1

FZ-12A

1000 026 990

Hand Screw

F

E

D

A B

C

G

1. Removing the Hand Screw

Carefully turn the fan on its side and

place on a table. Ensure the back of

the fan body faces upward. Loosen and

remove the hand screw (A) from the

front base (B) by turning

counterclockwise.

2. Base Assembly

Align the two portions of the circular

base and snap together by gently

pushing the two pillars at the bottom of

the rear base (C) into the two adjacent

sockets of the front base (B). Ensure

the connections are tight and secure.

ASSEMBLY INSTRUCTIONS

center of the base assembly.

Place the power cord (D) through the

Carefully remove all contents from the plastic bag and gift box.

CAUTION : THIS FAN MUST OPERATE STANDING UPRIGHT.

DO NOT USE WITHOUT BASE.

3. Securing the Tower Fan to the

Base Assembly

3

D

ASSEMBLY INSTRUCTIONS

6

5

A

4

4. Securing the Power Cord to the

Base Assembly

With the fan still on its side, locate the

power cord holding bracket at the

bottom of the base assembly. Gently

pull any slack out of the power cord,

place the power cord securely in the

holding bracket and secure the power

cord bracket over the power cord. Then

thread the power cord through the “U”

locating notch on the edge of the base

assembly. ( Fig. 6 )

Insert and tighten the hand screw (A)

into the hexagonal screw hole to

secure the base assembly to the tower

fan unit. ( Fig. 5 )

Return the tower fan to its upright

position.

Note: Do not operate the tower fan unless it is

in its proper, upright position.

Align the arrow on the base assembly

(which is near the central hole of the

base assembly ) with the arrow on the

rear of the tower fan unit and push the

base assembly close to the tower fan

unit tightly.Firmly hold the fan body

steady and rotate the base assembly

clockwise until three plastic hooks on

the tower fan bottom lock unto the three

open slots of the base assembly tightly.

You should now notice that the

hexagonal screw hole on the base

assembly is aligned with the screw hole

on the bottom of the tower fan unit.

( Fig. 4 )

9

VENTILADOR DE TORRE

GIRATORIO DE 71,1CM

FZ-12A

F

E

D

A B

C

G

DESCRIPCIÓN CANTIDAD

Tornillo

1

Base frontal 1

Base posterior 1

1

1

1

Botón de oscilación 1

PIEZA

A

B

C

D

E

F

G

Interruptor de perilla giratorio

Cable de alimentación

Tuerca de montaje de la

rejilla posterior

10
