Harman Infinity ClubZ 250 Manual de usuario

User Manual

Warning!

Warranty Card

CLUBZ 250

PORTABLE BLUETOOTH SPEAKER

WELCOME TO HARMAN's FAMILY OF LEGENDARY BRANDS

01 EN

Input: 5V/1A

What’s in the box

Connections

Buttons

QSG

02 EN

2.0s

2. Turn off the bluetooth speaker

1. Turn on the bluetooth speaker

Power on / Power off

EQ switching

This speaker comes with dual EQ to enter into various

personal preference, to swtich EQ, short press "+" and "－"

buttons to switch.

03 EN

2.0s

Bluetooth connection

Music

Choose ”Infinity CLUBZ 250” to connect

2. Connect to bluetooth device

Settings Bluetooth

Bluetooth

Infinity CLUBZ 250

DEVICES

Connected

Now Discoverable

1. The speaker will automatically enter into pairing mode

when power on and wait for the device to connect.

3. When turn on, the speaker will automatically connect to

the last connected device if available. If not, short press

the " " button to re-enter the pairing.

4. Clean up the pairing information by long press the " "

04 EN

and " " buttons in the same time.

3.0s

x 1 x 1

x 2

Phone call

Voice assistant

Bluetooth mode, double press the " " button on the

speaker to activate Siri or Google Now on your phone. Please

make sure the Siri or Google Now is enabled on your phone.

05 EN

3.0s

Speaker A

Speaker B

True wireless stereo pairing

2. Enable bluetooth on your device and connect to

"Infinity CLUBZ 250", stereo sound will play from both

1. Long press the " " button to enter into the true wireless

stereo pairing mode as a master speaker. If one of them

fails, clean up the pairing information.

06 EN

speakers.

Specifications

Bluetooth version: 4.2

Support: A2DP V1.2; GAVDP V1.3; AVRCP V1.6; HFP V1.7

Transducer: 2 x 45mm

Output power: 7.5W *2

Frequency response:75Hz - 20KHz

Signal-to-noise ratio: >70dB

Battery type: Lithium-ion polymer (3.7V, 2500mAh)

Battery charge time: 4 hour @ 5V 1A

Music playing time: up to 10 hours(50% volume level)

Bluetooth transmitter power: -6 ~ 4dBm

Bluetooth transmitter frequency range: 2.402 — 2.480GHz

Bluetooth transmitter modulation: GFSK, 1/4-DQPSK, 8DPSK

Dimensions: Φ88*116(mm)

Weight: 421g

LED Behavior

White

Fast flash

White

Slow flash

White

Flash

White

Fast flash

White

Fast flash

White

true wireless

stereo pairing

mode

true wireless

stereo

connected B

Stand by

Bluetooth

pairing mode

Bluetooth

connected

Dual speaker connect

07 EN

This symbol on the products and/or accompanying documents

means that used electrical and electronic products should not

be mixed with general household waste. For proper treatment,

recovery and recycling, please take these products to

designated collection points, where they will be accepted on a

free of charge basis. Alternatively, in some countries you may be

able to return yourproducts to your local retailer upon the

purchase of an equivalent new product. Disposing of this

product correctly will help to save valuable resources and

the environment which could otherwise arise from inappropriate

waste handling. Please contact your local authority for further

details of your nearest designated collection point. Penalties

may be applicable for incorrect disposal of this waste, in

accordance with national legislation.

INFORMATION ON DISPOSAL FOR USERS OF

WASTE ELECTRICAL &ELECTRONIC EQUIPMENT

(PRIVATE HOUSHOLD)

Warning

IMPORTANT: To ensure that the CLUBZ 250 is waterproof,

please remove all cable connections and tightly close the

cap; exposing the CLUBZ 250 to liquids without doing so

may result in permanent damage to the speaker. And do

not expose CLUBZ 250 to water while charging, as doing so

may result in permanent damage to the speaker or power

immersed in water up to 1m for up to 30 minutes.

CLUBZ 250 is IPX7 waterproof.

08 EN
