Hanna Instruments Checktemp2 Manual de usuario

EN 50081-1

EN 50082-1

Checktemp2

Pocket-sized

Thermometer

ISTRCHT2

01/97

Visit our Internet Home Page:

http://www.hannacan.com

Authorized Dealer

ISO 9001

Certified Company

SPECIFICATIONS:

RANGE

Checktemp 2Checktemp 2

Checktemp 2 C -50.0 to 150.0°C

Checktemp 2Checktemp 2

Checktemp 2 F -58.0 to 302°F

RESOLUTION

Checktemp 2Checktemp 2

Checktemp 2 C 0.1°C

Checktemp 2Checktemp 2

Checktemp 2 F 0.1°F (-58.0 to 199.9°F)

1°F (200 to 302°F)

ACCURACY (@20°C/68°F)

Checktemp 2Checktemp 2

Checktemp 2 C ±0.3°C (-20 to 90°C)

±0.5°C (outside)

Checktemp 2Checktemp 2

Checktemp 2 F ±0.5°F (-4 to 194°F)

±1°F (outside)

TYPICAL EMC DEVIATION

Checktemp 2Checktemp 2

Checktemp 2 C ±0.3°C

Checktemp 2Checktemp 2

Checktemp 2 F ±0.5°F

ENVIRONMENT 0 to 50ºC

(32 to 122ºF)

95% RH

BATTERY TYPE 1 x 1.4V alkaline

LIFE approx.3000 hours

PROBE Folding,

110mmx3mm diameter

DIMENSIONS 150x30x20 mm

(5.9x1.2x0.8")

WEIGHT 60 g (2.1 oz.)

ACCESSORIES:

HI76504/P1 1.4V battery

Checktemp2

Pocket-sized

Thermometer

OPERATION:

• Turn the Checktemp 2on

by pressing the ON-

OFF switch located on

the front.

• Dip the Checktemp 2

probe into the sample

without exceeding the

maximum immersion

level.

• Stir gently and wait for

a few seconds until

the display stabilizes.

• Read the temperature

value of the solution in

°C or °F (according to

the model) shown on

the display.

• When not in use,

switch Checktemp 2 off.

CALIBRATION

CHECK DEVICE (CCD):

Beneath the battery compartment

cover there is a CCD switch.

When activated, the circuit will send

a signal to the LCD requesting a

0.0°C (32.0°F) reading. The

Checktemp 2 should display 0.0°C

±0.3°C (32°F ±0.5°F). This assures

the user that the reading is reliable

and accurate.

BATTERY REPLACEMENT:

When the Checktemp 2 cannot be

switched on or the display fades,

pull out the battery compartment (af-

ter unscrewing the screw under-

neath the battery clip) and change

the 1.4V battery, paying attention to

the polarity.

Batteries should only be replaced in

a safe area using the battery type

specified in this instruction manual.

RECOMMENDATIONS FOR

USERS:

Before using this product, make sure that it is entirely

suitable for the environment in which it is used.

Operation of this instrument in residential areas could

cause interference to radio and TV equipment.

Any variation introduced by the user to the supplied

equipment may degrade the instrument's EMC

performance.

To avoid electrical shock, do not use this instrument

when voltages at the measurement surface exceed

24 VAC or 60 VDC.

To avoid damage or burns, do not perform any

measurement in microwave ovens.

BACK SIDE

ON/OFF

SWITCH BATTERY

CASE

POCKET

CLIP

LIFT THE

POCKET CLIP

HERE

TO RELEASE

THE PROBE

180° MAXIMUM

IMMERSION

LEVEL

TEMPERATURE

PROBE

FRONT

LIQUID

CRYSTAL

DISPLAY

°c

°C

°c

POCKET

CLIP

(LIFTED)

LOOSEN

SCREW

MEASUREMENT

MODE

CALIBRATION

CHECK

MODE

CALIBRATION

CHECK

DEVICE

BATTERY

COVER

POCKET

CLIP

(LIFTED)

BATTERY

COVER

LOOSEN

SCREW

BATTERY
