User’s Manual

GEM-EX

Dual 4K HDMI, USB, AUDIO, & RS-232 over 1

CAT6 Extender with Daisy-Chainable Receivers

Part Number Function

GEM-EX-S Dual Video, USB, Audio, RS-232 Sender with 2-Port

Splitter

GEM-EX-R Dual Video, USB, Audio, RS-232 Receiver with

Daisy-Chain output

UMA1291 Rev NC

Order toll

free in the U.S.

800

959

6439

FREE technical support: 714-641-6607 or [email protected]

Hall Research, 1163 Warner Ave. Tustin, CA 92780

www.hallresearch.com

CUSTOMER

SUPPORT

INFORMATION

GEM

20 Hall Research, LLC

Table of Contents

1.0 Introduction ................................................................................. 3

Product Description ............................................................................... 3

Features ................................................................................................. 4

2.0 Package Contents ........................................................................ 5

3.0 Setup .............................................................................................. 5

Installation ............................................................................................. 5

DisplayPort Adapters ............................................................................ 6

Single Video Display Receiver ............................................................. 7

RS-232 Baud Rate Programming and Dual-Port Support ..................... 7

4.0 Connector and Indicator Functions ......................................... 8

GEM-EX-S (front) ................................................................................ 8

GEM-EX-S (Rear) ................................................................................. 9

GEM-EX-R (front) .............................................................................. 10

GEM-EX-R (Rear) .............................................................................. 11

5.0 Troubleshooting ........................................................................ 12

Contacting Hall Research .................................................................... 12

6.0 Specifications ............................................................................. 13

FCC Notice

This device complies with Part 15 of the FCC Rules. Operation is subject to the following

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference even if it causes undesired operation.

This equipment has been desinged to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy, and if

it is not installed and used in accordance with the instruction manual, it may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference, in which case the user will be required to correct the

interference at his own expense.

Dual 4K Extender with USB 2.0, Audio, and RS

232

20 Hall Research, LLC

1.0 Introduction

Product Description

The GEM-EX is comprised of the GEM-EX-S sender and the GEM-EX-R receiver.

The system is used to extend USB 2.0, Audio, dual RS-232, and dual display

HDMI video supporting various resolutions including 1080p @ 60 Hz and 4K

UHD @ 30 Hz. These signals are extended to one or more receivers up to a

distance of 100 m (328 ft.) over a single CAT6 cable.

The sender features two HDMI inputs, one USB input, one analog audio input,

and a dual-port capable RS-232 port for connection to a dual-head PC. The audio

input is embedded into HDMI A. It provides two local HDMI outputs

(corresponding to the two HDMI inputs) and features an internal USB hub with

two local USB outputs. Additionally, there are two separate RJ45 output ports to

extend these signals to multiple remote locations.

The receiver provides two HDMI outputs, 6 USB ports, an analog audio output,

and a dual-port capable RS-232 port. Two of the USB ports are labeled for use

with keyboard and mouse; however, they can also be connected to other USB

devices such as KVM switches or touch-screen displays if desired. The audio

output is de-embedded from HDMI A.

For connection of other USB devices such as printers or scanners, four

additional general-purpose USB 2.0 ports are available. For security purposes,

USB memory devices are not supported by default. If you want to enable USB

memory support, please contact Hall Research.

In a setup with one Sender going to only one Receiver, the USB ports

automatically pair with the Sender. However when there is more than one GEM-

EX Receiver connected to the same Sender, only one Receiver can be paired at a

given time. Pairing is accomplished using a push button on the front panel of the

Receiver. A corresponding LED next to the button indicates USB pairing status

with the Sender.

Each Receiver features an RJ45 “LINK OUT” port that can be daisy-chained to

down-stream Receivers. All signals are re-buffered, so the LINK OUT port can

drive cables to 100 meters long.

It is important to note that the RJ45 output ports (on the Sender or the

Receiver), can also be connected to ULTRA-V Receivers. ULTRA-V Receivers

provide only one video output and no USB. The ULTRA-V Receivers show Video

A by default, however, they can be configured to display Video B if desired.

Please refer to the ULTRA-V User’s Manual for further details.

GEM

20 Hall Research, LLC

Typical Connection Diagram

Features

 Supports high resolution HDMI video including FHD

(1920x1080), WQHD (2560x1440), and 4K UHD (3840x2160)

 Two video streams, one USB port, one audio signal, and two RS-

232 ports extended over a single CAT6 cable up to 100 m/328 ft.

 Full plug-and-play support with USB keyboard, mouse, and

connected peripherals

 Computer OS independent - No driver or software required

 Local HDMI and USB outputs on the Sender

 Two Sender extension outputs and one Receiver daisy-chain

output to distribute video to multiple locations

 No video calibration required; no video quality reduction due to

cable length or resolution

 Locking power supply connector to prevent inadvertent

disconnection

 Sender includes mounting ears for standard 19” rack; Receiver

includes mounting brackets for surface mounting.

Dual 4K Extender with USB 2.0, Audio, and RS

232

20 Hall Research, LLC

2.0 Package Contents

GEM-EX-S

(x 1) GEM-EX-S

(x 2) RACK MOUNT EARS and screws

(x 1) POWER SUPPLY (Hall P/N 511-IEC5V4AP5L)

(x 1) USER’S MANUAL CARD

GEM-EX-R

(x 1) GEM-EX-R

(x 2) Surface-mount brackets

(x 1) POWER SUPPLY (Hall P/N 511-IEC5V4AP5L)

(x 1) USER’S MANUAL CARD

3.0 Setup

Installation

 Connect the PC HDMI outputs to the GEM-EX-S ports marked “HDMI A IN”

and “HDMI B IN” using quality HDMI cables

 Connect the PC USB to the GEM-EX-S port marked “USB IN” using a USB

cable

 Optionally, connect PC analog audio to the GEM-EX-S port marked

“AUDIO IN” using a 3.5 mm audio cable, to embed an external audio signal

into HDMI A

 Optionally, connect an RS-232 device (or two, using Hall Research

CA10223 and CA10224 cables.) Use PC GUI to set baud rate(s)

 Optionally, connect HDMI displays to the HDMI A/B OUT ports, and USB

peripherals to the USB LOCAL ports

 Using a CAT6 cable, connect the GEM-EX-S “LINK OUT” port to the GEM-

EX-R “LINK IN” port

 Connect remote HDMI displays to the GEM-EX-R HDMI A and HDMI B

output ports

 Connect keyboard, mouse, KVM Switch, or touch-screens to the GEM-EX-

R ports marked as KBRD/MOUSE

 Optionally, connect other USB devices to any of the USB 2.0 ports

 Optionally, connect external speakers to “AUDIO OUT” to use audio from

“HDMI A” or “AUDIO INPUT” of GEM-EX-S

 Once all other connections have been made, apply power to the GEM-EX-S

and GEM-EX-R using the included power supplies

GEM

20 Hall Research, LLC

DisplayPort Adapters

While HDMI is the most widely adopted video standard, there are a number of

computer and display manufacturers that rely on DisplayPort for higher

resolutions such as 2560 or 4K. Hall Research offers 4K compatible adapters

to convert between these two video standards.

To connect to a source (PC) with Displayport output, use GC-DP-HD.

Model GC-DP-HD: DisplayPort source to HDMI output

Virtually all monitors and TVs have HDMI (or DVI) inputs, but if your display

only has Display port input, the following adapter converts HDMI to DP.

Model GC-HD-DP: HDMI source to DisplayPort output

NOTE These adapters are unidirectional. For example, the

DisplayPort to HDMI adapter cannot convert an HDMI signal

to DisplayPort.

Dual 4K Extender with USB 2.0, Audio, and RS

232

20 Hall Research, LLC

Single Video Display Receiver

In cases where only a single video display is required, an ULTRA-V-R Receiver

can be connected to either the GEM-EX Sender or Receiver. The Receiver will

display the video coming from HDMI A by default, or it can be configured to

display video from HDMI B if desired. Please refer to the ULTRA-V User’s

Manual for more information.

Model ULTRA-V-R: Single HDMI output Receiver

RS-232 Baud Rate Programming and Dual-Port Support

The RS232 ports on the GEM-EX-S and GEM-EX-R have different baud rates by

default. RS-232 Port A defaults to 9600 baud. RS-232 Port B defaults to 115200

baud.

These can change to any standard rate between 2400 and 15200 using free PC

GUI software. Both sender and receiver are programmed separately.

The GEM-EX has a dual-port RS-232

output, supporting a second RS-232

extension.

This requires the use of adapter cables

CA10233 and CA10224, sold separately.

NOTE Baud Rate Conversion: When the GEM-EX-S and GEM-EX-R

are set to different baud rates; they will automatically

convert between the two.

GEM

20 Hall Research, LLC

4.0 Connector and Indicator Functions

GEM-EX-S (front)

1 2 3 4

1) SERVICE: USB-Mini connection, used for upgrading firmware or

configuring parameters such as EDID and RS-232 baud rates via free PC

GUI.

2) USB HUB: LED indicates that the hub is active (note that PC/Host has

the ability to put the hub in “selective suspend” mode in which case the

Hub LED will turn off. Hosts usually do this if no downstream devices

are connected to the hub.

3) VID/LINK: Status indicators of HDMI A/B

a. VID: This LED is lit when HDMI video input is present.

b. LINK: When this LED is solidly on, it indicates the system has

detected at least one Receiver and is actively transmitting video

and data. Blinks if the system has never seen a compatible

Receiver or it is not transmitting video.

4) POWER: Power LED lights when power is supplied.

Dual 4K Extender with USB 2.0, Audio, and RS

232

20 Hall Research, LLC

GEM-EX-S (Rear)

1 2 3 4 5 6 7

1) HDMI A IN/OUT: HDMI A input port and local output. HDMI A IN is

extended to GEM-EX-R HDMI A OUTPUT.

2) HDMI B IN/OUT: HDMI B input port and local output. HDMI B IN is

extended to GEM-EX-R HDMI B OUTPUT.

3) AUDIO IN: Analog audio input. When connected, it embeds and replaces

the audio in HDMI A. Audio is extended to GEM-EX-R HDMI A and

AUDIO OUT ports.

4) USB HOST IN/LOCAL: USB Input port, and local outputs. HOST IN is

extended to GEM-EX-R USB ports.

5) RS-232: RS-232 communication port, extended to GEM-EX-R. Port A

defaults to 9600 baud. Port B defaults to 115200 baud.

6) REMOTE OUTPUTS/LINK 1/LINK 2: Two separate outputs for

connection to remote GEM-EX-R Receivers. Use CAT6 cable to extend

up to 100 m/328 ft.

a. GREEN LED on left side of ports indicates an active link to

GEM-EX-R or ULTRA-V-R.

7) 5V DC: Power input. Connect supplied 5V DC locking power supply to

power Sender.

GEM

20 Hall Research, LLC

GEM-EX-R (front)

1 2 3 4

1) SERVICE: USB-Mini connection, used for upgrading firmware or

configuring parameters such as USB Mass Storage Class device filtering

or RS-232 baud rates via free PC GUI.

2) USB 2.0 PAIRING: When only one Receiver is connected to a Sender, the

Receiver will automatically pair by default and the PAIRING LED will be

on. If multiple Receivers are connected, the user needs to decide which

Receiver’s USB ports is to be paired with the Sender. To change pairing

to a different Receiver, press the button and the PAIRING LED will light.

If the pairing LED is solidly lit, the Receiver has sucessfully paired with

the Sender, but if it is blinking, the pairing was unsuccessful and you

should press the pairing button again until the LED is solidly lit.

3) HDMI A/B VID/LINK: Status indicators of HDMI A/B

a. VID: This LED is lit when HDMI video is being output.

b. LINK: This LED indicates the system is actively receiving video

and data. Blinks if the system is not receiving video.

4) POWER : Power LED lights when power is supplied.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Extensor de Hall Research Technologies

Hall Research Technologies

Hall Research Technologies EMX-DVI Instrucciones de funcionamiento

Hall Research Technologies

Hall Research Technologies UH-2C-3S Manual de usuario

Hall Research Technologies

Hall Research Technologies UV-1 Manual de usuario

Hall Research Technologies

Hall Research Technologies U22-160-DP Manual de usuario

Hall Research Technologies

Hall Research Technologies ULTRA-4K Series Manual de usuario

Hall Research Technologies

Hall Research Technologies UHBX-8X Manual de usuario

Hall Research Technologies

Hall Research Technologies U22-160 Manual de usuario

Hall Research Technologies

Hall Research Technologies HR-733 Manual de usuario

Hall Research Technologies

Hall Research Technologies U3CAT6 Series Manual de usuario

Hall Research Technologies

Hall Research Technologies UHBX-S Manual de usuario

Hall Research Technologies

Hall Research Technologies SP-DVI-2A Manual de usuario

Hall Research Technologies

Hall Research Technologies EX-HDMI-2A Manual de usuario

Hall Research Technologies

Hall Research Technologies UH-1D Manual de usuario

Hall Research Technologies

Hall Research Technologies ECHO Series Manual de usuario

Hall Research Technologies

Hall Research Technologies ULTRA-4K Series Manual de usuario

Hall Research Technologies

Hall Research Technologies UU-2X4 Manual de usuario

Hall Research Technologies

Hall Research Technologies UH-2C Manual de usuario

Hall Research Technologies

Hall Research Technologies UD2A-EDID Manual de usuario

Hall Research Technologies

Hall Research Technologies UH-1C Manual de usuario

Hall Research Technologies

Hall Research Technologies EXHD-RG6 Manual de usuario

Hall Research Technologies

Hall Research Technologies U2-160-DP Manual de usuario

Hall Research Technologies

Hall Research Technologies UH-2D-3S Manual de usuario

Hall Research Technologies

Hall Research Technologies VERSA-4K Series Manual de usuario

Hall Research Technologies

Hall Research Technologies UV232A Manual de usuario

Manuales populares de Extensor de otras marcas

SY HDBT-60T Manual de usuario

Appsys ProAudio

Appsys ProAudio ADX-16 Manual de usuario

Atlona

Atlona RS232 Manual de usuario

IDK

IDK OPF-TH1000-A Manual de usuario

Enable-IT

Enable-IT 824WP Manual de usuario

Worx

Worx Landroid RadioLink WA0864 Hoja de especificaciones

TP-Link

TP-Link TL-WA730RE Manual de usuario

Camplex

Camplex CMX-HDMI-SFPL Manual de usuario

SC&T

SC&T HE03-4K Manual de usuario

Marmitek

Marmitek MegaView70 Manual de usuario

Samsung

Samsung SCS-26UC4 Manual de usuario

Foxun

Foxun SX-GES24 Manual de usuario

MuxLab

MuxLab 500771 Manual de usuario

foxunhd

foxunhd SX-AEX01 Manual de usuario

TERK Technologies

TERK Technologies LFIRX2 Manual de usuario

Devolo

Devolo Audio Extender Manual

Edimax

Edimax EW-7438RPn V2 Manual de usuario

Shinybow USA

Shinybow USA SB-6335T5 Manual de usuario
