Hanna Instruments Checktemp-Dir HI 98510-01 Manual de usuario

Checktemp®-Dip

HI 98509-01 • HI 98510-01

Precision Thermometers

with a Stainless Steel

Weighted Probe

Dear Customer,

Thank you for choosing a Hanna product.

Please read carefully this instruction manual be-

fore using the instrument. If you need additional

technical information, do not hesitate to e-mail us

at [email protected].

These instruments are in compliance with the

directives.

PRELIMINARY EXAMINATION

Remove the instrument from the packing material

and examine it carefully to make sure that no

damage has occurred during shipment. If there is

any damage, immediately notify your Dealer.

Each meter is supplied complete with battery and

instructions.

Note:Conserve all packing material until the in-

strument has been observed to function

correctly. Any defective item must be re-

turned in its original packing.

SPECIFICATIONS

Range -20.0 to 100.0°C / -4.0 to 212°F

Resolution 0.1°C

0.1°F (-4 to 199.9°F) / 1°F (200 to 212°F)

Accuracy

±0.5°C (-20 to 50°C) / ±0.9°C (outside)

±0.9°F (-4 to 122°F) / ±2°F (outside)

Probe Stainless steel, 3 m (9.9’) cable

Environment 0 to 50°C (32 to 122°F);

RH 95% max

Battery Type 1x1.5V AAA alkaline

Battery Life Approx. 3 years of use

Dimensions 106 x 58 x 19 mm (4.1x5.2x0.7")

Weight 80 g (2.8 oz.)

www.hannainst.com

GENERAL DESCRIPTION

Checktemp®-Dip is an accurate thermometer

provided with a fixed stainless steel probe with a 3

meter (9.9’) cable, and weighted so that it can be

dipped into any vat and tank and measure the tem-

perature at different depths.

Due to its hygienic stainless steel probe, it is ideal

for food applications, especially to check the tem-

perature inside wine casks and milk tanks.

Checktemp®-Dip can also be used for applications,

such as fish farms, water reservoirs and pools where

the operator can simply stand on the edge of the

water and throw the probe over.

The accuracy, in spite of the longer probe lead, is

an excellent ±0.3°C (±0.5°F).

In addition, you can check to make sure that your

thermometer is measuring the right temperature with

the Hanna Instruments’ exclusive Cal-Check®

technology.

Two models are available:

• HI 98509-01 (Checktemp®-Dip C) reads tempera-

ture in °C unit

• HI 98510-01 (Checktemp®-Dip F) reads tempera-

ture in °F unit

WARRANTY

These meters are guaranteed for one year against de-

fects in workmanship and materials when used for its

intended purpose and maintained according to instructions.

Probes are guaranteed for a period of six months. This

warranty is limited to repair or replacement free of charge.

Damages due to accident, misuse, tampering or lack of

prescribed maintenance are not covered. If service is re-

quired, contact the dealer from whom you purchased the

instrument. If under warranty, report the model number,

date of purchase, serial number and the nature of the

failure. If the repair is not covered by the warranty, you will

be notified of the charges incurred. If the instrument is to

be returned to Hanna Instruments, first obtain a Returned

Goods Authorization Number from the Customer Service

department and then send it with shipment costs prepaid.

When shipping any instrument, make sure it is properly

packaged for complete protection.

ISTCKTDIP R3 05/05

BATTERY REPLACEMENT

When Checktemp®-Dip cannot be switched on or

the display fades, remove the two screws, remove

the battery cover and change the 1.5V AAA bat-

tery, while paying attention to its polarity.

Replace the cover and tighten the two screws.

Battery should only be replaced in a safe area

and using an alkaline 1.5V AAA type battery.

OPERATION

• Turn the Checktemp®-Dip on and dip the probe in

the sample to be measured.

• Do NOT wrench the probe. If the cable is dam-

aged, the meter may have to be replaced.

• Wait a few seconds for the display to stabilize.

• After use, always switch the meter off

• Variations in readings or a fading display can

indicate a low battery level (see “Battery Re-

placement” section for details).

•Checktemp®-Dip should not be used for continu-

ous measurement at high temperatures. In fact,

even though Checktemp®-Dip can reach 100ºC

(212°F), prolonged measurements at high tem-

perature will reduce the sensor life dramatically.

The ideal operating temperature is in the -20 to

50ºC (-4 to 120ºF) range.

CALIBRATION CHECK SWITCH

Move the Cal-check®switch on the back of the

meter to the “Test” position.

The display should show 0.0°C (±0.5°C) or 32ºF

(±0.9°F).

Contact your dealer or the nearest Hanna Service

Center for recalibration, if necessary.

Move the Cal-check switch back to the “Run” po-

sition, and the display will return to normal mea-

surement mode.

Recommendations for Users

Before using this product, make sure that it is entirely suitable for the

environment in which it is used. Operation of this instrument in residential

areas could cause interference to radio and TV equipment. Any variation

introduced by the user to the supplied equipment may degrade the

instrument's EMC performance. To avoid electrical shocks, do not use this

instrument when voltage at the measurement surface exceeds 24 Vac or

60 Vdc. To avoid damage or burns, do not perform any measurement in

microwave ovens.
