Harley Benton CB-110X Manual de usuario

Owner`s Manual

CB-110X

Caution

Overviews

The panel descriptions

The top panel

The rear panel

System block diagram

Specification

2-4

Table Of Contents

Please carefully read and strictly follow the owner`s

manual when you use H series professional

amplifier. If you have any question, please contact

the local dealer.

Dear Customers

To assure the finest performance, please read this manual carefully. Keep it in

a safe place for future reference. It's different in plug and socket from this

device in some countries and regions, while the operation and connection of

the device is same.

To reduce the risk of fire or electric

shock. Do not expose this apparatus

to rain or moisture. To reduce the

risk of electric shock. Do not remove

cover. Refer servicing to qualified

service personnel for repair this

apparatus.

The exclamation point

within an equilateral

triangle.is intended to alert

you to the presence of

important operating and

servicing instructions.

The lighting flash &

arrowhead symbol,within

an equilateral triangle, is

intended to alert you to the

presence of danger.

Voltage: Voltages are 220V AC, 50Hz.

All the safety and operation instruction should be read before the appliance

is operated. All warnings on the appliance and in the operation instructions

should be adhered to. All operating and use instructions should be followed.

The safety and operating instructions should be retained for future reference.

1. Connect the amplifier ONLY to a properly grounded AC outlet of the

proper voltage for your amp.

2. Avoid the thread to be under kick and hustle by heavily.

3. Do not block any ventilation openings on this amplifier.

4. Do not operate near any heat source.

5. Do not expose this amplifier to rain or moisture.

6. Disconnected the electric thread if the amplifier dose not use forlong time.

7. To reduce the risk of electric shock, DO NOT remove the cover.

Caution

Thank you for purchasing our product.

HEADPHONE

ON/OFF

BRIGHT

BOOST

LOW LOW MID MID HIGH HIGH E.LEVEL

GAIN VOLUME BASS TREBLE E.MODEINPUT

EFFECTS COMP

POWER

OFF

781615

EQUALIZER

3513

14 1111224

1 Delay

2-9 Chorus

Overviews

The Panel Descriptions

The Top Panel

12" bass speaker design

110W RMS (4ohm)

4 band EQ (LOW, LOW MID, MID HIGH, HIGH) for precise tonal

shaping

Powerful built-in effects (CHORUS, DELAY )

Stereo auxiliary input for connecting CD player, drum machine etc.

headphone output for silent practice

preamp output

extension speaker jack

Footswitch (EFF ON/OFF)

CB-110X

Effect

1. GAIN

Use this control to adjust the gain level of amplifier.

2. BRIGHT

Depress this switch for boosting the high frequency of amplifier.

3. BOOST

Depress this switch for boosting the low frequency of amplifier.

4. VOLUME

Use this control to adjust the output level of preamp. Rotate the control fully

counterclockwise to MIN. Rotate the knob clock wise to the desired amount.

5. EQUALIZER

Use these 2 controls to adjust the bass, treble frequency level of the amplifier.

Equalizer

6. EQ ON/OFF

Use this switch to turn the EQ channel on or off..

7. EQ CONTROL

4-BAND EQ designed for boosting or cutting LOW, LOW

MID, MID HIGH, HIGH level of EQ channel.

8. EFF LED

This LED illuminates when the Effect mode is selected.

9. EFF SWITCH

Use this switch to turn the Effect mode on (top of the switch depressed)

and off (bottom of the switch depressed).The LED illuminates when the

Effect is turned on.

10. EFF LEVEL CONTROL

Use this control to adjust the output level of the effect.

11. EFF MODE/PARAMETER ADJUSTMENT

This is a multi-function control which can change and edit the effects in

real time. At the preset state, 9 built-in effects can be selected by rotating

the continuerol. Enter the edit mode by depressing the control, rotating the

control to adjust the parameter. To save the parameter and exit the edit mode,

depress the control again.

THIS MACHINE WILL SAVE AND EXIT AUTOMATIC AT THE PROCESS

OF EDITING IF THERE ISN'T ANY OPERATION WITH THIS CONTROL

OVER 5SECONDS.

DEPRESS THE CONTROL OVER 3 SECONDS WILL REMOVE THE

PARAMETER BE EDITED AND GO BACK TO THE PRESET STATE.

12. EFF MODE LED

These LED indicate the 9 powerful build-in effects, besides, they

indicate the parameter of the effect.

13. POWER

Use this switch to turn the amplifier on and off.

14. INPUT

(1/4" MONO) Use this jack to connect your bass guitar to the amplifier.

15. HEADPHONE

(1/4" STEREO) Use this jack to connect headphone for silent practice.

The internal speaker is disconnected when this jack is used.

16. COMPRESSION LED

The compression circuit designed to limits harsh, transient peaks and

evens out bass guitar signal in post-amp. This LED illuminates when

he circuit is in work.

The Rear Panel

17. AUX INPUT

(1/4" STEREO) Use this jack to connect CD player, drum machine etc.

18. PREAMP OUTPUT

(1/4" MONO) the signal may be taken from this jack and sent to the mixer,

recording console or external power amplifier.

19. EXTENSION SPEAKER

(1/4" MONO) Use this jack to connect the amplifier to an external speaker

cabinet.

20. FOOT SWITCH

(1/4" STEREO) Use this jack to connect the footswitch for turning the

EFF ON/OFF.

FOOT SW

EFF ON/OFF PRE OUT AUX IN

STEREO

CAUTION

RISK OF ELECTRIC SHOCK DO NOT OPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVECOVER (OR BACK).

NO USER-SERVICEABLE PARTSINSIDE.

REFER SERVICING TOQUALIFIED

SERVICE PERSONNEL.

EXT

SPEAKER

181920 17

BASS AMPLIFIER

POWER CONSUMPTION: MAX 130W

SERIAL NO:

CB-110X

BASS

AMPLIFIER

CB-110X

System Block Diagram

Specification

RMS.....................................................................110W (4ohm)

INPUT SENSITIVE/IMPEDANCE

......................................INPUT (CHANNEL A)/-10dBu/1M ohm

.........................................................................AUX IN/-10dBu

SPEAKER ...........................................................30cm (12inch)

CONTROL

........................................................................................GAIN

..................................................................................VOLUME

........................................................................BASS, TREBLE

....................................................................................BRIGHT

.....................................................................................BOOST

.............................................................................EQ(ON/OFF)

...........................................HIGH,MID HIGH, LOW MID,LOW

EFFECTS

..................................................................................E.LEVEL

...................................................................................E.MODE

.............................................................................EFF ON/OFF

LED

....................................................................................POWER

.......................................................................COMPRESSION

CONNECTION (1/4 )

........................................................................INPUT (MONO)

....................................................................AUX IN (STEREO)

..........................................................HEADPHONE (STEREO)

....................................................................PRE OUT (MONO)

...........................................................EXT SPEAKER (MONO)

.................................................FOOT SWITCH ( EFF ON/OFF)

POWER SUPPLY ...............................................AC 220V/50Hz

POWER CONSUMPTION ................................................130W

DIMENSION..................................397(W)*324(D)*435(H) mm

PACKINGSIZE ..............................................453*367*477mm

NET WEIGHT ...............................................................16.8Kg
