Quick Start User Guide

Contents

Guardian

SAFETY PENDANTS

Your Device.....................................................

LED Indicators..................................................

Procedures.......................................................

On/Off....................................................

Charging the Device...................................

Testing the SOS button................................

Testing the Fall Detection............................

FAQ.....................................................................

Download the full User Guide by

scanning this image with a QR

Code Reader or call the ofﬁce on

(08) 6336 9448

1. Loudspeaker

2. On/Off Button

3. SOS Button

4. SIM Tray (do not touch)

5. Cell Signal LED

6. GPS Signal LED

7. WiFi Signal LED

8. Power LED

5. 6. 7. 8.

Your Device

1 4

2 3

LED Indicators

3. WiFi

4. Power

2. GPS Signal

1. Cell Signal

Off

Flashing

Off

Solid Red (while off charger)

Solid Orange (while on charger)

Flashing Orange (while on charger)

Solid Light

Quick Flash (1ﬂash every second)

Slow Flash (1ﬂash every 3 seconds)

In sleep mode to save battery

Searching for GPS signal

GPS signal aquired successfully

In sleep mode to save battery

Using WiFi to help aquire GPS location

Battery is between 30-100%

Battery is below 30%

Battery is being charged

Battery is fully charged

Searching for cell signal OR on call

Operating on the 4G Network

Operating on the 3G Network

FEATURE DESCRIPTION

Procedures

Press and hold the right side button (image 1)

for 2-3 secs until it vibrates to either turn the

device on or turn it off. When turning on, the

Power LED will ﬂash a few times, letting you

know it’s turning on.

If the Rova is on and you give the SOS button

(image 2) a brief press without holding it down

you will see some of the LED lights ﬂash.

Recharge your Rova by connecting the wall

plug, (image 3) which is connected via the

back of the charging cradle (image 4), into a

power point. Turn the power point on.

Place the Rova into the charging cradle (see

image 3) so the charging points on the back

of the Rova match the charging points in the

cradle.

Note: Please disregard the micro-USB port on

the side of the Charging Cradle as this is to be

used only by Guardian SP staff in our ofﬁce.

Turning the device On/Off

Charging the device

Procedures

Testing the SOS Button

1. Inform the emergency contacts that the Rova is being tested.

2. Press the SOS button for 2-3 seconds until it vibrates.

3. A call will be made to Contact Number 1 within a few seconds

(and the text messages with GPS location will shortly thereafter

be sent to all emergency contacts).

4. The emergency contact must answer within 10 seconds.

5. This will stop the Rova from *hanging up and calling the next

contact.

6. After the emergency contact answers the phone, conﬁrm

both parties can hear each other.

7. While either party can hang up, it is suggested that the Pendant

User hang up to reinforce their memory of how to hang up.

*Note: If an emergency contact’s phone is off or goes straight to

voicemail this will prevent the Rova from calling the next emergency

contact because it assumes the voicemail answering the call is a

successful connection with a person.

It is recommended to test the Rova every

1-3 months. 5

Procedures

1. Inform the emergency contacts that the Rova is being tested.

2. Hold the Rova vertically to the ground and drop it over a carpeted or soft area.

3. If the Cell Signal LED begins to ﬂash rapidly you know the Fall Detection has

been triggered. Wait about 20 seconds to conﬁrm this as the Rova will beep

loudly to conﬁrm the activation.

4. Cancel the Fall Detection alarm when it starts beeping by brieﬂy pressing the

SOS button (do not hold it down).

5. Go back to Step 2 and repeat the steps again but instead of cancelling the Fall

Detection at Step 4, skip to step 6 by letting the alarm ﬁnish sounding.

6. A call will be made to Contact Number 1 (and the text messages with GPS

location will shortly thereafter be sent to all emergency contacts).

7. The emergency contact must answer within 10 seconds. This will stop the Rova

from *hanging up and calling the next contact.

8. After the emergency contact answers the phone, conﬁrm both parties can hear

each other.

9. While either party can hang up, it is suggested that the Pendant User hang up to

reinforce their memory of how to hang up.

Testing the Fall Detection

*Note: If an emergency contact’s phone is off or goes straight to voicemail this will

prevent the Rova from calling the next emergency contact because it assumes the

voicemail answering the call is a successful connection with a person.

FAQ

Question Answer

Is the device ready to go?

What do the emergency contacts

need to do in an emergency?

How do I cancel the Fall Alert after it

starts making the alarm sound?

Why didn’t Fall Detection sound

after a fall?

What do the lights mean?

How do I reprogram the device if

people's phone numbers change?

Why didn't the GPS work?

Why is the device not charging?

See page 3.

Just call us! We can do this for you.

Yes! Just turn it on and you're good to go.

When they get a call from the Rova, they need to:

• Answer the call within 10 seconds

• Conﬁrm they can hear each other.

Press the SOS button once brieﬂy to cancel

the Fall Alert when you hear the alarm sound.

Additionally, if the User thinks the Rova may have

detected a fall, they may press the SOS button

brieﬂy to cancel the alarm before it sounds.

Due to the varied nature of falls, some falls

may not register. We can adjust the sensitivity if

necessary. However, in the event of a fall, do not

wait for the Fall Alert alarm sound but press and

hold the SOS button if you are conscious.

GPS works best when there is a clear view of the

sky. When initially receiving your Rova, turn it on

and take it outside for a couple minutes or until

the GPS LED (see page 3) ﬂashes once every 3

seconds.

Conﬁrm the Rova is connected to the Charging

Cradle, as explained on page 5. If any of the 4

connectors on the Rova become dirty or

discoloured, clean them with alcohol wipes or

multipurpose cleaner and a toothbrush.

Guardian

SAFETY PENDANTS

Thank you for choosing

Guardian Safety Pendants!

New Technology, Old Fashioned Service

Where you're treated like family

GUARDIAN SAFETY PENDANTS PTY LTD.

6/26 DUGDALE STREET, WARWICK, WA, 6024

Phone: (08) 6336 9448 Email: [email protected]

Website: guardiansp.com.au
