CY-WDCB7UR installation manual P/N: BN59-01157A 1 of 37

CY-WDCB7UR installation manual

Proprietary Information

All information contained in this document is confidential and proprietary to Hanshin IT. No license, expressed or implied,

under any patent, copyright or trade secret right is granted or implied by the conveyance of this document. No part of this

document may be reproduced, transmitted, transcribed, stored in a retrieval system, translated into any language or

computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual, or otherwise

without the prior written permission of Hanshin IT.

Document Title CY-WDCB7UR Installation manual

Samsung P/N BN59-01157A

Hanshin IT P/N HS6621 Rev 2.6

Latest Revision Number V0.9

Latest Revised Date 04/23/2012

Confidential

Revision No.: V0.9

Authors: DC Kim

Project Leader: DC Kim

Project Code: SS-UWB-201101

Release Date: 04/23/2012

COMPANY CONFIDENTIAL

CY-WDCB7UR installation manual P/N: BN59-01157A 2 of 37

CONTENT

1. SCOPE ............................................................................................................................................................................................. 8

1.1 DOCUMENT ...................................................................................................................................................................... 8

2. How to install the CY-WDCB7UR? ..................................................................................................................................... 8

2.1 UWB RF module applications ................................................................................................................................... 8

2.2 Interface signals .............................................................................................................................................................. 8

2.3 Installation ......................................................................................................................................................................... 8

3. HARDWARE SPECIFICATIONS ........................................................................................................................................... 10

3.1 GENERAL ......................................................................................................................................................................... 10

3.2 PRODUCT CHACTERISTICS ..................................................................................................................................... 10

3.3 ENVIRONMENT ............................................................................................................................................................ 11

3.3.1 Temperature ................................................................................................................................................... 11

3.3.2 Humidity ........................................................................................................................................................... 11

3.4 PRODUCT PHOTOGRAPH ....................................................................................................................................... 12

4. HARDWARE REQUIREMENTS ............................................................................................................................................ 13

4.1 FUNCTIONAL BLOCK DIAGRAM .......................................................................................................................... 13

4.2 AL6301/AL5100 CHIPSET ARCHITECTURE ....................................................................................................... 14

4.3 IO CONNECTOR PIN DEFINITION ....................................................................................................................... 15

4.4 Manufacturing Test Block Diagram .................................................................................................................... 16

4.4.1 PT Block Diagram ......................................................................................................................................... 16

4.4.2 FT Block Diagram ......................................................................................................................................... 16

COMPANY CONFIDENTIAL

CY-WDCB7UR installation manual P/N: BN59-01157A 3 of 37

4.5 PRODUCT TEST ITEMS & SPEC ............................................................................................................................ 17

4.5.1 Transmission Section .................................................................................................................................. 17

4.5.2 Receiver Section ............................................................................................................................................ 17

4.6 PERFORMANCE TEST RESULTS ............................................................................................................................. 18

4.6.1 Current Consumption ................................................................................................................................. 18

4.6.2 Indoor Range Throughput ....................................................................................................................... 18

5. DIMENSION INFORMATION .............................................................................................................................................. 19

5.1 PCB DIMENSION ......................................................................................................................................................... 19

5.2 SHIELD CASE DIMENSION ...................................................................................................................................... 20

5.3 ASSEMBLY DIMENSION ........................................................................................................................................... 22

6. PACKAGE DIMENSION ......................................................................................................................................................... 23

6.1 LABEL DIMENSION ..................................................................................................................................................... 23

6.2 LABEL STICK .................................................................................................................................................................. 23

7. ANTENNA SPECIFICATIONS ............................................................................................................................................... 24

7.1 Summaries ...................................................................................................................................................................... 24

7.1.1 Function and Features ............................................................................................................................... 24

7.2 Specification .................................................................................................................................................................. 24

7.2.1 Applicable Boundary ................................................................................................................................... 24

7.2.2 Electrical Specification ................................................................................................................................ 24

7.3 Results of Antenna Measurement ....................................................................................................................... 26

7.3.1 Antenna Return Loss .................................................................................................................................. 26

COMPANY CONFIDENTIAL

CY-WDCB7UR installation manual P/N: BN59-01157A 4 of 37

7.3.2 Antenna VSWR .............................................................................................................................................. 27

7.3.3 Antenna Radiation Pattern ....................................................................................................................... 27

7.3.4 Antenna Peak Gain ...................................................................................................................................... 28

7.4 Drawing ........................................................................................................................................................................... 30

7.4.1 Antenna Drawing .......................................................................................................................................... 30

8. PACKAGE DIMENSION ......................................................................................................................................................... 32

8.1 ANTI SHIELDING BAG ............................................................................................................................................... 32

8.2 CARTON .......................................................................................................................................................................... 32

8.3 PAD ................................................................................................................................................................................... 33

8.4 TRAY ................................................................................................................................................................................. 33

8.5 CARTON ASSY DRAWING (TRAY STACK DRAWING) ................................................................................. 34

9. HANSHIN IT CONTACT INFORMATION ....................................................................................................................... 35

10. IC Statement..................................................................................................................................................................... 35

COMPANY CONFIDENTIAL

CY-WDCB7UR installation manual P/N: BN59-01157A 5 of 37

Revision History

Revision Originator Description Date

0.9 DC Kim Initial Released. 04/23/12

COMPANY CONFIDENTIAL

CY-WDCB7UR installation manual P/N: BN59-01157A 6 of 37

COMPANY CONFIDENTIAL

CY-WDCB7UR installation manual P/N: BN59-01157A 7 of 37

FCC information

The following information must be included in the User Manual for the Final End Product

(Host Product):

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This device is authorized under Title 47 CFR 15.519 (the FCC Rules and Regulations).

The operation of this device is subject to the following restriction:

Changes or modifications made to this equipment not expressly approved by SAMSUNG or parties

authorized by SAMSUNG could void the user's authority to operate the device under the FCC Equipment

Authorization. This includes changes or substitutions of the antennas which are furnished with the device.

UWB devices may not be employed for the operation of toys. Operation onboard an aircraft, a ship or

satellite is prohibited.

LABEL OF THE END PRODUCT:

The final end product must be labeled in a visible area with the following

Contains FCC ID: A3LCYWDCB7UR

This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1)

this device may not cause harmful interference and (2) this device must accept any interference received,

including interference that may cause undesired operation.

COMPANY CONFIDENTIAL

CY-WDCB7UR installation manual P/N: BN59-01157A 8 of 37

1. SCOPE

1.1 DOCUMENT

This documentation describes the hardware specifications of the UWB Module product for wireless PC monitor

and how to install the module. This product adopts the Alereon AL6301/AL5100 chipset solutions.

It is a confidential document of HANSHIN IT.

2. How to install the CY-WDCB7UR?

2.1 UWB RF module applications

This is the UWB module for OEM usage in the application of high speed data transmission. This module

follows standard Half miniCard mechanical dimension which is used in the commercial area. It can be

used in notebook PC or wireless monitor or A/V receiver box.

2.2 Interface signals

This module is based on USB 2.0 interface. Pins of connector have USB and GPIO signals and power.

GPIO signals can be programmed for I2C signal line for device control. Power 3.3V is supplied to the

module. In the module, 1.2V, 2.4V DC are made for the circuit and 3.3V is used for I/O part. The power

consumption is about 1W.

2.3 Installation

The mother board which is installed with the UWB module should have a miniCard connector and latch

parts.

This module is half size minicard and the connector and latch on the mother board should be spaced with

the distance for half size miniCard..

The installation procedure is as follows.

COMPANY CONFIDENTIAL

CY-WDCB7UR installation manual P/N: BN59-01157A 9 of 37

Prepare the module and align the

module to the miniCard connector as

the picture.

If the alignment is done, insert the

module into the connector, press

down the top center of module. Then

you can hear the sound of locking by

latch part.

COMPANY CONFIDENTIAL

CY-WDCB7UR installation manual P/N: BN59-01157A 10 of 37

3. HARDWARE SPECIFICATIONS

3.1 GENERAL

Wireless circuit compatible with IEEE 802.15.3a standard and provide maximum speeds up to 480 Mbps.

3.2 PRODUCT CHACTERISTICS

The CY-WDCB7UR is designed for PC monitor UWB module product. It provides the fast data transportation

between user and PC monitor via wireless network. The device is intended for use in a wide range of system types

with extensive communication and connectivity requirements.

Radio technology: Compliance with 802.15.3a standards

Operating frequency: 3.16GHz ~8.97GHz, BG1, BG3, BG6

Modulation Schemes: Multiband OFDM

Data rate(Mbps)

53.3, 80, 106.7, 160, 200, 320, 400, 480 in BG1, BG3, BG6.

This is the picture which is installed

with the module. Check that the latch’s

clip is locked properly.
