HBM PMX Manual de usuario
Quick Start Guide | Kurzanleitung | Guide rapide |
English Deutsch Français
PMX
Hottinger Baldwin Messtechnik GmbH
Im Tiefen See 45
D-64239 Darmstadt
Tel. +49 6151 803-0
Fax +49 6151 803-9100
www.hbm.com
Mat.: 7-2001.3259
DVS: A3259-4.0 HBM: public
03.2015
EHottinger Baldwin Messtechnik GmbH.
Subject to modifications.
All product descriptions are for general information only.
They are not to be understood as a guarantee of quality or
durability.
Änderungen vorbehalten.
Alle Angaben beschreiben unsere Produkte in allgemeiner
Form. Sie stellen keine Beschaffenheits- oder Haltbarkeits
garantie dar.
Sous réserve de modifications.
Les caractéristiques indiquées ne décrivent nos produits
que sous une forme générale. Elles n'impliquent aucune
garantie de qualité ou de durablilité.
Quick Start Guide | Kurzanleitung | Guide rapide
English Deutsch Français
PMX
2A3259-4.0 HBM: public PMX
English
1 Safety instructions 3........................................
2 Purpose of the manual 3....................................
3 Symbols on the device 4....................................
4 Mounting/Dismounting/Replacing 5..........................
4.1 Mounting tools and tightening torques 5.........................
4.2 Support rail mounting 6.......................................
4.3 Wall-mounting 10.............................................
5 Quick start 13...............................................
5.1 Preparing the measurement system 13..........................
5.2 Typical operating procedure 19.................................
5.2.1 Measurement example 19.....................................
5.3 Update software (PMX web server) 24...........................
Safety instructions
PMX A3259-4.0 HBM: public 3
1 Safety instructions
Important
Please follow the safety instructions in the PMX Ope
rating Manual, and in the separate "Safety Instruc
tions" document (enclosed with the device).
2 Purpose of the manual
This Quick Start Guide provides a quick summary of the
steps required to connect a PMX device to a PC and a
network, so that you can start to obtain measurement
results with the PMX device as quickly as possible.
An actual measurement example rounds off the Quick
Start Guide.
Important
This Quick Start Guide does not replace the detailed
PMX Operating Manual.
The information provided in this Quick Start Guide is
expanded on in greater detail in:
- the Operating Manual for the PMX Measuring Am
plifier System
- the PMX web server online Help
Symbols on the device
4A3259-4.0 HBM: public PMX
3 Symbols on the device
Symbol Meaning
Statutory waste disposal mark
Statutory mark of compliance with emission limits in electronic
equipment supplied to China.
CE mark
The CE mark is used by the manufacturer to declare that the
product complies with the requirements of the relevant EC
directives (the Declaration of Conformity can be found at
www.hbm.com
Take details in the operating manual into account.
CODESYS is a software platform for programmable logic
controllers. The license for CODESYS is already
implemented in WG001 basic housings.
Mounting/Dismounting/Replacing
PMX A3259-4.0 HBM: public 5
4 Mounting/Dismounting/Replacing
4.1 Mounting tools and tightening torques
Mounting Required tool Tightening torque
Fasten Rail-Clip to support
rail
M 2.5 hexagon socket
screw
Hexagon socket screw
driver
2.5 a.f.
1.0 - 1.2 Nm
Mounting DIN rail on hous
ing
M5 hexagon socket
screw
Hexagon socket screw
driver
3 a.f.
3 Nm
Mounting front panel
M2.5 Torx screws
Torx screwdriver
TX8 0.5 - 0.6 Nm
Mounting wall bracket
M4 hexagon socket
screw
Hexagon socket screw
driver
3 a.f.
1.5 … 2 Nm
Mounting side partes
M3 Torx screws
Torx screwdriver
TX10 0,8 … 1 Nm
Grounding screw on the
PMX
M4 Torx screws
Torx screwdriver
TX20 1,5 … 2 Nm
Mounting/Dismounting/Replacing
6A3259-4.0 HBM: public PMX
4.2 Support rail mounting
1
2
3
4
75 mm
3
B
A
C
D
Allen screw
3 mm a.f.
Fig. 4.1 Mounting on a support rail
► Undo the four back-panel screws (Torx T10) (1)
► Slide the side parts forward (2)
► Screw on the support rail mounting (Rail-Clip) (3) (ap
prox. 5 Nm) in a choice of four positions (Ato D) (two
positions for the 7.5 mm support rail)
► Screw the side panels (2) back on
► Hook the PMX device into the support rail (4)
Mounting/Dismounting/Replacing
PMX A3259-4.0 HBM: public 7
Important
Device damage caused by the PMX falling due to resis
tance in hooking/unhooking the PMX.
HBM recommends using a DIN support rail (DIN EN
60715), 15 mm in height. When using a smaller support
rail (7.5 mm high), it should be shimmed to make it easy
to hook/unhook the PMX device.
The 7.5 mm support rail can only be used in the top two
positions (A and B).
Attach the support rail mounting (Rail-Clip) to the DIN
rail
Allen screw
2.5 a.f.
At the time of delivery, the self-locking (2.5 mm a.f.) Allen
screws are unscrewed as far as the stop.
► Clip on the support rail mounting (Rail-Clip)
► Hand-tighten the self-locking Allen screw (1 - 1.2 Nm)
Mounting/Dismounting/Replacing
8A3259-4.0 HBM: public PMX
Important
Device damage caused by electromagnetic irradiation of
external devices.
Faulty measurements due to electromagnetic irradiation
from other devices.
To ensure adequate grounding for the PMX, the support
rail must be connected to a functional earth .
Both the DIN rail and the PMX must be free of paint, var
nish and dirt at the point of installation.
►Connect the PMX housing to ground via the grounding
screw.
