Haier XQB50-10 Manual de usuario

Automatic Washing Machine

XQB50-10

SERVICE MANUAL

10 minutes QUICK WASH program,4 water level

Full plastic cabinet, never rusts

Spray current

Features

Special No.: SM XQB50-10-01 Edition: 2006.7.18

Models

Automatic Washing Machine

Model: XQB50-10

1.Contents 1

2..

3. Specifications 3

4. 4

5. 5

6. Net dimension 6

7. 6

8. Parts and functions 10

9. Maintenance service and trouble shooting 11

10. Wiring diagram 17

11. Exploded view 18

12. List of parts 20

Features 2

Safety precautions

Warning and cautions

Installation and accessory parts

Contents

Brand new appearance:

The model is novel and nice, with full streamline curving shape to make the whole unit compact

in structure.

Music prompting: It adopts the nationally originated music buzzer, which will prompt

you the current mode during washing with sweet music.

Low vibration and low noise: the low noise retarder clutch, motor and mute drain

motor, and the advanced air damping system can guarantee the washing machine

operating under low vibration and noise.

Automatic power-off function: If the washing machine is not started after the power is

switched on, or the washing is finished, the power will be switched off automatically

after 5 minutes for the sake of safety.

Alarm against breakdown: the washing machine will alarm with abnormal display and

buzzer when the drain hose is not put down, or when top lid is open, or the laundries are

slanting during automatic program or spinning, or when the imbalance can not be revised.

Automatic imbalance-revising function: during spinning, if the laundries are slanting

and bumping the tub, the washing machine will add one rinse automatically to revise the

imbalance.

10-minute quick wash program (suitable for laundries less than 2.0kg): please select

this program to wash laundries with light dirt. This program only costs 10 minutes for

the whole washing procedure from water inlet, wash, rinse to spin.

4-water level selection: This machine offers 4 water level selection with lowest 20L

level. It can offer water levels corresponding laundries from below 1.0kg to 5.0kg. It can

save more water.

Automatic Washing Machine

Model: XQB50-10

Features

Automatic Washing Machine

Model: XQB50-10

Model

New Model XQB50-10

Free standing

Built under ×

EAN code 6901570056449

Energy eff iciency class —

Features for use

Wash capac ity kg 5

Spin capacity kg 5

Preset H

Residual dampness %

Contral model

contraller

Normal computerized

Fuzzy c omputerized

Frequency c onvers ion

Service features

Programs

Short cycle

Inlet heating select

Heating selection

Spinning cycle (selector )

Spinning cycle (v ariable)

Start/Pause

Automatic balncing

Aesthetics

Drain type

Door (glass=g / plastic=p)

Adjustable f eet

Desiccation

Air-dry

Dr y in g

Te chnical d ata

Voltage/f requency V/H z

Water cons umtpion L

Wash pow er W

Spin pow er W

Special func tion

Air- Bubble

Feet w heel

Water fall current

Dimensions (measurements)

Height / built under mm

Width mm

Depth / w ith open door mm

Dimensions packed ( measurements packed)

Height mm

Width mm

Depth mm

Net weight kg

Gross weight kg

20'Container load Set s

40 Container load Set s

40HContainer load Set s

<115%

directly drain (drain down )

110v 60Hz

117

380

250

890

520

970

586

160

Specifications

Automatic Washing Machine

Model: XQB50-10

Please plug the plug on special 110V AC

receptacle.Please guarantee that the

earthing wire is ear-thed reliably.

The power cord plug should be convenient

to be pluged in or pluged out with hand

while the washing machine runs normally.

Be sure to pull the plug out and close the

water tap when the machine is idle,when

moving the machine,or when cleaning

the machine.Do not use wet hand to ins-

ert or pull out the power plug.

In case the washing machine is installed on ground with

carpet, do not block the ventilation hole with carpet.

Do not let the machine share one receptacle with other electric appliances. If the power plug is damaged, or the

plugging into the receptacle is loose, do not use the plug any more.

Do not wash water-proof laundries like the raincoat,

bike covers etc. to avoid abnormal vibrations in spinning.

Do not use water hotter above 50 C .

Do not put the machine at damp place like

the bathroom. Never wash it with water.

Do Not put wet laundries on the control panel.

soft items

The ventilation holes

at the bottom

earth

Do not bend ,extend,twist,bind by force.Do not press or nip it with weight.

Keep the pin of the power plug clean,if the power plug is polluted with dust,

please wipe with dry cloth carefully.

Safety precautions

Automatic Washing Machine

Model: XQB50-10

Do not decompose, repair or alter the

machine by yourself.

Do not put any hot or heavy items (such

as the kettle with hot water ) on the

washing machine.

Do not wash laundries with volatile

materials (such as thinner, petrol etc.)

The handicapped or children without

care shall not use the machine. Keep the machine away from direct

sunlight and heat source like the heater.

Do not stretch hands into the working

machine. It is dangerous even if the

rotation is slow. Take special care of

the children.Do not let the children

climb the washing machine.

Petrol

Thinner

To prevent your laundries and washing

machine from damage,be sure to take

out all of the foreign materials from your

pocket,such as coins,buttons,sand or

hairpins etc.

Before washing,please check if the water

tap is open ,and if the water inlet pipe is

connected properly.

It is suggested to use low-foaming was-

hing powder

To prevent the lint in the tub from blocking

the cascade outlet and influencing the

cascade effect, please keep the lint filter

in good condition, and install it to proper

position during washing.

Warning and cautions

Unit mm

Figure 1

INSTALLATION AND ACCESSORY PARTS

Please install and adjust the washing machine according to the requirement of this manual.

It is important for user's safe and proper using the machine.

The distance of washing machine to wall should be longer than 20mm.The largest

allowed slope of the base of the machine is 2 . The slanting or rough ground will

result in unstable running or stoppage of the machine. Please adjust it with following

methods:

Confirm it's horizontal:

Hang the lead line to confirm if it is horizontal.

Adjust the installation position

Automatic Washing Machine

Model: XQB50-10

Net dimension

Adjust the adjustable foot:

Loosen Fasten

High Low

Adjustable nut

Adjustable foot

1.To twist the adjustable foot, please first lift up the side of the foot slightly, loosen

the adjustable nut, and twist the foot.

2.Fasten the nut after adjustment.

1.Lean the machine down gently with the

front surface facing the ground.

3.Extend the drain hose from the left side.

Push the drain hose into the groove with

hands.

2.Pull out the drain hose from the right side

groove.

Back

Front

Soft item

Use this groove after

direction changing

Push the drain hose

into the groove with

hands at this point

How to change the direction of the drain hose

Automatic Washing Machine

Model: XQB50-10

INSTALLATION AND ACCESSORY PARTS

Automatic Washing Machine

Model: XQB50-10

INSTALLATION AND ACCESSORY PARTS

If the extra hose is too long, cut it either

at point A or B.

<10cm

> 30mm

<1.5m

Usage of the drain hose

The drainage shall be smooth with the drain hose.

1.The height of the drain hose shall be

less than 10cm , or the drainage will

not be smooth enough and cause

incomplete drainage.

2.Do not tramp or press the drain hose.

3.If the drain hose is too long, cut it at mid point.

To make smooth drainage, cut the front end of

the hose slantingly.

4.If extra drain hose is needed , please make

separate purchase. The inner diameter of the

extra hose shall not less than 40mm, and the

length shall not exceed 1.5m.

Automatic Washing Machine

Model: XQB50-10

Water absorption cushion

Nut of the water inlet hose

Jointer of the water inlet valve

Install the water inlet hose

1. Insert a new flat washer into each end of the inlet hoses. Firmly put the

washers in the coupling.

2. Connect the water inlet hoses to the water faucet.

Use the new hose sets supplied with the washer.

Any other old hose sets should not be used.

You may have to use pliers to tighten the coupling.

Do not over tighten because you may cause

damage to the valve.

Note:

3. Connect the other ends to their respective cold and hot water inlet valve

located at the rear of the washer

Check the connection between the water inlet

hose and the water tap

1.Swaying the hose gently to confirm if it is fastened

stable.

2.After installation, open the tap to check if it leaks.

3.Do not bend the hose with overstrain.

4.Before each usage please check if the connection

between the water inlet hose and the water tap,

and the connection between the water inlet hose and

washer are firm, so as to prevent dropping from

improve Installation position.

1.Close the water tap.

2. Pull off the water inlet hose from the water tap

and washer

Take down the water inlet hose

4.Fasten the nut. Swing it gently to confirm if it's suitable.

INSTALLATION AND ACCESSORY PARTS
