Haier HFU-09HA03/R(DB) Guía de instalación y uso

Domestic

Air conditioner

HFU-09HA03/R(DB)

HFU-12HA03/R(DB)

HFU-18HA03/R(DB)

1. READ THIS MANUAL CAREFULLY TO

DIAGNOSE TROUBLE CORRECTLY

BEFORE OFFERING SERVICE.

2. THIS MANUAL IS USED BY QUALIFIED

APPLIANCE TECHNICIANS ONLY.

3. HAIER DOES NOT ASSUME ANY

RESPONSIBILITY FOR PROPERTY

DAMAGE OR PERSONAL INJURY FOR

IMPROPER

SERVICE PROCEDURES DONE BY ONE

UNQUALIFIED PERSON.

CAUTION

DC Inverter

Console Type

stnetnoCfoelbaT

Table of Contents

1. Features.…………………………...…………………………..…….…….…............ 1

2. Specifications……….……………………………….……………. .….….……….. 2

3. Remote controller lists…….…………..………….….….……….………………... 5

4. Sensors lists…...….….…………………………………………………………........ 5

5. Dimensional drawings…………………………………………………………….....6

6. Operation range……………………………………...…………………………….....8

7. Piping diagrams……………………………………………………………. .…….... 9

8. Wiring diagrams………………………………………………….…………….........10

9. Performance curves diagrams ...............………………………………. ……...13

10. Sound level……………………………………………………… ………………...

11. Accessories……………………………………………………………………….. 38

12. Control systems…………………………………………………………………..

13. Center of gravity…………………………………………………………………..

14. Installations……………………………………………………………………..… 41

Domestic air conditioner

HFU-09,12,18HA03/R2(DB)

9.1 Cooling capacity-temperature curves..................................................................................13

9.2 Heating capacity-temperature curves………………………………………...........................

9.5 Cooling discharge pressure cu rves................................................................................... 25

9.6 Cooling suction pressure cu rves........................................................................................

9.7 Heating discharge pressure curves.....................................................................................31

9.8 Heating suction pressure curves........................................................................................

9.3 Cooling power consumption value curves..........................................................................19

power consumption value curves..........................................................................

9.4 Heating

The end

…….........................................................................................................

Carpet airflow: This setting blows air from upper outlet only or from both upper and lower outlet

Dry function: Make dehumidifying in the room when the unit is working in the "DRY" mode

Child lock: Avoid the child's wrong operation on the remote controller

24 Hour timer: Use the timer function to set on,or off,or from on to off,or from off to on

Auto restart: The function permits automatic return to previous peration conditions

Easy clean design: The panel is easy to wash and the airflow vents can be detached without

any special tools for quick cleaning of the inside of the air conditioner

Sleep mode: The setting temprature and the indoor noise can be adjusted to a more

comfortable level when you set the "sleep mode"during night sleep

4 Fan setting: Slect the fan speed LO,MED,HI,AUTO

Entire auto mode: You can set a tempreture value,with which the unit can be adjusted

theoperation mode automatically

Features

Domestic air conditioner

1. Features

HFU-09,12,18 HA03/R2(DB)

HFU-09,12 HA03/R2(DB) HFU-18HA03/R2(DB)

HFU-09,12,18HA03/R2(DB) Specifications

Domestic Air Conditioner

2. Specifications

NOMINALCAPACITY and NOMINAL INPUT

Model HFU-09HA03/R(DB) HFU-12HA03/R(DB) HFU-18HA03/R(DB)

Cooling(1) min.~norm.~max. w 750.~2600.~3200. 850.~3600.~4200. 1050.~5000.~5800.NORMINAL

CAPACITY(3-4) Heating(2) min.~norm.~max. w 800.~3200.~4000. 1000.~4000.~4500. 1200.~6000.~7000.

Cooling min.~norm.~max. w 300.~760.~1150. 320.~1100.~1450. 420.~1550.~2100.NORMINAL

INPUT Heating min.~norm.~max. w 350.~880.~1200. 380.~1100.~1600. 550.~1650.~2300.

EER Cooling 3.42 3.27 3.23

COP Heating 3.63 3.63 3.63

ANNUAL ENERGY

CONSUMPTION(9)

Cooling kwh 400 540 750

TECHNICAL SPECIFICATIONS

INDOOR UNITS HFU-09HA03/R(DB) HFU-12HA03/R(DB) HFU-18HA03/R(DB)

H mm 640 640 640

W mm 720 720 720

DIMENSIONS Unit

D mm 255 255 255

WEIGHT Unit KG 17 17.5 17.5

COLOR Unit WHITE WHITE WHITE

high dB(A) 42/41 44/43 48/47

medium dB(A) 39/38 41/40 45/43

Sound

pressure(cooling/heating)(5)

low dB(A) 37/35 38/36 42/40

SOUND

LEVEL

Sound

power(cooling/heating)(6)

high dB(A) 52/51 54/53 58/57

high m3 /min 7.5 8.5 11

medium m3 /min 6 7.5 9.5

Air flow

rate(cooling/h

eating) low m3 /min 4.8 6 8.5

steps 4steps,silent and auto 4steps,silent and auto 4steps,silent and auto

high rpm 900 1000 1200

medium rpm 850 975 1125

Speed(cooling

/heating)

low rpm 800 850 1050

Type Cross flow fan Cross flow fan Cross flow fan

FAN

Motor output（upper/lower）20/11 20/11 20/11

AIR FILTER

Removable/washable/

mildew proof

Removable/washable/

mildew proof

Removable/washable/

mildew proof

REMOTE CONTROLLER YR-H05 YR-H05 YR-H05

liquid mm 6.35 6.35 6.35

gas mm

9.52 9.52 12.7

PIPING

CONNECTIONS(external

diameter) drain mm 16 16 16

INSULATION MATERIAL

Heat insulation type

both liquid and gas

pipes

both liquid and gas

pipes

both liquid and gas

pipes

HFU-09,12,18HA03/R2(DB) Specifications

TECHNICAL SPECIFICATIONS

OUTDOOR UNITS HFU-09HA03/R(DB) HFU-12HA03/R(DB) HFU-18HA03/R(DB)

H mm 543 543 680

W mm 783 783 813

NET DIMENSIONS(stop

valve, and bottom

supportis not included)

Unit

D mm 255 255 312

WEIGHT Unit KG 31 33 44

COLOR Unit Ivory white Ivory white Ivory white

Sound

pressure(cooling/heating)(5)

high dB(A) 55/55 55/55 57/58

SOUND

LEVEL Sound

power(cooling/heating)(6)

high dB(A) 65/65 65/65 67/68

high m3 /min 30.2/26.5 30.2/26.5 31.3/27.7

Air flow

rate(cooling/heating) low m3 /min 18.7/15.3 18.7/15.3 20.5/16.8

high rpm 800 800 840

Speed(cooling/heating)

low rpm 500 500 500

Type Propeller fan Propeller fan Propeller fan

FAN

Motor output 20 20 35

Refrigerant type R410A R410A R410A

Refrigerant charge kg 0.65 1.0 1.1

Maximum allowable distance

between indoor and outdoor

m 15 15 20

Maximum allowable level difference m 7 7 10

REFRIGERANT

CIRCUIT

Refrigerant control Capillary Capillary Capillary

Type DC Inverter DC Inverter DC Rotary

Model DA89X1C-20FZ DA108X1C-20FZ3 5CS130XCC03

Motor output W 690 855 1405

Oil type ESTER OIL VG74 ESTER OIL VG74 ESTER OIL VG74

COMPRESSOR

Oil charge volume ml 370 480 480

liquid mm 6.35 6.35 6.35

gas mm

9.52 9.52 12.7

PIPING

CONNECTIONS

drain mm 16 16 16

INSULATION MATERIAL Heat insulation type

both liquid and gas

pipes

both liquid and gas

pipes

both liquid and gas

pipes

Domestic Air Conditioner

HFU-09,12,18HA03/R2(DB) Specifications

ELECTRICAL SPECIFICATIONS

Model HFU-09HA03/R(DB) HFU-12HA03/R(DB) HFU-18HA03/R(DB)

Phase 1PH 1PH 1PH

Frequency Hz 50 50 50

NORMINAL

DISTRIBUTION

SYSTIEM

VOLTAGE Voltage V 230V~ 230V~ 230V~

Cooling A 3.5 5.0 6.8

Norminal running

current Heating A 4.0 5.0 7.3

Cooling A 5.8 7.5 10.2Maximum running

current Heating A 5.3 7.0 10.2

Cooling A 1.1 1.2 1.5

CURRENT

Starting current

Heating A 1.1 1.2 1.5

Domestic Air Conditioner

NOTES

1 Nominal cooling capacities are based on: indoor temperature 27°CDB/19°CWB * outdoor temperature 35°CDB * refrigerant piping length:

5m * level difference: 0m.

2 Nominal heating capacities are based on: indoor temperature 20°CDB * outdoor temperature 7°CDB/6°CWB * refrigerant piping length

5m (horizontal) * level difference 0m.

3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.

4 Units should be selected on nominal capacity. Maximum capacity is limited to peak periods.

6 The sound power level is an absolute value indicating the ’’power’’ which a sound source generates.

7 Energy label: scale from A (most efficient) to G (less efficient).

8 The energy label Directive 2002/31/EC will enter into force once the relevant measurement standard will be published in the European

official Standard.

9 Annual energy consumption: based on average use of 500 running hours per year at full load (= nominal conditions)

The sound pressure level is measured in an anechoic room at 1m distance from the unit. It is a relative value, depending on the distance

and acoustic environment. For measuring conditions: please refer to item 8 of this chapter.

HFU-09,12,18HA03/R2(DB) Specifications

Domestic Air Conditioner

3. Remote controller lists

4. Sensors lists

Mode HFU-09HA03/R(DB) HFU-12HA03/R(DB) HFU-18HA03/R(DB)

YR-H05 Y Y Y

INDOOR UNIT

Description Value Qty

Room sensor It's used for detecting room temperature 1

Pipe sensor It's used for detecting temperature of evaporator 1

OUTDOOR UNIT

Ambient sensor It's used for detecting temperature outdoor side 1

Defrosting sensor It's used for controlling outdoor defrosting at heating mode 1

Descharging sensor It's used for protecting compressor in case of over-heat 1

HFU-09,12,18HA03/R2(DB) Dimensional Drawings

Domestic Air Conditioner

5. Dimensional Drawings

Indoor

Dimensional drawings

Domestic air conditioner

Outdoor unit

HFU-09,12HA03/R2(DB)

HFU-09,12,18HA03/R2(DB)

2-way valve

6.35mm(1/4")

3-way valve

9.52mm(3/8")

HFU-18HA03/R2(DB)

2-way valve

6.35mm(1/4")

3-way valve

12.7mm(1/2")

146

680

813

352

583

312

319.5

837

6.35mm(1/4")

783

543

255

840

HFU-09,12,18HA03/R2(DB) Operation range

Domestic air conditioner

Cooling

Outdoortemp.

40 43

nwodllup03

0 16 23 32

10 20 30

indoor temp WB

gnitaeH42

outdoortemp

Outdoortemp.

-5

-10

-15

10 20 30

indoor temp DB

Notes

The graphs are based on the following condition

Equivalent piping length 7.5m

Level difference 0m

hgihetarwolfriA

outdoortemp
