Hanwha Vision RoadWatch XNO-6120R/RW Manual de usuario
QUICK REFERENCE GUIDE
RoadWatch
LPN HT-777-WS
Country FRANCE
Direction ↓
CONTENTS
1PRE-INSTALLATION
1.1 Choosing Location
CONFIGURING YOUR CAMERA
1. Data and Time
2. Network Settings
3. Analytics
4. SD Card
5. Exposure
6. Focus
7. Pixel width
8. Install or Update Application
9. Activate Application
10. Configure Application
2
3
4
INSTALLING AND
POSITIONING CAMERA
1. Camera Installation
2. Adjusting Plate Tilt Angle
3. LPR (ANPR) Specification
INSTALLATION
1. Observing proper installation
2. Examples of proper installation
1PRE-INSTALLATION
1.1 Choosing Location
The LPR (License Plate Recognition) / ANPR (Automatic Number Plate Recognition) Technology running on this camera will provide
you with the best results when following the recommended installation requirements below.
Minimum Forward Distance
30º Maximum Vertical Angle
Maximum Forward Distance
30º
4 m
3 | RoadWatch Quick Reference Guide
Recommended
30 degrees Maximum Vertical Angle
Minimum and Maximum Forward Distance
depend on lens zoom.
Please, refer to the table on pp. 6-7 for
different camera models.
Fig. 1
Camera shown from side
Fig. 2
Example of installation at a height of 4 m
13 m
7 m
1.1 Choosing a Location (Continued)
All the license plates that meet the on-frame size
criteria below will be recognized in the selected
area.
•130-300 pixels for regular EU plates
•80-300 pixels for US plates without stacked
symbols (small ones)
•160-300 pixels for US plates with stacked symbols
Color coded pixel counts are available in the settings
section of RoadWatch.
Recommended
30 degrees Maximum Horizontal Angle
Fig. 3
Camera shown from top
30º Maximum Horizontal Angle
Minimum Forward Distance
Maximum Forward Distance
Fig. 4
Camera can cover 1 road lane.
Normally, setting recognition zone (see orange
frame below) in lower half of camera view is
sufficient and favours app performance.
4 | RoadWatch Quick Reference Guide
2INSTALLING AND POSITIONING CAMERA
2.1 Camera Installation
NOTE: Refer to camera installation guide and follow the installation instructions.
2.2 Adjust for Plate Tilt Angle
For the best results, check the angle of your plate compared to the horizontal alignment and
rotate the camera to achieve less than 5° as shown below.
Recommended Angles
NOTE: Refer to the “show plate grid” section available in RoadWatch settings for assistance.
>5°
5°max
5 | RoadWatch Quick Reference Guide
2.3 LPR(ANPR) Specification: Wisenet 5 cameras
LPR Usage Conditions Urban Traffic Urban Traffic Urban Traffic
Speed Description Regular Speed Moderate speed Moderate speed
Lane Coverage 1 lane (3.6m/12ft Wide) (with built in IR) 1 lane (3.6m/12ft Wide) (with built in IR) 1 lane (3.6m/12ft Wide) (with built in IR)
Speed limit Up to 90km/h (55mph) Up to 50km/h (30mph) Up to 50km/h (30mph)
Min. Forward Distance 17m (55ft) 7m (23ft) 7m (23ft)
Max. Forward Distance 32m (105ft) 13m (42ft) 13m (42ft)
Max. Horizontal Angle 30°30°30°
Max. Vertical Angle 30°30°30°
Horizontal Offset Up to 9.8m (32ft) Up to 4m (13ft) Up to 4m (13ft)
Camera Height Up to 9.8m (32ft) Up to 4m (13ft) Up to 4m (13ft)
LPR(ANPR) CAMERAS XNO-6120R/RW XNO-6080R/RW XNV-6080R/RW
6 | RoadWatch Quick Reference Guide
2.4 LPR(ANPR) Specification: Wisenet 7 cameras
LPR Usage Conditions Urban Traffic Urban Traffic Urban Traffic
Speed Description Regular Speed Moderate speed Moderate speed
Lane Coverage 1 lane (3.6m/12ft Wide) (with built in IR) 1 lane (3.6m/12ft Wide) (with built in IR) 1 lane (3.6m/12ft Wide) (with built in IR)
Speed limit Up to 90km/h (55mph) Up to 50km/h (30mph) Up to 50km/h (30mph)
Min. Forward Distance 17m (55ft) 7m (23ft) 7m (23ft)
Max. Forward Distance 32m (105ft) 13m (42ft) 13m (42ft)
Max. Horizontal Angle 30°30°30°
Max. Vertical Angle 30°30°30°
Horizontal Offset Up to 9.8m (32ft) Up to 4m (13ft) Up to 4m (13ft)
Camera Height Up to 9.8m (32ft) Up to 4m (13ft) Up to 4m (13ft)
LPR(ANPR) CAMERAS XNO-6123R/RW XNO-C6083R/RW XNV-C6083R/RW
7 | RoadWatch Quick Reference Guide
NOTE: There is no default username and password to access the camera settings
1) Please setup your own username and password when you access camera settings for the first time.
2) Make sure to set correct date and time for the camera before going in to any additional settings.
3) If camera firmware update is required, it is strongly advised to factory reset on camera to make sure that changes applied successfully
○Field of View
Follow the steps below on the Wisenet camera configuration webpage
●Configure camera so that left and right sides are correct, not mirrored.
●Set camera zoom to capture license plates
●Adjust camera view angle so that plates pass through the middle of the image.
○Configure Initial Camera Settings
For proper operations, please, check and set properly:
●Camera Date Time (see p.9)
●IP settings (see p.10)
●Analytics (see p.11)
●SD card storage (see p.12)
●Camera exposure and focus (see p.13~15)
●Check pixel size (see p. 16)
SSDR, WDR, DIS, Defog, AGC and anti-flickering features are good for human eye but affect computer vision performance and
therefore turning them off is strongly advised.
3CONFIGURING YOUR CAMERA
8 | RoadWatch Quick Reference Guide
Set date and time or opt to synchronizing
with your PC or NTP server.
Choose A Timezone and set Use daylight
saving time if applicable.
3.1 Configure Initial Camera Settings
[Date and Time]
NOTE: RoadWatch app relies on camera time
and time zone settings and if those are not set
properly, you may not see events in RoadWatch
app and events delivered to the outer systems
may not have proper timestamps.
9 | RoadWatch Quick Reference Guide
Date & Time
A
B
A
B
3.1 Configure Initial Camera Settings (Continued)
[IP, DNS, Ports]
Proper IP, DNS and ports setting are
important for:
•NVR and other integrations
•outside LAN access if required
NOTE: Reboot the camera whenever IP address
gets changed.
IP & Port
10 | RoadWatch Quick Reference Guide
