Harman Kardon AVR 140 Manual de usuario

250 Crossways Park Drive, Woodbury, NY 11797

516.255.HKHK(4545) FAX 516.682.3520

www.harmankardon.com

Part No. HKLITUSA8/05 Printed in USA

Harman Kardon

believes that high-

quality audio/video

components must do

more than just look

and sound good –

they must deliver a

complete package of

performance, design,

flexibility and ease of

use. For more than 50

years, Harman Kardon

products have done just

that by incorporating

abroad array of

technological and

design innovations.

So if you’re looking

for audio/video

products that produce

pure, realistic sound

and video with ever-

smarter engineering

and ever-simpler

design, we invite you

to experience the

unique combination

of artistry and

engineering that

is Harman Kardon.

PERFORMANCE

DESIGNED TO ENTERTAIN, PAGE 6

A/V RECEIVERS (40 SERIES), PAGE 10

iPOD DOCKING STATION, PAGE 12

ACTIVITY-BASED REMOTE, PAGE 14

A/V RECEIVERS (35 SERIES), PAGE 16

DIGITAL PATH RECEIVER, PAGE 18

MULTIROOM PRODUCTS, PAGE 20

STEREO RECEIVERS, PAGE 22

DVD & CD PLAYERS, PAGE 26

INTEGRATED HOME THEATER SYSTEM, PAGE 30

HOME THEATER SPEAKER SYSTEMS, PAGE 32

HOME THEATER SYSTEMS, PAGE 36

SPECIFICATIONS, PAGE 38

Asingle connection from The Bridge™to a The Bridge-Ready Harman Kardon receiver provides audio playback,

complete control and charging of most iPod®1 models. You can select tracks using your AVR’s remote and view

on-screen navigation menus. What could be easier?

Wouldn’t it be nice it you could use simple language to tell your remote what equipment it needs to control, have

it automatically program the correct codes and then adapt each activity to your personal preferences? Thanks to

Harman Kardon technology – programmable via the Internet – that’s exactly what the TC 30 can do, with a color

LCD screen as an added bonus!

Getting the best sound takes more than just power, it requires tailoring the system parameters to the unique

characteristics of the listening room. With the press of a few buttons, our patented EzSet/EQ,

™EzSet+

™and EzSet™

systems do that for you automatically, with accuracy previously possible only with expensive professional gear.

Harman Kardon technology unleashes music power so that it can be heard almost anywhere in the house.Thanks

to configurable amplifiers, A-BUS/READY ®single-wire connectivity and standard Zone II remotes, it’s easier than

ever to have the sound you want, where you want it.

Sometimes technology changes after you purchase a component. That’s why all Harman Kardon DVD players and

HS systems, the DPR and select AVR receivers can be easily updated when needed, keeping your system current

for years to come.

DESIGNED

to Entertain

6 7

TC 30

THE BRIDGE

EzSet/EQ

A-BUS

UPDATES

The best technologies

are the ones that add

to the power and

performance of a

system while making

it easier to use.

7x85W 7.2-Channel A/V Receiver

Digital audio meets digital video. Ready for the future, the AVR 740’s DCDi®by Faroudja video processing flawlessly

upscales all incoming video to 720p or 1080i high definition and outputs it through an HDMI™jack. On the audio side,

direct HDMI connection to compatible DVD-Audio players, USB playback from compatible digital audio sources and

XM-Ready®2capability for digital satellite radio greatly expand your digital options. Our advanced EzSet/EQ II system,

7.2-channel capability, TC 30 remote and more make this the most flexible AVR we’ve ever produced.

7x55W 7.1-Channel A/V Receiver

Tune up your room; no tools required. Thanks to EzSet/EQ, the AVR 340 not only establishes all system speaker

parameters, it measures how the speakers “sound” in your room and equalizes their output to compensate for any

room-based acoustic situation. Add a wide range of convenience features such as video cross conversion, component

output for simplified connectivity, A-BUS/READY multiroom capability, and compatibility with The Bridge, and you’ll be

enjoying movies and music quicker than ever.

7x50W 7.1-Channel A/V Receiver

For high quality “by the numbers” the AVR 240 is clearly best in class. Seven channels of high-current amplification,

Logic 7®processing, 192kHz/24-bit digital converters, two high-bandwidth component video inputs, a two-line front-

panel display and more inputs and outputs than you can count. Add the power of EzSet+ to automatically set system

speaker levels, and it all adds up to a magnificent total of high-quality audio and video performance.

6 x 40W 6.1-Channel A/V Receiver

Don’t let the AVR 140’s modest price fool you. Our most affordable A/V receiver is loaded with features. With

on-screen menus that include renameble inputs, component video switching, compatibility with The Bridge, and

our classic high-current, ultrawide-bandwidth amplifier topology, there is no better way to upgrade an old analog

system or add high-quality home theater performance when budget considerations are paramount.

If A/V receivers are

the heart of a home

entertainment system,

then Harman Kardon

AVRs are both heart

and mind. They take

today’s vast array of

audio/video formats

and sources, and make

it easy for you to select

asource, tailor it to

the requirements of

your listening room

and then play it back

without skipping a beat.

AVR

A/V Receivers

10 11

AVR 740

AVR 340

AVR 240

AVR 140

iPod Docking Station

iPod and Harman Kardon: two names synonymous with music playback, ease of control and elegant design. Now,

The Bridge literally links the two, allowing you to share the favorite tracks and playlists stored on your iPod with

anyone in listening range of a compatible Harman Kardon AVR – even in a connected second room. Dock your

iPod in The Bridge, then sit back and operate it with the AVR’s remote control while on-screen and front-panel

menus guide your track selections. The Bridge also charges the iPod while you use it.

Together for the first

time – your iPod

and your home

entertainment system –

thanks to The Bridge.

Asingle connection

provides complete

navigation and control

of an iPod with the

remote control from

aThe Bridge-Ready

Harman Kardon receiver,

and charges the battery

at the same time. Of

course, you can also

hear any track on the

iPod through your home

entertainment system.

12 13

THE BRIDGE

iPOD

Docking Station

Activity-Based Remote

There’s a good reason that the “TC” in “TC 30” stands for “Take Control.” This unique product does more than just

operate single components; it dramatically changes the way you configure and use a remote control. Setup is done

directly with our Web site, where plain language “wizards” recognize the brand and model of all your equipment and

automatically send the right codes back to the TC 30. The TC 30 remote groups all the needed commands, including

“Watch TV,” “Listen to CD,” “Watch a DVD” and “Listen to The Bridge,” into unified activities. All you need to do is look at

the color LCD screen, select the icon that matches the activity, and the TC 30 does the rest. It’s easy, it’s fun and it

makes operating otherwise complex systems a breeze.

It’s time to Take Control™!

The TC 30 extends our

commitment to taking

integrated entertainment

to the next level by

making it easier than

ever to not only program

aremote control for

virtually any combination

of components – from

Harman Kardon and

other brands – but

to link them together

so that even the

most technophobic

among us can operate

the most complex

audio/video system.

Activity-Based

REMOTE

14 15

TC 30

7x75W 7.1-Channel A/V Receiver

The AVR 635 combines the sonic power of our high-current, ultrawide-bandwidth amplifier design with advanced

audio processing technology from Texas Instruments™to deliver unparalleled performance. Thanks to Harman Kardon’s

proprietary EzSet/EQ functionality, the AVR 635 not only automates speaker output and delay settings, it corrects for room

acoustics.The AVR 635’s video technology is equally impressive, with video conversion so that all input sources may be

viewed via component video, and A/V Sync delay that reconnects the timing of sound and image. An RS-232 port makes

future software upgrades possible, and enables external control systems.

7x65W 7.1-Channel A/V Receiver

Perfect home theater made easy! Thanks to EzSet/EQ, setting up the AVR 435 is quick and painless. Plug in the compact

microphone,press a few buttons,and your system is precisely and automatically calibrated with full-room correction. Once

you’re ready to listen, the latest digital surround modes and our own Logic 7 processing deliver flawless performance. With

high-current power to spare, and a host of advanced features such as A-BUS/READY connectivity, the AVR 435 is home

theater perfection.

As the company

that invented the

audio receiver,

Harman Kardon has

always defined a

receiver’s power by

more than just the

traditional benchmarks

of watts and dBs. Our

AVRs express power

as a total package of

features, functionality,

ease of use and elegant

industrial design. From

that perspective, the

AVR 635 and AVR 435

are perfectly powered.

AVR

A/V Receivers

16 17

AVR 635

AVR 435

7 x 120W 7.1-Channel Digital Path Receiver

Thanks to our digital path receiver technology, the DPR 2005 packs an incredible amount of power into a compact

form. It features the latest surround formats from Dolby®and DTS,

®including Dolby Pro Logic®IIx, Dolby Virtual Speaker

and DTS 96/24, along with our proprietary Logic 7 technology, which gives older stereo and matrix soundtracks a full

7.1-channel presentation. Digital bass management, even for analog inputs from DVD-A and SACD players, combined

with our quadruple crossover system, creates a seamless, powerful soundfield, while a wide range of multiroom options,

including A-BUS/READY connectivity, assignable rear channels and a separate Zone II remote, let you spread great sound

throughout the house.

Pure digital, pure

performance.

Harman Kardon’s

digital path receiver

topology preserves

the quality of your

program sources by

linking them directly

to a powerful amplifier

without any conversions

back and forth between

analog and digital.

Beyond the power

and musicality it

delivers across the

full audio bandwidth,

Harman Kardon’sDPR

is designed to be

highly efficient – there’s

no need to sacrifice

performance when

space is at a premium.

DPR

Digital Path

Receiver

18 19

DPR 2005
