Hach PTM450 Manual de usuario

DOC022.98.80554

PTM450

03/2016, Edition 1

User Manual

Bedienungsanleitung

Manuale utente

Manuel d'utilisation

Manual del usuario

Manual do utilizador

Návod k použití

Brugsanvisning

Gebruikershandleiding

Instrukcja obsługi

Bruksanvisning

Käyttäjän käsikirja

Ръководство на потребителя

Használati útmutató

Manual de utilizare

Kullanım Kılavuzu

Návod na obsluhu

Navodila za uporabo

Korisnički priručnik

Εγχειρίδιο χρήσης

English..............................................................................................................................3

Deutsch.......................................................................................................................... 11

Italiano............................................................................................................................ 19

Français......................................................................................................................... 27

Español.......................................................................................................................... 35

Português...................................................................................................................... 43

Čeština........................................................................................................................... 51

Dansk..............................................................................................................................59

Nederlands....................................................................................................................67

Polski.............................................................................................................................. 75

Svenska......................................................................................................................... 83

Suomi..............................................................................................................................91

български..................................................................................................................... 99

Magyar......................................................................................................................... 107

Română....................................................................................................................... 115

Türkçe...........................................................................................................................123

Slovenský jazyk......................................................................................................... 131

Slovenski..................................................................................................................... 139

Hrvatski........................................................................................................................ 147

Ελληνικά...................................................................................................................... 155

Table of contents

Specifications on page 3 Maintenance on page 9

General information on page 3 Troubleshooting on page 10

Installation on page 5 Replacement parts and accessories on page 10

Operation on page 8

Specifications

Specifications are subject to change without notice.

Specification Details

Dimensions (W x H x D) 110 x 45 x 60 mm (4.33 x 1.77 x 2.36 in.)

Weight approximately 250 g (0.55 lb)

Operating temperature 15 to 35 °C (59 to 95 °F)

Storage temperature –5 to 40 °C (23 to 104 °F)

Relative humidity 20 to 80%, non-condensing

Power requirements Instrument input: 24 VDC 0.2 mA; External plug-in power supply: Input,

100–240 VAC, 50-60 Hz, 1.5 A, Class I; output, 24 VDC, 2.5 A

Output1Minimum 20 mV; maximum 1250 mV

Impedance 10 kOhms

Wavelengths 3-position switch: 525 nm ±10 nm (green); 610 nm ±10 nm (red); OFF

Response time < 1 second

Connections Local BNC cable, 1.20 m (3.94 ft)

Certifications Safety: IEC/EN 61010-1; EMC: IEC/EN 61326-1

Warranty 1 year (EU: 2 years)

General information

In no event will the manufacturer be liable for direct, indirect, special, incidental or consequential

damages resulting from any defect or omission in this manual. The manufacturer reserves the right to

make changes in this manual and the products it describes at any time, without notice or obligation.

Revised editions are found on the manufacturer’s website.

Safety information

N O T I C E

The manufacturer is not responsible for any damages due to misapplication or misuse of this product including,

without limitation, direct, incidental and consequential damages, and disclaims such damages to the full extent

permitted under applicable law. The user is solely responsible to identify critical application risks and install

appropriate mechanisms to protect processes during a possible equipment malfunction.

Please read this entire manual before unpacking, setting up or operating this equipment. Pay

attention to all danger and caution statements. Failure to do so could result in serious injury to the

operator or damage to the equipment.

Make sure that the protection provided by this equipment is not impaired. Do not use or install this

equipment in any manner other than that specified in this manual.

1The signal output is not sensitive to daylight.

English 3

Use of hazard information

D A N G E R

Indicates a potentially or imminently hazardous situation which, if not avoided, will result in death or serious injury.

WARNING

Indicates a potentially or imminently hazardous situation which, if not avoided, could result in death or serious

injury.

CAUTION

Indicates a potentially hazardous situation that may result in minor or moderate injury.

N O T I C E

Indicates a situation which, if not avoided, may cause damage to the instrument. Information that requires special

emphasis.

Precautionary labels

Read all labels and tags attached to the instrument. Personal injury or damage to the instrument

could occur if not observed. A symbol on the instrument is referenced in the manual with a

precautionary statement.

This is the safety alert symbol. Obey all safety messages that follow this symbol to avoid potential

injury. If on the instrument, refer to the instruction manual for operation or safety information.

This symbol indicates that a risk of electrical shock and/or electrocution exists.

Electrical equipment marked with this symbol may not be disposed of in European domestic or public

disposal systems. Return old or end-of-life equipment to the manufacturer for disposal at no charge to

the user.

Product overview

The PTM450 is a photo-colorimetric titration module used with the OPT300 photo-colorimetric probe.

Use the module and the probe to do photo-colorimetric titrations with the Titralab AT1000 series

titrator.

Connect the module to the Titralab AT1000 series titrator with the legacy adapter and follow the

application working procedure to complete a titration. Refer to the AT1000 series titatror and

OPT3000 probe documentation for additional information.

Refer to Figure 1.

4 English

Figure 1 Product overview

1 LED in connector (from probe) 5 BNC connector (to titration system)

2 LED out connector—525 nm (from probe) 6 External power supply connection

3 Titration module 7 LED out connector—610 nm (from probe)

4 3-position switch: Off, 525 nm, 610 nm

Product components

Make sure that all components have been received. Refer to Figure 2. If any items are missing or

damaged, contact the manufacturer or a sales representative immediately.

Note: The power adapter is not supplied with the instrument. The power adapter is sold separately. Refer to

Replacement parts and accessories on page 10.

Figure 2 Product components

1 Titration module

Installation

CAUTION

Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the

document.

English 5

Installation guidelines

• This instrument is for indoor use only.

• The power supply connector on the rear panel must be easily accessible so the power can be

disconnected quickly in case of emergency.

• Keep the instrument away from temperature extremes, including heaters, direct sunlight and other

heat sources.

Install the instrument

D A N G E R

Electrocution hazard. If this equipment is used outdoors or in potentially wet locations, a Ground Fault

Circuit Interrupt (GFCI/GFI) device must be used for connecting the equipment to its main power

source.

WARNING

Fire hazard. Use only the external power supply that is specified for this instrument.

CAUTION

Electrical shock and fire hazards. Make sure that the supplied cord and non‐locking plug meet the

applicable country code requirements.

Prepare the probe and the titration system. Refer to the probe and titration system documentation.

Refer to the illustrated steps that follow.

6 English

English 7

Operation

D A N G E R

Chemical exposure hazard. Obey laboratory safety procedures and wear all of the personal protective

equipment appropriate to the chemicals that are handled. Refer to the current safety data sheets

(MSDS/SDS) for safety protocols.

Do a titration

Do the steps that follow to complete a titration.

1. Prepare the titration system. Refer to the titration system and the application working procedure

documentation.

2. Make sure that the titration module and the probe are correctly installed and connected.

3. Install the probe on the electrode holder.

4. Connect the titration module to the legacy adapter of the titration system. Follow the instructions

that show on the TitraLab AT1000 to set up the legacy adapter.

5. Select the applicable wavelength on the module 3-position switch: 525 nm or 610 nm based on

your application working procedure.

Usually, select the wavelength that is non-absorbing for the coloured solution at the titration start

then absorbing for the color after the end point. Refer to Table 1 and Table 2.

6. Use the titration system and the instructions on the application working procedure to complete the

titration.

Table 1 Wavelength selection based on indicator

Indicator Non complexed form Complexed form Wavelength

Calmagite Red Blue 610 nm

Eriochrome black T Red Blue 610 nm

Table 2 Wavelength selection based on pH indicator

pH indicator Colour = f (pH) Wavelength

Helianthin red = <3.1

orange = 3.1 to 4.4

yellow = > 4.4

525 nm

Phenolphtalein no colour = <8.3

pink = 8.3 to 10

purple = >10.0

610 nm

Example of a titration curve

In the example, complexometric titration with EDTA at pH = 10 is used to determine the total

hardness of a mineral water. The equivalent point is find with colorimetric detection. The change in

color (wine red to blue) causes a potential jump of 600 to 800 mV and an accurate and reproducible

definition of the equivalent point (standard deviation around 1% on the 3 tests). Refer to Figure 3.

8 English

Figure 3 Titration curve

1 Potential in mV 2 Volume in mL

Maintenance

Clean the instrument

Clean the exterior of the instrument with a moist cloth, and then wipe the instrument dry.

Clean the probe

The OPT3000 probe has a low maintenance level. Clean the probe with deionised water and dry with

a soft tissue. Do not use organic solvents to clean the probe. Do not put the probe in organic solvent.

Replace the probe tip only if the mirror is damaged (e.g, scratches). Refer to the probe

documentation for additional information.

English 9

Troubleshooting

Problem Possible cause Solution

No output signal The probe is defective.

The connections are not

correct.

1. Remove the probe from the solution and make sure that the

probe transmits light (red for the 610 nm position and green for

the 525 nm position).

2. Examine the titration system connections and power

connections. Make sure that the 3-position switch is set to

525 nm or 610 nm. On the titration system, examine the probe

connection. Disconnect and connect the probe again. Do a

direct measurement to examine the output signal.

There is noise in

the output signal

or the output

signal is not

stable

The probe is not

correctly installed on the

electrode holder.

There is dirt on the

probe mirror tip.

1. Make sure that the probe is firmly attached in the sensor

holder. A small vibration can cause not stable output signals.

2. Make sure that the probe tip is correctly installed in the probe

body.

3. Make sure that there are no unwanted materials in the optical

path of the probe.

The output signal

decreases and

becomes low

There is dirt on the

probe tip.

The optical fibre is

damaged.

1. Make sure that there are no unwanted materials in the optical

path of the probe. Clean the probe.

2. Interchange the two LED Out fibre connections (525 nm and

610 nm).

3. Examine the mirror surface and the optical fibre. Clean or

polish the mirror surface and the optical fibre. Clean the probe.

4. Replace the probe tip.

Replacement parts and accessories

Note: Product and Article numbers may vary for some selling regions. Contact the appropriate distributor or refer to

the company website for contact information.

Description Item no.

Photocolorimetric Titration Module PTM450 X61T005

Photocolorimetric probe OPT300 E71T001

Mirror tip for OPT300 probe E91T001

Power supply (without power cable) LZE144

Power cable (EU) YAA080

Power cable (US) XLH055

Power cable (UK) XLH057

10 English

Tabla de contenidos

Idiomas:

Otros manuales de Equipo de laboratorio de Hach

Hach

Hach Lange 2100AN Manual de usuario

Hach

Hach DR 3900 Manual rápido

Hach

Hach AS1000 Manual de usuario

Hach

Hach PHC201 Manual de usuario

Hach

Hach LT 200 Manual de usuario

Hach

Hach MTC10101 Manual de usuario

Hach

Hach TU5200 Manual de usuario

Hach

Hach sensION MM340 Manual de usuario

Hach

Hach AS950 AWRS Manual de instrucciones

Hach

Hach 2100N Manual rápido

Hach

Hach MET ONE 6003 Manual de usuario

Hach

Hach TenSette 19700-01 Manual de usuario

Hach

Hach LQV157.99.50001 Manual de usuario

Hach

Hach ISEF121 Series Manual de usuario

Hach

Hach ORBISPHERE K1200 Manual rápido

Hach

Hach 2100Q Manual rápido

Hach

Hach AS950 AWRS Manual de instrucciones

Hach

Hach QP 1680-TOC/TNb Manual rápido

Hach

Hach 2100AN IS Manual de usuario

Hach

Hach PHC745 Manual de usuario

Hach

Hach QuikChem 8500 2 Series Manual de usuario

Hach

Hach 2100AN IS Manual rápido

Hach

Hach sensION+ MM374 Manual de usuario

Hach

Hach BODTrak II Manual rápido

Manuales populares de Equipo de laboratorio de otras marcas

Qiagen

Qiagen DML 3000 Manual de usuario

Queensgate

Queensgate NANOSCAN OP400 Manual de programación

Conviron

Conviron GEN1000-GE Manual de usuario

Parr Instrument

Parr Instrument 4560 Manual de instrucciones

IKA

IKA IC control Manual de usuario

Integra

Integra DOSE IT Manual de usuario

Agilent Technologies

Agilent Technologies 5800 ICP-OES Manual de usuario

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manual de usuario

NI PXI-5422 Manual

Collomix

Collomix Aqix Manual de usuario

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manual de usuario

Ocean Insight

Ocean Insight FLAME-NIR+ Manual de usuario

Parker

Parker ALIGN-MG-NA Manual de usuario

BD 644787 Manual de usuario

DENTAURUM

DENTAURUM Compact Megaplus Manual de usuario

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manual de usuario

VWR

VWR SAS Super IAQ Manual de usuario

illumina

illumina MiSeqDx Manual de usuario
