ASSEMBLY & OPERATING INSTRUCTIONS

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our Web Site at www.harborfreight.com

any artwork contained herein may be reproduced in any shape or form without the

express written consent of Harbor Freight Tools.

For technical questions and replacement parts please call 1-800-444-3353.

44983

Due to continuing improvement, actual product may differ slightly from the product described herein.

6” MACHINE VISE

WITH LOCK-DOWN JAWS

Brought to You by Augusta Flint

SKU 44983 For technical questions please call 1-800-444-3353. Page 2

THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please

complete the owner’s record below:

Model______________ Serial No._____________ Purchase Date_______________

SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the

entire manual to become familiar with the unit BEFORE you begin assembly.

Technical Specifications

Jaw Width: 6-1/4”

Throat Depth: 1-7/8”

Maximum Jaw Opening: 5-7/8”

Base Dimensions: 16-7/8” x 8-3/4”

Base Swivel Capacity: Flat mount

Mount Holes: 2

Mount Holes Diameter: 3/4”

Anvil Dimensions: 6-3/4” X 6”

Overall Dimensions: 16-7/8” x 8-3/4” x 5”

Vise Weight 72 Lbs.

Safety Warnings and Precautions

WARNING: When using product, basic safety precautions should always be followed to

reduce the risk of personal injury and damage to equipment.

Read all instructions before using this product!

1. Keep work area clean. Cluttered areas invite injuries.

2. Check for damaged parts. Before using any product, any part that appears damaged should

be carefully checked to determine that it will operate properly and perform its intended function.

Check for any broken or damaged parts and any other conditions that may affect its operation.

Replace or repair damaged or worn parts immediately.

3. Replacement parts and accessories. When servicing, use only identical replacement parts.

Use of any other parts will void the warranty.

4. Always check hardware and assembled parts after assembling. All connections should be

tight and hardware tightened.

5. Keep children away. Children must never play with the Vise.

6. Dress properly. Gloves are recommended when using the Vise. Wear restrictive hair covering

to contain long hair.

7. Use eye protection. Always wear ANSI approved impact safety goggles when using this

product.

8. Maintain product with care. Keep the Vise in a dry location. Keep the Vise clean of grease

and metal filings.

Brought to You by Augusta Flint

SKU 44983 For technical questions please call 1-800-444-3353. Page 3

9. Use the right Vise for the job. There are certain applications for which this Vise was

designed. Do not modify this Vise and do not use this Vise for a purpose for which it

was not intended.

10. If struck by a striking tool, the jaws may chip, this will damage the vise and possibly

result in eye or bodily injury. Always check the Vise for damage before using it. Always

replace the jaws if they are damaged.

11. Do not use the Vise if under the influence of alcohol or drugs. Read warning labels on

prescriptions to determine if your judgement or reflexes are impaired while taking drugs. If there

is any doubt, do not assemble or use the Vise.

WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot

cover all possible conditions and situations that may occur. It must be understood by

the operator that common sense and caution are factors which cannot be built into

this product, but must be supplied by the operator.

Assembly/ Operation

Your Vise comes fully assembled other than putting on the handle (10). It is important that you read

the entire manual to become familiar with the product BEFORE you use the Vise. Before ataching

the handle (10) to the Vise be sure that you have all parts described in the Parts List and Assembly

Diagram located on the last pages of this manual.

NOTE: Make certain to follow all precautions and safety warnings listed in this manual and in the

drilling or milling machine manual.

NOTE: The Vise weighs 72 Lbs. It is recommended that two adults are present when moving or

assembling the Vise. Before intial use of the Machine Vise, use a soft cloth to wipe off the protective

coat of grease.

1. To mount the Machine Vise to your milling or drill table Insert the T-Slot Bolts (15) into the

T-Slots on the Vise as shown in Figure 1.

T-Slot Bolt (15)

Figure 1

2. Set the Machine Vise so that the T-Slot Bolts (15) in the Machine Vise line up with

the T-slots on the drill or mill table. Make certain that the surface being used is capable of

supporting the weight of the Vise and anything clamped into the Vise. Make certain that the

Vise is stable and secure once set in place on the milling/drilling machine. Then us T-nuts

(not provided) to secure the Machine Vise to the mill or drill table.

Brought to You by Augusta Flint

SKU 44983 For technical questions please call 1-800-444-3353. Page 4

3. To install the Handle (10) first locate it and slide it onto the Screw (8) as in Figure 2.

Insert Lock Screw (6) to secure it in place.

Handle (10)

Lead Screw (8)

Figure 2

4. To open the Plain Jaw (1), turn the Handle (10) counterclockwise until the jaws are at the

desired width. Insert your workpiece.

5. Turn the Handle (10) clockwise to tighten the Plain Jaw (1) on the workpiece. Do not

overtighten the Vise on the workpiece; damage may occur to the workpiece.

6. When you are finished, turn the Handle (10) counterclockwise to remove your

workpiece from the jaws.

7. The Machine Vise has a Scale (24) to set degree and location of the workpiece. Numerical

orientation is marked on the Scale (24) and can be set by lining up the number on the scale

with the metal clover shaped tab on the Scale (24) as in Figure 3. Move the Vise by

loosening the Hex Nut (13) and rotating the Vise to desired degree setting. Retighten Hex

Nut (13).

Figure 3

Replacing Plain Jaws (1)

1. To remove the Plain Jaws (1), unscrew the Inner Turret Screws (2). Pull off the Plain

Jaws (1) and replace with a new set-see Figure 4. Replace the Turret Screws (2)

see Figure 4.

Inner Turret Screw (2)

Figure 4

Plain Jaw (1)

Lock Screw (6)

marker

Scale (24)-currently

set at “0”

Brought to You by Augusta Flint

SKU 44983 For technical questions please call 1-800-444-3353. Page 5

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE

TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY

KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS

QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED

TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER

REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION

OF REPLACEMENT PARTS THERETO.

Maintenance

1. Remove dirt and debris from the vise using a clean, soft cloth. Do not use flammable,

corrosive or abrasive solvents to clean the vise.

2. BEFORE EACH USE, inspect the general condition of the Machine Vise. Check for loose

connections, misalignment or binding of moving parts, cracked, torn, or broken parts, and

any other condition that may affect its safe operation. Do not use damaged equipment.

3. Lubricate all moving parts on a frequent and regular basis with a light machine oil.

Part # Description Qty Part # Description Qty

1 Plain Jaw 2 13 Hexagon Nut 2

2 Inner Turret Screw 4 14 Washer 2

4 Movable Block 4 15 T-Slot Bolt 2

5 Adjusting Screw 1 16 Center Axle 1

6 Lock Screw 1 17 Swivel Base 1

7 Thrust Washer 1 18 Inner Turret Screw 2

8 Lead Screw 1 20 Nut 1

9 Swivel Sleeve 1 21 Body 1

10 Handle 1 22 Location Key 1

11 Spring 1 23 Fixed Block 1

12 Thrust Needle Bearing 1 24 Scale 1

REV 01/06

Brought to You by Augusta Flint

SKU 44983 For technical questions please call 1-800-444-3353. Page 6

1245678910

Parts and Assembly Diagram

REV 01/06
