GW Instek PPX Series Manual de usuario

Programmable High Precision DC

Power Supply

PPX Series

USER MANUAL

Rev. A

ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by

photocopied, reproduced or translated to another language without

prior written consent of Good Will company.

The information in this manual was correct at the time of printing.

However, Good Will continues to improve products and reserves the

rights to change specification, equipment, and maintenance

procedures at any time without notice.

Good Will Instrument Co., Ltd.

No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

TABLE OF CONTENTS

Table of Contents

SAFETY INSTRUCTIONS .................................................. 5

GETTING STARTED.......................................................... 8

PPX Series Overview ..............................9

Appearance .......................................... 12

Theory of Operation ............................. 20

OPERATION .................................................................. 30

Set Up.................................................. 31

Menu Tree............................................ 40

Basic Operation ................................... 46

Sequence Test ...................................... 74

MENU CONFIGURATION ..............................................107

Configuration Overview ..................... 108

Output ............................................... 108

Measurement..................................... 112

EXT Control ....................................... 115

TRIG Control...................................... 120

PWR On Config .................................. 126

Constant PWR .................................... 127

Temperature....................................... 130

Save/Recall ........................................ 134

Interface ............................................ 137

Utility................................................. 144

APP.................................................... 152

Calibration ......................................... 155

ANALOG CONTROL......................................................156

Analog Remote Control Overview....... 157

Remote Monitoring ............................ 173

PPX Series User Manual

COMMUNICATION INTERFACE ....................................178

Interface Configuration ...................... 179

FAQ..............................................................................208

APPENDIX ....................................................................210

PPX Factory Default Settings .............. 210

PPX Specifications ............................. 213

PPX Dimensions ................................ 218

Declaration of Conformity .................. 219

INDEX ..........................................................................220

SAFETY INSTRUCTIONS

This chapter contains important safety

instructions that you must follow during

operation and storage. Read the following before

any operation to insure your safety and to keep

the instrument in the best possible condition.

Safety Symbols

These safety symbols may appear in this manual or on the

instrument.

WARNING

Warning: Identifies conditions or practices that

could result in injury or loss of life.

CAUTION

Caution: Identifies conditions or practices that

could result in damage to the PPX or to other

properties.

DANGER High Voltage

Attention Refer to the Manual

Protective Conductor Terminal

Earth (ground) Terminal

PPX Series User Manual

Do not dispose electronic equipment as unsorted

municipal waste. Please use a separate collection

facility or contact the supplier from which this

instrument was purchased.

Safety Guidelines

General

Guideline

CAUTION

Do not place any heavy object on the PPX.

Avoid severe impact or rough handling that

leads to damaging the PPX.

Do not discharge static electricity to the PPX.

Use only mating connectors, not bare wires, for

the terminals.

Do not disassemble the PPX unless you are

qualified.

Power Supply

CAUTION

WARNING

AC Input Voltage:

100Vac/120Vac/220Vac/240Vac, 50Hz/60Hz,

single phase

Frequency: 47Hz to 63Hz

Before connecting the power plug to an AC line

outlet, make sure the voltage selector switches

of the bottom panel in the correct position.

Disconnect power cord and test leads before

replacing fuse.

The fuse specification is as following:

To avoid electrical shock connect the protective

grounding conductor of the AC power cord to

an earth ground.

SAFETY INSTRUCTIONS

Cleaning the PPX

Disconnect the power cord before cleaning.

Use a soft cloth dampened in a solution of mild

detergent and water. Do not spray any liquid.

Do not use chemicals containing harsh material

such as benzene, toluene, xylene, and acetone.

Operation

Environment

Location: Indoor, no direct sunlight, dust free,

almost non-conductive pollution (Note below)

Relative Humidity: 20%~ 80% (no condensation)

Altitude: < 2000m

Temperature: 0°C to 40°C

(Pollution Degree) EN61010-1:2010 specifies the pollution degrees

and their requirements as follows. The PPX falls under degree 2.

Pollution refers to “addition of foreign matter, solid, liquid, or

gaseous (ionized gases), that may produce a reduction of dielectric

strength or surface resistivity”.

Pollution degree 1: No pollution or only dry, non-conductive

pollution occurs. The pollution has no influence.

Pollution degree 2: Normally only non-conductive pollution

occurs. Occasionally, however, a temporary conductivity caused

by condensation must be expected.

Pollution degree 3: Conductive pollution occurs, or dry, non-

conductive pollution occurs which becomes conductive due to

condensation which is expected. In such conditions, equipment

is normally protected against exposure to direct sunlight,

precipitation, and full wind pressure, but neither temperature

nor humidity is controlled.

Storage

environment

Location: Indoor

Temperature: -20°C to 70°C

Relative Humidity: 20 to 85%(no condensation)

Disposal

Do not dispose this instrument as unsorted

municipal waste. Please use a separate collection

facility or contact the supplier from which this

instrument was purchased. Please make sure

discarded electrical waste is properly recycled to

reduce environmental impact.

PPX Series User Manual

GETTING STARTED

This chapter describes the power supply in a

nutshell, including its main features and front /

rear panel introduction. After going through the

overview, please read the theory of operation to

become familiar with the operating modes,

protection modes and other safety considerations.

PPX Series Overview ..............................................9

Series lineup ........................................................................................9

Main Features .....................................................................................9

Accessories ........................................................................................10

Appearance .......................................................... 12

Front Panel........................................................................................12

Display Area......................................................................................16

Rear Panel..........................................................................................18

Theory of Operation ............................................. 20

Operating Description ....................................................................20

CC and CV Mode.............................................................................21

Slew Rate ...........................................................................................22

Bleeder Control ................................................................................23

Alarms ................................................................................................24

Considerations ..................................................................................25

Grounding .........................................................................................28

GETTING STARTED

PPX Series Overview

Series lineup

The PPX series consists of 6 models, covering a number of different

current, voltage and power capacities:

Model name

Operation Voltage

Operation Current

Rated Power

PPX-1005

0-10V

0-5A

50W

PPX-2002

0-20V

0-2A

40W

PPX-2005

0-20V

0-5A

100W

PPX-3601

0-36V

0-1A

36W

PPX-3603

0-36V

0-3A

108W

PPX-10H01

0-100V

0-1A

100W

Main Features

Features

2.4" TFT-LCD Panel.

Preset memory function.

Output ON/OFF delay function.

CV, CC priority start function. (prevents

overshoot with output ON)

Adjustable voltage and current slew rates.

Bleeder circuit ON/OFF setting. (to prevent

over-discharging of batteries)

OVP, OCP, AC Alarm and OTP protection.

Supports test sequence.

Web server monitoring and control. (The

function is activated when connecting to LAN

Interface)

Analog monitor output.

PPX Series User Manual

Remote sensing to compensate for voltage drop

in load leads.

Support K type thermocouple temperature

measurement.

With 4 measuring currents and Manual / Auto

shift function.

Interface

Built-in USB, RS-232/485 and LAN interface.

External analog control function.

Optional GPIB interface.

Accessories

Before using the PPX power supply unit, check the package

contents to make sure all the standard accessories are included.

Standard

Accessories

Part number

Description

Qty.

GTL-104A

Test leads for PPX-1005/PPX-

2005/PPX-3603 (Binding Posts

Terminal), 1m, 10A

GTL-105A

Test leads for PPX-2002/PPX-3601,

1m, 3A

Short Bar (Binding Posts Terminal)

GTL-204A

Test leads for PPX-1005/PPX-

2005/PPX-3603 (European Type Jack

Terminal), 1m, 10A

GTL-203A

Test leads for PPX-2002/PPX-

3601/PPX-10H01 (European Type Jack

Terminal), 1m, 3A

GTL-201A

Ground lead for European Type Jack

Terminal

Power Cord

Otros manuales para PPX Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Fuente de alimentación de GW Instek

GW Instek

GW Instek GRA-441 Manual de usuario

GW Instek

GW Instek PSP-603 Manual de usuario

GW Instek

GW Instek GPP-3610H Manual de usuario

GW Instek

GW Instek PEL-300 Manual de usuario

GW Instek

GW Instek PSB-2000 series Manual de usuario

GW Instek

GW Instek PFR-100L Manual del propietario

GW Instek

GW Instek APS-9301 Manual de usuario

GW Instek

GW Instek SPS-1230 Manual de usuario

GW Instek

GW Instek PFR-100MGP Manual de usuario

GW Instek

GW Instek SPD-3606 Manual de usuario

GW Instek

GW Instek PSM-2010 Manual de usuario

GW Instek

GW Instek GPP-3323 Manual de usuario

GW Instek

GW Instek SPS-1230 Manual de usuario

GW Instek

GW Instek PSU Series Manual de usuario

GW Instek

GW Instek GPD-303S Series Manual de usuario

GW Instek

GW Instek ASD Series Manual de usuario

GW Instek

GW Instek PPX Series Manual del propietario

GW Instek

GW Instek PEL-3000AH Series Manual de usuario

GW Instek

GW Instek PPH-1503 Manual de usuario

GW Instek

GW Instek PEL-3000A Series Manual de usuario

GW Instek

GW Instek PSU Series Manual del propietario

GW Instek

GW Instek PSB-2000 series Manual de usuario

GW Instek

GW Instek PPH-1503D Manual de usuario

GW Instek

GW Instek PEL-3000 Series Manual de usuario

Manuales populares de Fuente de alimentación de otras marcas

Monacor

Monacor PS-12CCD Manual de usuario

VOLTIMA

VOLTIMA MagicBox 15 Manual de usuario

Agilent Technologies

Agilent Technologies 6032A Manual de usuario

Miller

Miller Auto Deltaweld 452 Manual de usuario

BCP

BCP PUOUBK Hoja de instrucciones

HC 2210 Manual de usuario

Puls

Puls CT5.241 Manual de usuario

OCZ

OCZ ZX1250W Manual de usuario

iseg

iseg ECH 238 Manual de usuario

Power

Power XXL A Series Manual de usuario

Agilent Technologies

Agilent Technologies 6631B Manual de usuario

Renogy

Renogy PHOENIX 300 Manual de usuario

HP 6200B Manual de servicio

Epson

Epson Stylus Scan 2500 Manual de funcionamiento

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manual de usuario

Puls

Puls MiniLine ML50.100 Manual de usuario

Puls

Puls AS-Interface SLA4.100 Manual de usuario

Kenwood

Kenwood PS-60 Manual de usuario
