Hanna Instruments DiST 2 Manual de usuario

DiST®1 • DiST®2

DiST®3 • DiST®4

HI 96301 • HI 96302

HI 96303 • HI 96304

Pocket-Sized

EC/TDS Meters

with ATC

www.hannainst.com

SPECIFICATIONS

Range/Resolution

DiST1 (HI96301) 1990ppm / 10ppm

DiST2 (HI96302) 10000ppm / 100ppm

DiST3 (HI96303) 1990µS/cm / 10µS/cm

DiST4 (HI96304)19900µS/cm / 100µS/cm

Accuracy (@20°C) ±2% Full Scale

Calibration manual, 1 point

Calibration solution (optional)

DiST1 (HI96301) HI70032P

DiST2 (HI96302) HI70038P

DiST3 (HI96303) HI70031P

DiST4 (HI96304) HI70039P

Temperature Compensation

Automatic, 5 to 50°C (41 to 122°F)

Environment

0 to 50°C (32 to 122°F); RH 95% max

Battery type 4 x 1.5V alkaline

Battery life approx. 150 hours of use

Dimensions

150x30x21 mm (5.9x1.2x0.8")

Weight 70 g (2.5 oz.)

ACCESSORIES

HI 70031P 1413 µS/cm calibration sa-

chet (20 ml, 25 pcs)

HI 70032P 1382 ppm calibration sa-

chet (20 ml, 25 pcs)

HI 70038P 6.44 ppt calibration sachet

(20 ml, 25 pcs)

HI 70039P 5000 µS/cm calibration sa-

chet (20 ml, 25 pcs)

Dear Customer,

Thank you for choosing a Hanna product.

If you need additional technical informa-

tion, do not hesitate to e-mail us at

[email protected].

These instruments are in compliance with

the directives.

IST96301 12/04

DiST is a registered Trademark of

"Hanna Instruments"

OPERATION

• Remove the protective cap.

• Turn the meter ON sliding the

switch on the top.

• Immerse into solution up to

the max immersion level with-

out touching the bottom of the

beaker.

• Stir gently and wait until the

display stabilizes. Readings are

automatically compensated for

temperature variations.

• The value on the display has

to be multiplied by a factor of

10 for DiST1 & DiST3 and

by a factor of 100 for DiST2

& DiST4 (as shown on the

upper left corner of the LCD) to give

direct reading in ppm or µS/cm.

CALIBRATION

• Immerse the tester up to the maximum

immersion level in the appropriate cali-

bration solution (see Specifications).

• Allow the reading to stabilize and using

a small screwdriver adjust the calibra-

tion trimmer to match the solution value.

E.g. calibrating DiST1 with HI70032P

solution, turn the trimmer to read "138"

(x10 = 1380 ppm).

BATTERY REPLACEMENT

When the meter cannot be switched on or

the display fades, pull out

the battery compartment and

replace all four 1.5V batter-

ies, while paying attention

to their polarity.

Batteries should only be re-

placed in a safe area using

the battery type specified in

this instruction manual.

Recommendations for users

Before using these products, make sure that they are

entirely suitable for the environment in which they are

used. Operation of these instruments in residential areas

could cause interference to radio and TV equipment.

The pins at the end of the sensor are sensitive to

electrostatic discharges. Avoid touching this metal band

at all times. Any variation introduced by the user to the

supplied equipment may degrade the instrument's EMC

performance. To avoid electrical shock, do not use this

instrument when voltages at the measurement surface

exceed 24 Vac or 60 Vdc. To avoid damage or burns, do

not perform any measurement in microwave ovens.

WARRANTY

These meters are guaranteed for six months against de-

fects in workmanship and materials when used for their

intended purpose and maintained according to instruc-

tions. This warranty is limited to repair or replacement free

of charge. Damages due to accident, misuse, tampering

or lack of prescribed maintenance are not covered. If

service is required, contact the dealer from whom you

purchased the instrument. If under warranty, report the

model number, date of purchase, serial number and the

nature of the failure. If the repair is not covered by the

warranty, you will be notified of the charges incurred. If

the instrument is to be returned to Hanna Instruments,

first obtain a Returned Goods Authorization Number from

the Customer Service department and then send it with

shipment costs prepaid. When shipping any instrument,

make sure it is properly packaged for complete protec-

tion.
