Harman JBL PULSE Manual de usuario

Service Manual

PULSE

Wireless sound system with rechargeable battery, Bluetooth® and custom LED light show.

Released EU 2013 Harman International Rev 3, 08/2015

8500 Balboa Boulevard

Northridge, California 91329

OWNER’S MANUAL 2

EXPLODED VIEW AND PARTS 7

PACKING VIEW AND PARTS 8

SPARE PARTS LIST 9

DISASSEMBLY PROCEDURE 10

RESET PROCEDURE 26

SPECIFICATION SHEET 27

CONTENTS

Pulse

JBL

PULSE Service Manual

Page 2 of 38

Pulse

Quick Start Guide

Guide de démarrage rapide

Battery level indicator

JBL Pulse

JBL

PULSE Service Manual

Page 3 of 38

Pulse

Quick Start Guide

Guide de démarrage rapide

JBL MusicFlow App

JBL MusicFlow

JBL

PULSE Service Manual

Page 4 of 38

Pulse

Quick Start Guide

Guide de démarrage rapide

LED Behavior

Pairing mode

Product is ON

Product is OFF

Not connected

Power

Light is ON

Connected

Light is OFFBlack light Mode

Bluetooth

Blinking

Drag

Press

Faites glisser

arrastrar

arrastar

ziehen

trascinare

slepen

dra

vetää

тащить

dra

Træk

ドラッグ

드래그

拖动

拖動

Appuyer

Pulsar

Premir

Drücken

Premere

Indrukken

Trykk

Paina

Нажать

Tryck på

Tryk

押す

누르기

按1 次

按一下

JBL

PULSE Service Manual

Page 5 of 38

• Power supply: 5VDC, 2.3A

• Transducers:1.5”(40mm)x2

• Amplifier power: 6W X2

• Frequency response:105~20kHz

• Signal-to-noise ratio: 80dB

• Dimensions (Dia x H): 79mmx182mm

• Battery type: Polymer Li-ion

3.7V/4000mAh

• Input connections:3.5mm

• Listening time on battery power: 5 hours

• Battery charge time: 3 hours

• Bluetooth transmitter frequency range:

2.402 – 2.480 GHz

• Bluetooth transmitter power: 0 ~ 4dBm

• Bluetooth transmitter modulation:

GFSK, π/4 DQPSK, 8DPSK

• Alimentation électrique: 5 VCC, 2,3A

• Transducteurs: 40 mm (1,5") x 2

• Puissance de l'amplificateur: 6 W x 2

• Plage de fréquences: 105~20 kHz

• Rapport signal sur bruit: 80 dB

• Dimensions (Dia x H): 79 mm x 182 mm

• Type de batterie: lithium-ion polymère

3,7 V / 4000 mAh

• Connexions d'entrée : 3,5 mm

• Durée d'écoute sur batterie : 5 heures

• Temps de charge de la batterie :

3 heures

• Bande de fréquences de l'émetteur

Bluetooth : 2,402 – 2,480 GHz

• Puissance de l'émetteur Bluetooth :

0 ~ 4 dBm

• Modulation de l'émetteur Bluetooth :

GFSK, π/4 DQPSK 8DPSK

• Alimentación: 5VDC, 2,3A

• Transductores: 1.5"(40mm)x2

• Potencia de amplificación: 6W X2

• Respuesta de frecuencia: 105~20kHz

• Relación señal-ruido: 80dB

• Dimensiones (Dia x A) 79mmx182mm

• Tipo de batería: Iones de polímero de

litio 3.7V/4000mAh

• Conexiones de entrada: 3.5 mm

• Tiempo de audición con alimentación a

batería: 5 horas

• Tiempo de carga de la batería: 3 horas

• Alcance de frecuencia del transmisor

Bluetooth: 2.402 – 2.480 GHz

• Potencia del transmisor Bluetooth:

0 ~ 4dBm

• Modulación del transmisor Bluetooth:

GFSK, π/4 DQPSK, 8DPSK

• Fonte de alimentação: 5V CC, 2,3A

• Transdutores: 40mm (1,5") x2

• Potência do amplificador: 6W x2

• Resposta em frequência: 105~20kHz

• Relação sinal/ruído: 80dB

• Dimensões (Diâm. x A): 79mm x 182mm

• Tipo de bateria: Polímero de iões de lítio

3,7V/4000mAh

• Ligações de entrada: 3,5mm

• Tempo de audição com bateria: 5 horas

• Tempo de carregamento da bateria:

3 horas

• Gama de frequências do transmissor

Bluetooth: 2,402 – 2,480GHz

• Potência do transmissor Bluetooth:

0 ~ 4dBm

• Modulação do transmissor Bluetooth:

GFSK, π/4 DQPSK, 8DPSK

Pulse

Quick Start Guide

Guide de démarrage rapide

JBL

PULSE Service Manual

Page 6 of 38

UnRegistered

JBL

PULSE Service Manual

Page 11 of 38

JBL PULSE EXPLODED VIEW

JBL PULSE PACKING VIEW AND PARTS

JBL Pulse spare parts

Ref.NO. Part Name_English Part .NO Description QTY per Corresponding PCBA P/N

1 Grille MM-HM08000100-B

SPCC T=0.6mm,BLACK PAINTED 1.0

2Lens MP-HM08A00300-B

ABS (MILK WHITE) 1.0

3Nonwovens MC-HM08000100-B 70g(Fabric KL180MB) 212*137.5）(212*137.5）1.0

4Double side tape AA-PD00400100-B

S-512,W=4mm，25m 0.0

5Back support MR-HM08S00301-B

SILICON RUBBER ,MATTE WITH PRINT（3M9448) 1.0

6Wind-screen MC-HM08000600-B

28mm*11mm*0.1mm 180 1.0

7Port_A MP-HM08A00400-B

ABS757 (BLACK) 1.0

8Port_B MP-HM08A00500-B

ABS757 (BLACK) 1.0

9LED Indicate PCBA FG-HM08GN0700-B PCBA LED Indicate 1.0

10 USB PCBA FG-HM08GN0200-B

PCBA USB 1.0

11 AUX Pcba FG-HM08GN0300-B

PCBA AUX 1.0

12 Screw MS-GEPBAPC099-B

ST2.0X7,D=3.2,Cr3+ 1.0

13 Rear house MP-HM08A00200-B

ABS757(BLACK) 1.0

14 Battery EU-BT00003600-B

3.7V/4000mAh 1.0

15 Rubber Button MR-HM08000200-B φ54.9±0.1mm,3M9448) 1.0

16 Key PCBA

FG-HM08GN0600-B PCBA Key 1.0

17 Double side tape MC-HM08000300-B

3M(9448)Φ52MM 1.0

18 Top cover MP-HM08C00100-B

ABS757 (WHITE),TPE( BLK),logo 1.0

19 Bottom cover MP-HM08C00200-B

ABS757 (WHITE),TPE( BLK) 1.0

20 Rubber Button MR-HM08000100-B

φ54.6±0.1mm,SILICON RUBBER (MATTE BLACK)

（

3M9448) 1.0

21 Rubber Block MR-HM08000400-B

SILICON RUBBER 11.8*8.04mm BLACK 60 1.0

22 Baffle MP-HM08A00100-B

ABS757(BLACK) 1.0

23 Screw MS-GEPBAPC0A5-B

ST2.6x7,Cr3+ 13.0

24 Screw MS-GEWBAPC034-B

ST2.0*7

，

W=Φ5.0MM, Cr3+ 3.0

25 Screw MS-GEPBAPC0A5-B

ST2.6x7,Cr3+ 13.0

26 Driver EB-M04000080300-B

Dimention: 40mm;Rated impedance: 8 Ohm;SPL: 80dB at 200,400,600,800;FO: 170Hz+/-20% 2.0

27 Main PCBA FG-HM08GN0400-B PCBA Main

1.0

28 LED Bar PCBA FG-HM08GN0500-B PCBA LED Bar 8.0

29 Double side tape MC-HM08000200-B

3M(9448)149.6MM*4.8MM 8.0

30 Connect cable driver EW-MC01205100-B

AWG#24,4,L=120MM 1.0

31 EVA MF-HM08000400-B

426*3.5*0.5mm 1.0

32 FFC cable EW-MC01151700-B

14P,L=115mm 4.0

33 FFC cable EW-MC01508000-B

14P,L=150mm 4.0

34 FFC cable EW-MC01550100-B

10P,L=155mm 1.0

35 EVA Bluetooth antenna MF-HM08000900-B

43x6.5x2mm 1.0

36 Antenna bluetooth EU-EL00000100-B

PCB 1.0

37 Mainboard EVA MF-HM08000201-B

12MM*4MM*1MM 2.0

38 Aux Socket EVA MF-HM08000500-B

12.0*8.0*2.0mm 1.0

39 Battery EVA bottom MF-HM08000701-B

2.0mm（20mm*20mm）2.0

40 Battery EVA top MF-HM08000600-B

12*12*4mm 1.0

41 FFC cable EW-MC01701100-B

7P,L=170mm 1.0

42 FFC cable EVA MF-HM08000100-B

30*20*1.0mm 1.0

43 Port EVA MF-HM08000300-B

55*20*0.5mm 2.0

Packing

4USB cable EW-MA10001000-B

L=1000mm,OD=4.5mm, MicroUSB to USB charger 1.0

5Adaptor ET-A240V0A100-B Switching AC/DC adapter, input:AC 100V-240V, output:USB DC 5V/2.3A,-Black 1.0

5a EU plug EG-000000DB00-B

5b GB plug EG-000000DA00-B

15 Master carton PC-HM08000100-B

219x215x183mm 0.5

1、Open top panel

To disassemble the unit

JBL

PULSE Service Manual

Page 13 of 38
