Hamilton Beach AC16 Manual de usuario

840155503

Blender

Mélangeur

Licuadora

READ BEFORE USE

LIRE AVANT L’UTILISATION

LEA ANTES DE USAR

Le invitamos a leer cuidadosamente este instructivo antes de usar su aparato.

English .............................................................................................................................. 2

USA: 1-800-851-8900

Visit www.hamiltonbeach.com for our complete line of products and Use and Care Guides – as well as delicious

recipes, tips, and to register your product online!

Français .......................................................................................................................... 10

Canada : 1-800-267-2826

Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de nos manuels utilisateur – ainsi

que nos délicieuses recettes, nos conseils, et pour enregistrer votre produit en ligne !

Español............................................................................................................................ 18

En México: 01-800-71-16-100

¡Visite www.hamiltonbeach.com.mx para obtener nuestra línea completa de productos y las Guías de Uso y Cuidado,

además de deliciosas recetas, consejos, y para registrar su producto en línea!

840155503 ENv01.qxd:840153700 ENv01.qxd 7/9/10 8:37 AM Page 1

Meijer.com

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

When using electric appliances, basic

safety precautions should always be

followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical

shock, do not put cord, plug, base, or

motor in water or other liquid.

3. Close supervision is necessary when

any appliance is used by or near

children.

4. Unplug cord from outlet when not in

use, before putting on or taking off

parts, and before cleaning.

5. Avoid contacting moving parts.

6. Do not operate any appliance with a

damaged cord or plug, or after the

appliance malfunctions, or is dropped

or damaged in any manner. Call our

toll-free customer service number for

information on examination, repair or

electrical or mechanical adjustment.

7. The use of attachments, including

canning jars, not recommended or sold

by the appliance manufacturer may

cause a risk of injury to persons.

8. Do not use outdoors.

9. Do not let cord hang over edge of table

or counter, or touch hot surfaces,

including the stove.

10. Keep hands and utensils out of jar while

blending to reduce the risk of severe

injury to persons or damage to the

blender. A rubber spatula may be used

but must be used only when blender is

not running.

11. Blades are sharp; handle carefully –

especially when assembling, disassem-

bling or cleaning inside blender jar.

12. Do not use a broken, chipped, or

cracked blender jar.

13. Do not use broken, cracked, or loose

cutting blades.

14. To reduce the risk of injury, never place

cutting assembly blades on base

without jar properly attached.

15. Always operate blender with lid in

place.

16. When blending hot liquids, remove

center-piece of two-piece lid. Hot liquids

may push lid off jar during blending.

To prevent possible burns: Do not fill

blender jar beyond the 3 cup (750 ml)

level. With the protection of an oven

mitt or thick towel, place one hand on

top of lid. Keep exposed skin away

from lid. Start blending at lowest speed.

17. Screw on cutting assembly firmly. Injury

can result if moving blades accidentally

become exposed.

18. If the jar should turn when the motor is

switched ON, switch OFF immediately

and tighten jar onto cutting assembly.

19. Do not leave blender unattended while

it is operating.

20. To disconnect cord, turn the control to

OFF. Then remove plug from wall outlet.

21. Do not use appliance for other than

intended purpose.

840155503 ENv01.qxd:840153700 ENv01.qxd 7/9/10 8:37 AM Page 2

Meijer.com

Other Consumer Safety Information

This appliance is intended for household

use only. Use for food or liquids only.

WARNING! Shock Hazard: This appliance has

a polarized plug (one wide blade) that reduces

the risk of electric shock. The plug fits only

one way into a polarized outlet. Do not defeat

the safety purpose of the plug by modifying

the plug in any way or by using an adapter. If

the plug does not fit, reverse the plug. If it still

does not fit, have an electrician replace the

outlet.

The length of the cord used on this appliance

was selected to reduce the hazards of

becoming tangled in, or tripping over, a longer

cord. If a longer cord is necessary, an

approved extension cord may be used. The

electrical rating of the extension cord must be

equal to or greater than the rating of the

blender. Care must be taken to arrange the

extension cord so that it will not drape over

the countertop or tabletop where it can be

pulled on by children or accidentally tripped

over.

Do not place blender jar in the freezer filled

with food or liquid. The contents may freeze

and may result in damage to the cutting

blades, jar, blender and possibly result in

personal injury.

NOTICE: To prevent leakage of liquids from

your blender jar, the round rubber gasket

must be properly placed between jar and

cutting assembly as shown in the diagram

on page 4.

Wattage/Peak Power Information

The wattage/ampere rating of the blender is

determined by an Underwriter’s Laboratory

test and is based on available cutting blades

and jar combinations that may not be provided

with your unit, but are available as replace-

ment parts. This is a measure of input

wattage/amperes after 30 seconds of opera-

tion. The blender as provided may draw

significantly less power.

Peak power is the measure of the motor

wattage during the first seconds of operation.

This is when a blender requires the most

power to crush ice, frozen fruit, etc. This is a

better measure of what a blender motor can

consume when power is needed most.

Hamilton Beach Stay or Go™ Personal

Blending Jar (AC16) may be purchased

separately and used with this appliance.

Optional Accessory

840155503 ENv01.qxd:840153700 ENv01.qxd 7/9/10 8:37 AM Page 3

Meijer.com

Parts and Features

BEFORE FIRST USE: After unpacking blender, wash everything except blender

base in hot, soapy water. Dry thoroughly. Wipe blender base with a damp cloth or

sponge. DO NOT IMMERSE BASE IN WATER. Care should be taken when handling

the cutting assembly as the blades are very sharp.

Dispense

Smoothie

Milkshake

Icy Drink

Control Knob

Setting Blender

Speed

Spout Cap Storage

(bottom of blender)

Filler Cap

Lid

Jar

Dispenser

Assembly

Spout Cap

Base

Gasket

Cutting

Assembly

Control Knob

840155503 ENv01.qxd:840153700 ENv01.qxd 7/9/10 8:37 AM Page 4

Meijer.com

How to Assemble

IMPORTANT: Your blender jar and

cutting assembly are subject to wear

during normal use. Always inspect jar

for nicks, chips, or cracks. Always

inspect cutting assembly for broken,

cracked, or loose blades. If jar or cut-

ting assembly is damaged, do not use.

Call our toll-free customer service num-

ber to obtain replacement parts.

1. Make sure blender is unplugged.

Place blender base on clean, dry

surface.

2. Fit gasket over blades as shown in

illustration on page 4. The gasket

must lie flat. Set jar on top of gasket

and screw on cutting assembly.

Make sure the cutting assembly is

firmly screwed onto the jar.

3. Set jar into place on blender base,

making sure it is securely seated.

If not, gently rock the jar until seated.

OPTIONAL: When dispenser is not

needed,

replace dis-

penser with

spout cap.

Remove

dispenser by

rotating

counterclock-

wise (see

“How to Clean” section). Insert

spout cap on jar. Turn spout cap

clockwise to tighten.

4. When spout cap is not in use, snap

onto bottom of blender base for

storage.

How to Operate

1. Plug cord into outlet.

2. Put ingredients in jar. Place lid with

filler cap on jar.

3. Process food or beverages.

NOTE: When blending thin liquids,

do not fill above the 32-ounce/

4 cup/1000 ml mark on blender jar.

4. ALWAYS turn blender off and wait

until blades have stopped rotating

before removing jar.

5. To remove jar after blending is com-

plete, lift the jar straight up. If it is not

easily removed, rock gently and lift.

Do not twist.

To Use the Dispenser:

To dispense thick liquids (such as

milkshakes, smoothies, frozen drinks,

etc.), turn the control knob to

DISPENSE

and pull Dispenser Lever up. Turn OFF

after dispensing.

NOTE: Blender MUST be ON to

dispense thick liquids and frozen drinks.

When dispensing thin liquids, it may not

be necessary to turn the blender ON to

dispense the liquid.

NOTE: NEVER replace jar onto unit

while motor is running.

840155503 ENv01.qxd:840153700 ENv01.qxd 7/9/10 8:37 AM Page 5

Meijer.com

1. Unplug blender from electrical outlet.

2. Wipe blender base and cord with a

damp cloth or sponge. To remove

stubborn spots, use a mild, non-

abrasive cleanser.

3. To clean jar, unscrew cutting

assembly from jar.

4. Carefully remove gasket from

cutting assembly.

5. Remove dispenser assembly from jar

by turning

counterclock-

wise four

revolutions.

NOTE: DO NOT remove seal rings

from dispenser adapter.

6. Carefully wash cutting assembly,

gasket, jar, and lid in hot, soapy

water. Rinse and dry thoroughly.

Do not soak. Do not wash cutting

assembly or gasket in a dishwasher.

NOTE: All parts except the cutting

assembly and gasket may be

washed in the dishwasher (on the

top rack only). Some part distortion

may occur if your household dish-

washer temperature is higher than

normal or if the parts are placed too

close to the heating element.

7. Reassemble cutting assembly and

gasket onto jar, and replace jar onto

blender base. Ensure dispenser

assembly or spout cap are fully

rotated clockwise to lock into posi-

tion (reverse of Step 5 above).

8. Store blender with lid or filler cap

removed to prevent container odor.

How to Clean

Quick cleaning should only be used to

rinse the blender between batches of

processing the same food. When the

processing of a single type of food is

finished, the blender should be disas-

sembled and thoroughly cleaned as

instructed below.

To quick clean, pour 2 cups (500 ml)

warm water in jar and add 1 drop liquid

dishwashing detergent. Run the blender

DISPENSE

for 10 seconds. Flush

soapy water through dispenser until

cleaned. Discard soapy water. Rinse

blender jar with clean water. Flush clean

water through dispenser until cleaned.

This function is not a substitute for

regular cleaning as instructed below

This function should never be used

when blending any mixture containing

eggs, milk, or any other dairy products.

Quick Cleaning

Regular Cleaning

Electrical Shock Hazard.

Disconnect power before cleaning.

Do not immerse cord, plug or base in any liquid.

wWARNING

840155503 ENv01.qxd:840153700 ENv01.qxd 7/9/10 8:37 AM Page 6

Meijer.com

1. Remove dispenser assembly cap by

rotating coun-

terclockwise.

2. Wash dispenser and parts in hot,

soapy water. Rinse and dry

thoroughly. Do not soak.

NOTE: Do not remove seal rings

from adaptor.

3. Reassemble plunger inside of

dispenser body and rotate cap

clockwise until tight.

Troubleshooting

PROBLEM

Blender leaks.

Ice not crushed.

Does not

blend well.

Does not dispense.

Dispenser leaks.

Cannot remove

cutting assembly.

PROBABLE CAUSE

• Tighten cutting assembly on jar.

• Make sure gasket is in place on cutting assembly.

• Make sure gasket is not damaged. If damaged, please

call our toll-free customer service number to order a

replacement.

• Make sure lid with filler cap is pushed down tightly on

jar.

• See ice crushing instructions in “Blending Specific

Foods” section.

•Make sure enough liquid has been added. A

minimum of 10 ounces (300 ml) is recommended.

• Make sure blender is ON.

• Make sure seal rings are in place on dispenser

adapter.

• Tighten dispenser cap (located above dispenser body).

• Loosen collar by holding jar and turning cutting

assembly counterclockwise.

Dispenser

Assembly

Cap

Dispenser

Assembly

Body

Adaptor

Seal Rings

Optional Cleaning

Plunger

840155503 ENv01.qxd:840153700 ENv01.qxd 7/9/10 8:37 AM Page 7

Meijer.com

Crushing Ice

For best performance, when a recipe

calls for liquid, place the liquid in

blender jar followed by the ice cubes.

Ensure ice cubes are separated. When

only crushed ice is desired, add 1 cup

(250 ml) of ice cubes to jar. Place lid on

blender jar then Pulse on any of the 5

pulse speeds. Allow blades to come to

a complete stop between pulses.

Continue until ice is crushed to desired

consistency. For best results always

crush ice immediately after removing

from freezer.

General

To add foods when blender is operat-

ing, remove filler cap from container lid

and add ingredients through the open-

ing. Do not store food or liquids in the

blender jar.

Hamilton Beach Stay or Go™ Personal

Blending Jar (AC16) may be purchased

separately and used with this appliance.

To Order Call:

1.800.851.8900 (U.S.)

1.800.267.2826 (Canada)

01.800.71.16.100 (Mexico)

or visit hamiltonbeach.com

Blending Tips

Optional Accessories

840155503 ENv01.qxd:840153700 ENv01.qxd 7/9/10 8:37 AM Page 8

Meijer.com

LIMITED WARRANTY

This warranty applies to products purchased in the U.S. and Canada. This is the only

express warranty for this product and is in lieu of any other warranty or condition.

This product is warranted to be free from defects in material and workmanship for a

period of three (3) years from the date of original purchase. During this period, your

exclusive remedy is repair or replacement of this product or any component found to

be defective, at our option; however, you are responsible for all costs associated with

returning the product to us and our returning a product or component under this

warranty to you. If the product or component is no longer available, we will replace with

a similar one of equal or greater value.

This warranty does not cover glass, filters, wear from normal use, use not

in conformity with the printed directions, or damage to the product resulting from

accident, alteration, abuse, or misuse. This warranty extends only to the original

consumer purchaser or gift recipient. Keep the original sales receipt, as proof of

purchase is required to make a warranty claim. This warranty is void if the product is

used for other than single-family household use.

We exclude all claims for special, incidental, and consequential damages caused by

breach of express or implied warranty. All liability is limited to the amount of the

purchase price. Every implied warranty, including any statutory warranty or

condition of merchantability or fitness for a particular purpose, is disclaimed

except to the extent prohibited by law, in which case such warranty or condition

is limited to the duration of this written warranty. This warranty gives you specific

legal rights. You may have other legal rights that vary depending on where you live.

Some states or provinces do not allow limitations on implied warranties or special,

incidental, or consequential damages, so the foregoing limitations may not apply to

you.

To make a warranty claim, do not return this appliance to the store. Please call

1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada or visit hamiltonbeach.com in

the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and

series numbers on your appliance.

840155503 ENv01.qxd:840153700 ENv01.qxd 7/9/10 8:37 AM Page 9

Meijer.com

Tabla de contenidos

Otros manuales de Licuadora de Hamilton Beach

Hamilton Beach

Hamilton Beach 58915-CN Manual de usuario

Hamilton Beach

Hamilton Beach HBH450R Manual de usuario

Hamilton Beach

Hamilton Beach Rio Series Manual de usuario

Hamilton Beach

Hamilton Beach 51103 Manual de usuario

Hamilton Beach

Hamilton Beach 53601C Manual de usuario

Hamilton Beach

Hamilton Beach MultiBlend 58158 Manual del propietario

Hamilton Beach

Hamilton Beach 52300 Manual de usuario

Hamilton Beach

Hamilton Beach 840065601 Manual de usuario

Hamilton Beach

Hamilton Beach 51101B - Single-Serve Blender With Travel... Manual de usuario

Hamilton Beach

Hamilton Beach 59769-CN Manual de usuario

Hamilton Beach

Hamilton Beach 908 Series Manual de usuario

Hamilton Beach

Hamilton Beach HBH450 Manual de usuario

Hamilton Beach

Hamilton Beach Tango Series Manual de usuario

Hamilton Beach

Hamilton Beach 840164501 Manual de usuario

Hamilton Beach

Hamilton Beach HBF500 Manual de usuario

Hamilton Beach

Hamilton Beach Summit Series Manual de usuario

Hamilton Beach

Hamilton Beach 908 Series Manual de usuario

Hamilton Beach

Hamilton Beach 840243700 Manual de usuario

Hamilton Beach

Hamilton Beach HBF1100S series Manual de usuario

Hamilton Beach

Hamilton Beach HBH755 Series Manual de usuario

Hamilton Beach

Hamilton Beach 53514 Manual de usuario

Hamilton Beach

Hamilton Beach 56205 Manual de usuario

Hamilton Beach

Hamilton Beach Turbo-Twister 59770 Manual de usuario

Hamilton Beach

Hamilton Beach HBH550 Manual de usuario

Manuales populares de Licuadora de otras marcas

ROTOR

ROTOR 1125.201 Manual de usuario

Braun

Braun Multiquick 5 Vario series Manual de usuario

ARENDO

ARENDO MIRA 305424 Manual de usuario

CHEF-BUILT

CHEF-BUILT CCB-3500 Manual de usuario

Viconte

Viconte VC-4406 Manual de usuario

Oster

Oster BLSTAB-CB0 Manual de usuario

HOFFEN

HOFFEN MC-3005 Manual de usuario

Black & Decker

Black & Decker BLC18750DM Manual de usuario

Sunbeam

Sunbeam 4182 Manual de usuario

Bialetti

Bialetti FMX35 Manual de usuario

Black & Decker

Black & Decker BL8000 Manual de usuario

Duronic

Duronic BL530 Manual de usuario

Exquisit

Exquisit MS 3002 wes Manual de usuario

Lumme

Lumme LU-KP1891A Manual de usuario

Binatone

Binatone HB-735 Manual de usuario

Moulinex

Moulinex LM936E10 Manual de usuario

Oster

Oster VERSA Manual de instalación y operación

Ninja

Ninja NN210Q Manual de usuario
