head rush technologies UM-01 Manual de usuario
NOTE TO INSTALLERS
Always Read Instrucons Before Use
The Operator Manual contains informaon relang to the
proper use of the Universal Mount and includes all product
and warranty informaon. This document may only be
removed by the end user. Ensure that this Operator Manual
is readily available to operators at all mes.
Head Rush Technologies Universal Mount Operator Manual
P/N 00070045003
Head Rush Technologies products are covered by a number of patents, including
U.S. Patents 8,490,751; 8,851,235; 9,016,435; 8,851,235 and D654,412
& corresponding patents/applicaons in the USA and in other countries worldwide.
UNIVERSAL
MOUNT
Operator Manual
Model: UM-01
ACCESSORY OF THE
3
www.headrushtech.com |+1-720-565-6885
TABLE OF CONTENTS
SAFETY INFORMATION 5
Symbols Used in this Manual 5
WARRANTY CONDITIONS 6
Customer Responsibility 6
DESCRIPTION 8
SPECIFICATIONS 9
UNIVERAL MOUNT PARTS 10
UNPACKING 11
Precauons 11
Receipt of the Universal Mount 11
INSTALLATION 12
Precauons 12
Standards 12
Anchor Points 12
Secondary Connectors 13
Selecng a Locaon 13
Mounng 13
Mounng Points 14
Strap Mounng 14
Bolt-Hole Point Mounng 15
OPERATION 16
Operator Training 16
INSPECTION & MAINTENANCE 17
Service Life 17
Weekly Inspecon 17
Safety Precauons 17
Inspecon Procedure 17
Wear Limits 17
MANUFACTURER’S DETAILS 18
Read Before Installaon & Operaon
Failure by the installer or operator to heed any and all instrucons, warnings,
and cauons for the correct installaon, operaon, care, and maintenance of the
Universal Mount may result in serious injury and/or death.
The Universal Mount and associated equipment is designed and specied for use
in the recreaonal climbing industry as a climbing anchor. Use of the Universal
Mount for any purposes other than that intended by the manufacturer is not
permied.
Owners and operators of the Universal Mount are responsible for the safety and
supervision of any person using the Universal Mount. Owners and operators are
required by the manufacturer to read, understand, and follow all instrucons in
this Operator Manual regarding the correct installaon and operaon of the Uni-
versal Mount and are required to undergo training in the correct installaon and
operaon of the device and associated equipment prior to use.
These instrucons must be made readily available to the operator at all mes. Pri-
or to installaon and use, all owners and operators must have read and shown to
have understood all instrucons, labels, markings, and safety informaon pertain-
ing to the installaon, operaon, care, and maintenance of the Universal Mount,
its component parts, and all associated hardware. Failure to do so may result in
equipment damage, serious injury, and death.
This manual does not cover the TRUBLUE Auto Belay system. Refer to the
TRUBLUE Auto Belay Operator Manual.
Health and Safety
Owners and operators must abide by all standards, internaonal, federal, state and
provincial laws, and any specic health and safety regulaons pertaining to the
installaon and use of this product.
Site Rescue Plan
Owners and operators must have devised an emergency rescue plan for any
climber in distress at all sites operang Universal Mounts. Operators must inform
users of the Universal Mount of the procedures for rescuing a climber in distress
prior to climbing.
IMPORTANT SAFETY NOTICE
Climbing Is a Dangerous Acvity
4www.headrushtech.com |+1-720-565-6885
SAFETY INFORMATION
Symbols Used in this Manual
The following safety symbols are used throughout this manual to highlight po-
tenal dangers. One or more precauons may be associated with pracces and
procedures described within this manual. Failure to adhere to the precauons
highlighted can result in death, serious injury, and equipment damage.
Ensure that you read and understand all operang procedures related to the work-
ing environment and task you are undertaking.
DANGER
Indicates a hazardous situaon exists that, if not avoided, will
result in death or serious injury.
WARNING
Indicates a potenally hazardous situaon that, if not avoided,
could result in death or serious injury.
CAUTION
Indicates a potenally hazardous situaon that, if not avoided,
may result in injury or equipment damage.
NOTE
Indicates an acon that must be taken to ensure personal safety
and prevent damage to property or equipment.
CARE FOR THE ENVIRONMENT
Take care to minimize impact on the environment when carrying
out this procedure.
5
www.headrushtech.com |+1-720-565-6885
WARRANTY CONDITIONS
The Universal Mount is warranted against factory defects in materials and work-
manship, excluding specic eld replaceable wear parts, for a period of two (2)
years from date of purchase. This warranty applies only to the original purchaser,
and is conngent upon the owner/operator using and maintaining the device in
accordance with the instrucons, including the requirement to maintain regular
inspecon as described in all applicable manuals.
THIS WARRANTY IS IN LIEU OF OTHER WARRANTIES, EXPRESS OR IMPLIED,
AND ANY IMPLIED WARRANTY OF MERCHANT-ABILITY OR FITNESS FOR A
PARTICULAR PURPOSE IS HEREBY EXPRESSLY EXCLUDED.
The sole remedy for breach of this warranty, or for any claim in negligence or strict
liability in tort, is the repair or replacement of defecve parts at the discreon of
the manufacturer. Parts claimed to be defecve shall be returned to the factory,
transportaon prepaid, for inspecon to determine to its sasfacon that said
part(s) are defecve.
This warranty is null and void if parts other than genuine parts are used, or if any
modicaons or services have been performed on the device by anyone other
than an authorized Head Rush Technologies servicing agent. This warranty does
not cover damages resulng from normal wear and tear, abuse to the device, dam-
age in transit, or any other damage beyond the control of Head Rush Technologies.
Head Rush Technologies makes no warranes in respect to trade accessories or
component parts which are not made by Head Rush Technologies. This warranty
expressly excludes the replacement of specic eld-replace-able wear parts.
No person, agent, or distributor is authorized to give any warranty, other than the
one herein expressed, on behalf of Head Rush Technologies, or to assume for it
any liability pertaining to such products. Head Rush Technologies expressly dis-
claims any implied guarantee of merchant-ability, or claim as to whether the device
is suited for a parcular purpose. Purchaser agrees that Head Rush Technologies
shall not be held liable to purchaser/operator for damages of any kind, including
but not limited to, lost or projected prots, equipment down-me, or any losses
considered to be caused by non-operaon or servicing/re-cercaon downme
of the equipment.
Customer Responsibility
The following items are considered to be the responsibility of the Customer and
are therefore non-reimbursable under the terms of the warranty.
Roune maintenance and inspecon
Normal replacement of service and wear items
Replacements required because of abuse, misuse, or improper operaon of
equipment by the installer or operator
6www.headrushtech.com |+1-720-565-6885
Wearing or addional parts such as fasteners, straps, etc.
Normal deterioraon due to use and exposure
This warranty is subject to the following requirements of this Operator Manual,
manufacturer instrucons, and advice given by authorized Head Rush Technolo-
gies service technicians.
7
www.headrushtech.com |+1-720-565-6885
DESCRIPTION
The Universal Mount is a mounng device designed specically for use as a
climbing anchor. It is meant to be used on trees, poles, and climbing walls to pro-
vide an anchor point to mount a TRUBLUE® Auto Belay or other climbing anchor.
The Universal Mount is suitable for climber weights up to 150 kg (330 lbs).
To protect the longevity of the Universal Mount, installaon, care, and use of the Uni-
versal Mount must be carried out in accordance with the instrucons in this manual.
8www.headrushtech.com |+1-720-565-6885
SPECIFICATIONS
MODEL UM-01
DIMENSIONS 300 x 175 x 257 mm (11.8 x 6.9 x 10.1 in)
NET WEIGHT 2.95 kg (6.5 lbs)
MATERIALS Powder Coated Aluminium 6061-T6
MAX. CLIMBER WEIGHT 150 kg (330 lbs)
9
www.headrushtech.com |+1-720-565-6885
UNIVERSAL MOUNT PARTS
SPINE
BOLT HOLES (6)
BASE
MFG DATE
MOUNTING HOLES (2)
MOUNTING
STRAP SLOTS (2)
10 www.headrushtech.com |+1-720-565-6885
UNPACKING
Precauons
LEAVE THIS OPERATOR MANUAL ATTACHED TO THE UNIVER-
SAL MOUNT UNTIL INSTALLATION IS COMPLETE
The Operator Manual contains informaon relang to the proper use of the
Universal Mount and warranty informaon. The Operator Manual may only be
removed by the end user. Ensure this manual is readily available to Universal
Mount users at all mes.
Receipt of the Universal Mount
The Universal Mount is packaged in a recycled cardboard box containing:
1 x Universal Mount
1 x Operator Manual
11
www.headrushtech.com |+1-720-565-6885
