Guild PSJ700G Manual de usuario
GUILD
710W Jigsaw
Instruction Manual
Important - Please read these instructions fully before operating or maintaining your Guild jigsaw
These instructions contain important information that will help you get the best from your Guild
jigsaw, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989
After Sales Support
PSJ700G
UK/Ireland 0333 3201989
Help@guildpowertools.co.uk
Customer Helpline 0333 3201989
2
Contents
Safety Information ����������������������������������������������������������������������������������������������������3
In The Box�����������������������������������������������������������������������������������������������������������������7
Accessories ��������������������������������������������������������������������������������������������������������������7
Operating Instructions����������������������������������������������������������������������������������������������8
Working Hints For Your Jigsaw�������������������������������������������������������������������������������13
Maintenance �����������������������������������������������������������������������������������������������������������15
Technical Data ��������������������������������������������������������������������������������������������������������15
Environmental Protection���������������������������������������������������������������������������������������16
Guarantee���������������������������������������������������������������������������������������������������������������17
Declaration of Conformity����������������������������������������������������������������������������������������17
Plug Replacement (Uk & Ireland Only) ������������������������������������������������������������������� 18
Customer Helpline 0333 3201989
3
Safety Information
Important - Please read these instructions fully before starting assembly
Warning Symbols
The following warning symbols appear throughout this assembly manual and
indicate the appropriate safety measures you should take when assembling and
operating the jigsaw.
To reduce the risk of injury, Please read the instruction manual
Wear eye protection
Wear ear protection
Wear dust mask
Warning
Double insulation
Waste electrical products must not be disposed of with household waste. Please recycle
where facilities exist. Check with your local authorities or retailer for recycling advice.
Customer Helpline 0333 3201989
4
Safety Information
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings
WARNING! Read all safety warnings and all instructions� Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference�
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit� Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust� Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while operating a power tool� Distractions can
cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet� Never modify the plug in any way� Do not
use any adapter plugs with earthed (grounded) power tools� Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators� There is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet conditions� Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord� Never use the cord for carrying, pulling or unplugging the
power tool� Keep cord away from heat, oil, sharp edges or moving parts� Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use�
Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply� Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power
tool� Do not use a power tool while you are tired or under the influence of drugs,
alcohol or medication� A moment of inattention while operating power tools may result
in serious personal injury.
b) Use personal protective equipment� Always wear eye protection� Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting� Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool�
Carrying power tools with your finger on the switch or energising power tools that have
the switch on invites accidents.
Original Instructions
Customer Helpline 0333 3201989
5
Safety Information
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings
d) Remove any adjusting key or wrench before turning the power tool on� A wrench or a
key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach� Keep proper footing and balance at all times� This enables better
control of the power tool in unexpected situations.
f) Dress properly� Do not wear loose clothing or jewellery� Keep your hair, clothing and
gloves away from moving parts� Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used� Use of dust collection can reduce dust-
related hazards.
4) Power tool use and care
a) Do not force the power tool� Use the correct power tool for your application� The
correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off� Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools�
Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool� Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools� Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation� If damaged,
have the power tool repaired before use� Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean� Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc� in accordance with these
instructions, taking into account the working conditions and the work to be performed�
Use of the power tool for operations different from those intended could result in a
hazardous situation.
5) Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts� This will ensure that the safety of the power tool is maintained.
Customer Helpline 0333 3201989
6
Safety Information
Important - Please read these instructions fully before starting assembly
Jigsaw Safety Warnings
1� Hold jigsaw by insulated gripping surfaces, when performing an operation where
the cutting accessory may contact hidden wiring or its own cord� Cutting accessory
contacting a “live” wire may make exposed metal parts of the power tool “live” and could
give the operator an electric shock.
1� Always wear a dust mask�
Additional Safety Rules for Jigsaw
Customer Helpline0333 3201989
7
In The Box
Parts
Pendulum Action Control
Roller Guide
Saw blade
Finger protection
Blade Holder
Work Light
Parallel guide
Variable Speed Control
On/Off Switch
Lock-On Button
Hand Grip Areas
Allen Key
Vacuum adaptor
Base Plate
Angle Plate
1
2
3 11
4
5
6
7
8
9
10
12
13
14
15
12
11
13
14
7
8
9
10
1234
5
6
15
Accessories
Parallel guide 1pc
Allen key 1pc
Vacuum adaptor 1pc
Wood cutting blade 1pc
Customer Helpline 0333 3201989
8
NOTE: Before using the tool, read the instruction book carefully.
Intended Use
The machine is intended for sawing wood, plastic, metal and building materials while
resting firmly on the workpiece. It is suitable for straight and curved cuts with bevel angles
to 45°. The saw blade recommendations are to be observed.
1�ON/OFF SWITCH
Depress to start and release to stop your tool. (SEE FIG A)
2� SWITCH LOCK-ON BUTTON
Depress on/off switch (2) then lock-on button (3) (SEE FIG B), release on/off switch first
then lock-on button second. Your switch is now locked on for continuous use. To switch off
your tool just depress and release on/off switch.
Operating Instructions
2 3
A B
C
Customer Helpline0333 3201989
9
3� VARIABLE SPEED CONTROL
Adjust the thumb-wheel to increase or decrease the speed (SEE FIG C) according to the
material, material thickness and blade specification to be used (also possible during no
load operation). See Chart 1 for general guidance on speed selection.
Avoid prolonged use at very low speed as this may damage your jigsaw’s motor.
Chart 1
Material Speed setting
Wood 5-6
Metal 3-4
Aluminum 3-5
PVC 3-4
Ceramic 3-5
Operating Instructions
Customer Helpline 0333 3201989
10
Operating Instructions
4� ALLEN KEY STORAGE
The allen key (5) is placed at the power cable sheath (SEE FIG D).
5� BLADE FITTING (SEE FIG E)
NOTE: Remove the plug from the socket before carrying out any adjustment, servicing or
maintenance.
To fit blade firstly use the allen key provided to loosen the blade set screws on the blade
holder. The blade’s cutting edge should be facing forward. Insert the blade’s mounting
portion into the groove in the blade holder until it touches the bottom of the holder. Then
firmly tighten the set screw as shown in FIG E.
NOTE: To fit the blade firmly, do not insert the blade over the line.(SEE FIG G)
WARNING: blade teeth are very sharp� For best cutting results ensure you use a
blade suited to the material and cut quality you need.
6� ROLLER GUIDE(SEE FIG F)
Ensure the blade is located and runs smoothly in the groove (SEE FIG F) otherwise the
pendulum function will not work correctly and the blade will not be supported during
cutting.
5
D E
F G
