GSS HDE 164 Manual de usuario
Assembly Instruction
HDE 164
- 2 - HDE 164
Contents
1 Safety regulations .......................................................................................3
2 General information ....................................................................................4
2.1 Scope of delivery ..........................................................................4
2.2 Meaning of the symbols used ..........................................................4
2.3 Technical data ...............................................................................4
2.4 Description ...................................................................................6
3 Installation ..................................................................................................7
3.1 Installing the Encoder module ..........................................................8
3.2 Connecting the Encoder module ......................................................9
3.3 EMC regulations ............................................................................9
4 The control panel at a glance .....................................................................10
4.1 Functions of the control panel buttons .............................................10
4.2 Menu items .................................................................................10
5 Programming ............................................................................................11
5.1 Programming procedure ...............................................................11
5.2 Programming the module ..............................................................13
Selecting the module / channel strip ..............................................13
Input parameter ...........................................................................14
Data rate of the video signal ....................................................14
TV standard ...........................................................................15
Aspect ratio ...........................................................................15
Sharpness ..............................................................................15
Audio signal type and bit rate ..................................................16
Level of the audio signal ..........................................................16
Programme number (SID - Service ID) ........................................17
Channel name .......................................................................17
ASI Input station filter ...................................................................18
Output parameter ........................................................................20
ASI transfer rate .....................................................................20
ASI options ............................................................................21
Transport stream ID and ORGNET ID .............................................22
Factory reset ...............................................................................22
Saving settings ...........................................................................23
6 Final procedures ........................................................................................23
- 3 - HDE 164
1 safety regulations
• The standards EN/DIN EN 50083 resp. IEC/EN/DIN EN 60728 must be
observed.
• Do not perform installation and service work during thunderstorms.
• Assembly, installation and servicing should be carried out by authorised
electricians.
• Switch off the operating voltage of the system before beginning with assem-
bly or service work.
• Avoid short circuits!
• Observe the relevant standards, regulations and guidelines on the installa-
tion and operation of antenna systems.
• To ensure electromagnetic compatibility, make sure all connections are tight
and the covers are screwed on securely.
• No liability is accepted for damage caused by faulty connections or inap-
propriate handling of the device.
Check the head-end station according to the safety instructions listed in their
assembly instruction.
Take precautions to prevent static discharge when working on the device!
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
European Council from January 27, 2003 which addresses old electronic and
electrical devices, such devices must be disposed of at a designated collection
facility. At the end of its service life, please take your device to one of these
public collection facilities for proper disposal.
- 4 - HDE 164
2 general information
2.1 sCope of delivery
1 Module HDE 164
1 BNC cable
1 Brief assembly instructions
2.2 meaning of the symbols used
Important note
—> General note
–
/
–
/
Optional use of the buttons
• Performing works
2.3 teChniCal data
The devices meet the following EU directives:
2011/65/EU, 2014/30/EU, 2014/35/EU
The product fulfils the guidelines and standards for CE labelling (page 24).
Unless otherwise noted all values are specified as "typical".
CVBS Video Inputs:
Standard: .....................................................................DIN EN 50049-1
Input level: .....................................................................................1 Vpp
Input impedance: ............................................................................75 Ω
Frequency range: .......................................................... 20 Hz … 5 MHz
Audio Inputs:
Standard: .....................................................................DIN EN 50049-1
Input level: ..............................................................................500 mVrms
Input impedance: .......................................................................... 10 kΩ
Frequency range: ..........................................................20 Hz … 15 kHz
MPEG2 Encoder:
Transport stream: ............................................MPEG2 (ISO/IEC 13818-1)
Video data stream: .........................................MPEG2 (ISO/IEC 13818-2)
Audio data stream: .........................................MPEG1 (ISO/IEC 11172-3)
Output data rate: ..................................................... 2 Mbit/s…15 Mbit/s
Audio data rate: ...................................................... 192 kb/s…384 kb/s
- 5 - HDE 164
ASI Interfaces
Standard: .....................................................................DIN EN 50083-9
Format: ..............................................................MPEG ISO IEC 13818-1
Max. data rate ......................................................................108 Mbit/s
User data rate: .................................................................2 … 90 Mbit/s
Impedance: ....................................................................................75 Ω
Level (input / output): .....................................................800 mVpp ± 10%
Rise/Fall Time: ............................................................ < 1.2 ns (20-80%)
Reflexion loss (input): ..........................................> 17 dB (5 … 270 MHz)
Connections:
Audio inputs: ............................................................4 x 2 Cinch sockets
CVBS Video inputs: ........................................................ 4 Cinch sockets,
ASI input: .................................................................1 BNC socket, 75 Ω
ASI output: ................................................................1 BNC socket, 75 Ω
Connection strip (20-pin): ....................
for supply voltages and control circuit
Remote maintenance
Remotely controllable (via PSW 160*): ................................................yes
(* and a corresponding management unit)
- 6 - HDE 164
2.4 desCription
In the module HDE 164 four analogue audio and video signals are converted
into MPEG2 data streams (transport streams).
The transport streams are emitted via the ASI output.
L
R
FBAS
CVBS
ASI-Ausgang
ASI output
BNC
ASI-Eingang
ASI input
BNC
Audio-Eingang
Audio input
Cinch
Video-Eingang
Video input
Cinch
ENCODER
AV 1
µP / TPS-MODUL
L
R
FBAS
CVBS
Audio-Eingang
Audio input
Cinch
Video-Eingang
Video input
Cinch
AV 2
L
R
FBAS
CVBS
Audio-Eingang
Audio input
Cinch
Video-Eingang
Video input
Cinch
AV 3
L
R
FBAS
CVBS
Audio-Eingang
Audio input
Cinch
Video-Eingang
Video input
Cinch
AV 4
The module is equipped with four video/stereo audio inputs and one ASI data
stream input. The fed in analogues signals are digitized and supplied to an
encoder that encodes them in real time.
The stereo audio signals are transferred via an adjustable amplifier to the
encoder. The bit rates are adjustable. A transport stream fed via the ASI input
socket will be inserted into the transport streams of the encoded analogous
signals. In this way it is possible to connect several HDE 164 in series.
IN
OUT
- 7 - HDE 164
At the ASI output sockets (BNC) a transport stream is provided according to
ISO/IEC 13818-1.
When the head-end station is switched on, the two-line LC display shows the
"SETUP" menu and the software version of the control unit.
The control of the module takes place via the control unit of the
head-end sta-
tion. To operate the
encoder module
the software version of the control unit
(head-end station) must be "V 10" or higher. The operating software of the
encoder module and the
head-end station can be updated using a PC and
the software "BE-Flash" via the 9-pin D-SUB socket on the head-end station.
You can find the current operating software for the head-end station
and the
encoder module,
the software "BE-Flash"
and the current assembly instructions
on the website "www.mygss.eu".
The
encoder module
is designed exclusively for use in the STC 160 head-end
station.
3 installation
– Ensure the head-end station is mounted so it will not be able to vibrate.
Avoid, for example, mounting the head-end station onto a lift shaft or any
other wall or floor construction that vibrates in a similar way.
– Before installing or changing a module, switch off the head-end station or
unplug the power cable from the mains power socket.
– Take measures to protect against ESD!
•
Open the housing of the head-end station in accordance with the assembly
instructions for the STC 160.
- 8 - HDE 164
3.1 installing the enCoder module
– When installing a module, make sure that it is inserted in one of the long,
numbered grooves in front of the contact strip on the board at the rear wall
of the housing.
– The shorter, non-numbered grooves without a contact strip on the board at
the rear wall of the housing are for add-on modules only.
•
Open the housing of the head-end station in accordance with the assembly
instructions for the STC 160.
• Open the locking device A in the direction of the green arrow.
A
• Insert the Encoder module in grooves B of an open slot (with contact strip
on the board at the rear wall of the housing) and gently slide it into the
head-end station until it makes contact with the board on the rear wall.
• After installing the Encoder module close the locking device A in the direc-
tion of the red arrow.
—> Ensure that the ground spring C gets contact to the locking device.
C
B
B
A
- 9 - HDE 164
3.2 ConneCting the enCoder module
E
D
F
H
G
•
Connect the audio inputs D (right channel) / E (left channel) and video
inputs F to corresponding signal sources.
• If required connect the ASI input G and ASI output H to corresponding
ASI devices (e.g. the ASI output to the ASI input of the next HDE 164 if you
would like to cascade several HDE 164 ; page 6).
3.3 emC regulations
To comply with the current EMC regulations, it is necessary to connect the lines
leading in and out of the head-end station using cable terminals.
When mounting the module in a head-end station which is installed in a 19"
cabinet, make sure the connections leading in and out for the 19" cabinet are
made using cable terminals.
Tighten the nuts on the cable terminals until the teeth on the lock washer have pen-
etrated the exterior coating and a good connection is made between the housing
and cable terminals.
- 10 - HDE 164
4 the Control panel at a glanCe
4.1 funCtions of the Control panel buttons
S
M To move the cursor
To adjust values and
functions
To save the programmed
data
To switch to the next
menu
4.2 menu items
Program the
Enc
oder module using the buttons on the head-end station control
panel. The menus appear on the two-line display of the control panel.
The parameters and functions to be set are underlined.
With the button select the channel strip / other modules.
You can use the button to select the following menu items:
– ASI output settings
ASI data rate
ASI options
– Input settings
Bit rate
Standard
Aspect ratio
Sharpness
Audio data rate
Volume
Station number
Station name
– Station Filter (ASI input)
– Transport stream and ORGNET-ID
– Factory reset
– Save data
Tabla de contenidos
Otros manuales de Unidad de control de GSS
Manuales populares de Unidad de control de otras marcas
Festo
Festo Compact Performance CP-FB6-E Manual de lista de piezas
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Manual de usuario
JS Automation
JS Automation MPC3034A Manual de usuario
JAUDT
JAUDT SW GII 6406 Series Guía rápida
Spektrum
Spektrum Air Module System Manual de usuario
BOC Edwards
BOC Edwards Q Series Manual de usuario
