Operating Manual | Bedienungsanleitung |

Manuel d'emploi

English Deutsch Français

MX403B

1250 V Ut 3000 V

1000 V CAT II

600 V CAT III

2A3757-2.2 HBM: public MX403B

English

1 Introduction 3..............................................

2 Safety instructions 6........................................

2.1 Warning signs and danger symbols 6...........................

2.1.1 Symbols on the measurement module 7........................

2.2 Proper use 7................................................

2.3 Measurement categories 9....................................

2.4 Operating conditions 11.......................................

2.5 Maintenance, repair and modification 12.........................

2.6 Cleaning 13..................................................

2.7 Transportation, storage and disposal 14.........................

2.8 Qualified Personnel 15........................................

2.9 Working safely 15.............................................

2.10 System integration 19.........................................

3 Additional markings used 20.................................

4 Scope of delivery 21.........................................

5 Accessories 22..............................................

6 MX403B operation 27........................................

6.1 Preparatory measures and starting up 27........................

6.2 Connection/measurement 28...................................

6.3 Status Display 30.............................................

7 Specifications 31............................................

MX403B A3757-2.2 HBM: public 3

1 Introduction

QuantumX is a modular data acquisition system from

HBM for demanding measurement and test functions.

The different inputs acquire mechanical, electrical,

hydraulic and thermal measurands, such as force, strain,

torque, pressure, displacement, temperature, rotational

speed, acceleration, position, flow rate, voltage, etc.

The MX403B voltage measurement module can measure

voltages as high as 1000 V, as well as small differential

voltages at high electric potential.

The QuantumX family documentation basically com

prises:

SThe current operating manual for the voltage mea

surement module (available in printed form)

SA quick start guide for initial start-up (available in

printed form)

SData sheets for the individual modules and acces

sories

SThe QuantumX operating manual with connection

descriptions and possible system topologies and

states

SThe operating manual for the EtherCAT1) / Ethernet

Gateway CX27

SThe operating manual for data recorder CX22-W /

CX22

SA comprehensive online help with index and easy

search options which is available after the installation

1) EtherCAT®is a registered brand and patented technology, licensed by Beckhoff Automation

GmbH, Germany

4A3757-2.2 HBM: public MX403B

of a software package (e.g. QuantumX Assistant, cat

manEASY)

These documents can be found:

SOn the QuantumX system CD supplied with the device

SAfter installing the QuantumX Assistant on the hard

drive of your PC

SUp-to-date versions are always available from our

Internet site at http://www.hbm.com/hbmdoc

Notice

When working with the MX403B, always take note of the

standard operating manual (I2322) as well.

The high level of protection of the MX403B is guaranteed

by consistent development in accordance with the latest

conditions specified in the measuring equipment stan

dards IEC 61010-1:2010+Cor.:2011 and

IEC 61010-2-030:2010+Cor.:2011, as well as by VDE

certification and production monitoring.

The MX403B has four insulated differential measurement

channels for directly measuring voltages up to 1000 V DC

or 1000 V rms AC.

The different measuring ranges allow the acquisition of

high voltages to remote ground, as well as the measure

ment of small differential voltages at high potential to

remote ground.

The connection is made with 4 mm safety lab jacks,

19 mm pitch, suitable for standardized BNC adapters.

Each channel is equipped with a programmable amplifier,

analog reconstruction and antialiasing filters, a 24bit

ADC and digital filters.

MX403B A3757-2.2 HBM: public 5

6A3757-2.2 HBM: public MX403B

2 Safety instructions

This measurement module is built and tested in accor

dance with EN 61010, Safety Requirements for Electrical

Equipment for Measurement, Control and Laboratory

Use, and was in perfect condition when it left production.

To maintain this condition and ensure risk-free operation

(reducing residual risks, EN 610101:2010 17 c), the user

must comply with the instructions and warning notices

contained in this operating manual.

2.1 Warning signs and danger symbols

Important instructions for your safety are specifically iden

tified. It is essential to follow these instructions in order to

prevent accidents and damage to property.

DANGER

This marking warns of an imminently threatening danger

ous situation which - if safety requirements are disregarded

- will result in death or serious physical injury.

Notice

This marking draws attention to a situation which - if dis

regarded - can result in damage to property.

MX403B A3757-2.2 HBM: public 7

2.1.1 Symbols on the measurement module

Take details in the operating manual into account

Read and comply with the operating manual.

2.2 Proper use

The MX403B voltage measurement module fits perfectly

into the modular QuantumX series and is solely used to

measure high differential voltages or differential voltages

at high potential to remote ground, within the ratings

stated in the specifications.

The device is not intended for use as a safety compo

nent. Please also refer to the section: "Additional safety

precautions".

Proper and safe operation requires proper transportation,

correct storage, siting and mounting, and careful opera

tion.

Everyone involved with siting, starting up, or operating

the measurement module must have read and under

stood the operating manual and in particular the technical

safety instructions.

In the interests of safety, the measurement module

should only be operated by qualified personnel (see

below) and as described in the operating manual. It is

also essential to comply with the legal and safety require

ments for the application concerned during use. The

same applies to the use of accessories.

8A3757-2.2 HBM: public MX403B

DANGER

If the measurement module is not used as intended, the

protection provided by the measurement module may be

impaired.

DANGER

If the measurement module is used outside the ratings,

the protection provided by the measurement module may

be impaired.
