenses, filters or mounted on specific platforms, to meet customers’
specific requirements. The following list identifies the three primary configurations for the Nano-Hyperspec®:
Nano-Hyperspec®VNIR 400-1000nm C-Mount unit
Nano-Hyperspec® Airborne Package
Nano-Hyperspec®Field Scanning Kit.
Not all components may have been ordered at one time. Locate the packing list of included components beneath the foam
in the shipping case lid, to identify the purchased components.
NANO-HYPERSPEC®AIRBORNE PACKAGE
GPS IMU Kit
Hyperspec® III Acquisition and Display Software, Airborne Application, DEMS, radio calibration, software
Hyperspec®III Ortho Rectification Software
NANO-HYPERSPEC®FIELD SCANNING KIT
Tripod and Rotation Stage, includes battery, tripod, and rotation stage
Two (2) 14.4v, 3.4 wh, Smart Lithium-Ion Batteries
Wireless portable Router
NANO-HYPERSPEC®UAV PACKAGES
Nano-Hyperspec®VNIR Concentric Imaging Spectrometer Fully Integrated on the X6 UAV
Nano-Hyperspec®VNIR Concentric Imaging Spectrometer and LIDAR Fully Integrated on the G4 UAV
NANO
1-4
Nano-Hyperspec®Options
LENSES:
The following table contains the list of standard lenses available with the Nano-Hyperspec®. Additional focal lengths are
available upon request and approval by Headwall Photonics.
CABLES:
3 meter CameraLink Cable
Cat6 Ethernet cable, 5 ft.
Power cable/Nano-Hyperspec®
NANO POWER CONNECTOR PIN OUT
The following table identifies the wires coming from the Nano power connector.
Table 1-1. VIS-VNIR Lenses, Compact Barrel
Focal Length Description
4.8 mm F/1.8, 400-1000nm, Compact Barrel, C-Mount, 4.8 mm
8 mm F/1.4, 400-1000nm, Compact Barrel, C-Mount, 8 mm
12 mm F/1.4, 400-1000nm, Compact Barrel, C-Mount, 12 mm
17 mm F/1.4, 400-1000nm, Compact Barrel, C-Mount, 17 mm
23 mm F/1.4, 400-1000nm, Compact Barrel, C-Mount, 23 mm
35 mm F/1.9, 400-1000nm, Compact Barrel, C-Mount, 35 mm
70 mm F/2.2 400-1000nm, Compact Barrel, C-Mount, 70 mm
Table 1-1. Power Connector Pin Out
Pin # Function IO Format Wire Color Comments
1 Ground Power Black
NANO
1-5
2 Voltage Input Power Red Voltage Input Range
+9.5V to +25V
3 Ground Power Black
4 Voltage Input Power Red Voltage Input Range
+9.5V to +25V
5 Voltage Output Power Blue Voltage output is +5V
with a maximum
current of 250mA
6 Voltage Output Return Power Black
7 GPIO3 General Purpose IO Brown 0 to 5V range
8 GPIO2 General Purpose IO Yellow 0 to 5V range
9 GPIO1 General Purpose IO Purple 0 to 5V range
10 GPIO0 General Purpose IO Orange 0 to 5V range
Table 1-1. Power Connector Pin Out
Pin # Function IO Format Wire Color Comments
NANO
1-6
THIS PAGE INTENTIONALLY LEFT BLANK.
HYPERSPEC®III INSTALLATION
2-7
CHAPTER 2 HYPERSPEC®III INSTALLATION
2.1 SYSTEM REQUIREMENTS:
The Compact Hyperspec®Data Processing Units (cHDPU) and Hyperspec®Data Processing Units (HDPU) ship with the
software installed, configured and tested for a specific sensor. The Hyperspec®III installation steps are used if the sensor
is different from that associated with either data processing unit, or if the user is connecting a computer other than the
HDPU or cHDPU, to the Headwall sensor.
NOTE
Prior to beginning software installation, ensure that you have administrative
privileges for the computer where the software is to be installed. Also, have the
necessary license and activation keys available for the installation and set up process.
Unless directed otherwise, do not change installation directories from those identified
in the default path.
• Windows 7, 8, 10, 64 bit systems, with administrator privileges.
• Minimum of 1.5 GB free memory is needed.
• Specific, identified services and functions disabled.
2.2 DISABLE WINDOWS FUNCTIONS AND SERVICES
Prior to installing Hyperspec®III there are multiple services and functions that need to be disabled. These steps will allow
the operating computer to provide the full functionality of Hyperspec®III. These steps need not be done if a Headwall
cHDPU or HDPU computer is used, the Windows functions and services are disabled at the factory during the installation
and configuring process.
With the computer powered ON and the user logged on with administrative privileges, perform the following steps.
2.2.1 Drive Indexing.
(1) Click the Windows Start icon and select My Computer.
(2) Right click the local drive.
(3) When the pop-up opens select the General tab.
(4) Uncheck the lower box, “Allow files on this drive to have contents indexed....”, as shown in the following figure.
HYPERSPEC®III INSTALLATION
2-8
Figure 2-1. Disable Indexing.
(5) Click Apply, then click OK.
(6) Close the Properties window then close the Windows Explorer window.
2.2.2 Disable Windows Defender.
(1) Click Windows Start icon and type Defender into the search box.
