Grundig VCC 4350 A Manual de usuario

VACUUM CLEANER

VCC 4350 A

ENGLISH

________________________________________________________

ENGLISH

Please read this manual complete-

ly before using your appliance!

Follow all the safety instructions

to avoid damage caused by im-

proper use!

Please retain this user manual for

further reference. This manual

shall also be supplied with the

appliance when the appliance is

handed over to a third person.

▪

This appliance is intended for

household use only. Warranty

shall be void when the appli-

ance is used for industrial or

commercial purposes.

▪

Please observe these instruc-

tions to prevent damage and

risks due to improper use.

▪

Do not clean wet surfaces and

vacuum wet objects with this ap-

pliances.

▪

Do not use this appliance in wet

areas.

▪

Do not use this appliance with

wet hands.

▪

This appliance is intended for

cleaning dirt and dust particles.

Do not attempt to vacuum large

objects that can damage the ap-

pliance by blocking it.

▪

Do not use the appliance to

vacuum cigarette butts, ﬁreplace

ashes or matchsticks. These ob-

jects may cause ﬁre.

▪

This appliance is not intended

for cleaning persons or animals.

▪

Do not insert anything through

the suction clearance of the ap-

pliance. Always keep the suction

clearance open.

▪

Do not hold the appliance up-

right while vacuuming.

▪

Do not roll the appliance over its

power cord.

▪

Do not close a door over the

power cord.

▪

Do not pull the power cord

round sharp edges and do not

squash it.

▪

If you move the appliance to an-

other room, always disconnect

the power cord and carry the

appliance by the handle.

▪

Never carry the appliance by

pulling its power cord.

▪

Never operate the appliance

without the dust container or ﬁl-

ter.

▪

Replace the dust bag when the

indicator illuminates in red.

SAFETY _____________________________________________

ENGLISH

▪

Always pull out the power cord

before cleaning or carrying out

any maintenance on the appli-

ance.

▪

Whenever possible, insert the

power cord plug directly into

the socket. Avoid using exten-

sion cables or multipoint con-

nectors.

▪

Pull out the power plug after

use. Do not disconnect the plug

by pulling on the cable.

▪

Never use the appliance if there

is visible damage on the appli-

ance or on the power cord. This

also applies if the appliance

has accidentally become wet.

Please contact a service centre

in this case.

▪

Our GRUNDIG Household Ap-

pliances meet all the applicable

safety standards; thus if the ap-

pliance or the power cord is

damaged, it must be replaced

by the dealer, a service centre

or a similarly qualiﬁed and au-

thorised service person to avoid

any danger arising. Faulty or un-

qualiﬁed repair work may cause

danger and risk to the user.

▪

Always keep the appliance

away from children.

▪

This appliance can be used

by children aged from 8 years

and above and persons with

reduced physical, sensory or

mental capabilities or lack of ex-

perience and knowledge if they

have been given supervision or

instruction concerning use of the

appliance in a safe way and un-

derstand the hazards involved.

Children shall not play with the

appliance. Cleaning and user

maintenance shall not be made

by children without supervision.

▪

Do not open the appliance un-

der any circumstances. No war-

ranty claims are accepted for

damage resulting from improper

handling.

SAFETY _____________________________________________

ENGLISH

Dear Customers,

Congratulations on your purchase of your new

vacuum cleaner VCC 4350 A.

Read the following user notes carefully to

ensure full enjoyment of your quality GRUNDIG

product for many years to come.

Responsible approach!

GRUNDIG focusses on contractu-

ally agreed social working condi-

tions with fair wages for both

inter nal employees and suppliers.

We also attach great importance

to the efficient use of raw materi-

als with continuous waste reduction of sev eral

tonnes of plastic every year. Furthermore, all

our accessories are available for at least 5

years.

For a future worth living.

For a good reason. Grundig.

Controls and parts

See the ﬁgure on page 3.

A Suction control

B Lower body

C Metal telescopic tube

D Flexible hose adapter

E Height setting switch

F Wheel

G On/Oﬀ button

H Multi-ﬂoor brush switch

I Multi-ﬂoor brush

J Brush parking position

K Power cord rewind button

L Rear cover

M Carrying handle

N Dust container cover

O Dust bag full indicator

P Dust container button

Q Flexible hose

Accessories

Crevice tool

OVERVIEW ________________________________________

ENGLISH

Preparation

Your appliance is provided with a dust bag. The

appliance is ready for use when all parts are

installed together.

1 Insert the ﬂexible hose Q with the ﬂexible

contact into the inlet on the main body of the

appliance until it latches in.

Note

■ To remove the ﬂexible hose Q press the side

release buttons buttons on the ﬂexible hose

adapter D and then pull out the hose.

2 Insert the end of the ﬂexible hose to the metal

telescopic tube C.

Note

■ To adjust the length of the metal telescopic

tube C, push and hold the height setting

switch E and slide the tube out or in as

required. Release the height setting switch E

and make sure that the tube clicks into place.

3 Insert the multi-ﬂoor brush or crevice tool into

the lower end of the metal telescopic tube C.

Note

■ Install all snap-on elements by pushing and

rotating to each other and remove them by

pulling and rotating.

Usage of multi-ﬂoor brush in two

diﬀerent positions

Brush part shall be out while cleaning hard

surfaces and parquet ﬂoors.

Brush part shall be inside while cleaning carpets

and rugs.

Crevice tool

This accessory is suitable for removing dust

from bookcases, curtains, window frames and

upholstered furniture.

OPERATION _______________________________________

ENGLISH

Switching on and oﬀ

1 Pull the power cord out to a suitable length.

Caution

■ The maximum cable length is indicated by

a red mark. Never try to pull out the power

cord beyond the red mark.

2 Plug the power cord plug into the wall socket.

3 Switch on the appliance by pressing

On/Oﬀ

button G.

4 Press On/Oﬀ button G to turn oﬀ the

appliance after using it and remove the

power cord from the outlet.

Caution

■ Never unplug the appliance when it is in use.

Suction control

The suction control A is located on the handle

and can be operated with your thumb. When

the control A is fully closed, the maximum suc-

tion power is reached.

However, in some cases it is advisable to have

less suction power, such as when cleaning

sensitive materials, upholstery or shag pile

carpets. Open the suction control if and when

required.

Rewinding the power cord

1 Unplug the appliance.

2 Hold the power cord with one hand and press

and hold the cord rewinding

button K.

3 Rewind the power cord carefully.

Caution

■ As rewinding in high speed may cause

unexpected cord movements, be careful when

you are rewinding the power cord by pressing

on the cord rewinding button K.

OPERATION _______________________________________

ENGLISH

Dust bag full indicator

Dust bag full indicator O will provide a warning

when the suction power is reduced when the

thin pores of the dust bag are blocked by thin

dust. It shall also indicate if a big object blocks

the hose or suction clearance.

Replacing dust bag

1 Unplug the appliance.

2 Open the dust container cover N

by pressing

on the dust container button P and lifting the

cover.

3 Pull out the ﬁlter holder.

4 Dispose of the dust bag.

Caution

■ Do not attempt to empty and re-use the dust

bag.

5 Insert a new dust bag in the holder.

6 Close the dust container cover N

Note

■ You should use dust bags from Swirl®, Type Y

05® or Menalux®, Type 1840 for VCC 4350 A.

Caution

■ Do not use the appliance without the dust

bag. Dust container cover cannot be closed

without installing the dust bag.

Note

■ Even if the dust bag does not appear full,

vacuuming very ﬁne dust such as ﬂour or

plaster may block the pores instantly and

reduce the suction power. You shall replace

the dust bag even if it appears to be empty in

this case. Always replace the dust bag every

6 months even if it is not ﬁlled in order to

prevent foul odors.

Caution

■ Your appliance is equipped with a system that

prevents closing of the front cover when the

dust bag is not inserted. Please check whether

the dust bag is inserted if the front cover

cannot be closed.

INFORMATION ___________________________________

ENGLISH

Replacement or cleaning of the

ﬁlter

Caution

■ Install the dust bag and ﬁlter before operating

the appliance; otherwise motor may be

damaged.

Cleaning the ﬁlter of the dust

container (motor protection

ﬁlter)

1 Open the dust container cover N by pressing

on the dust container button P.

2 Pull out the dust bag from the bracket.

3 Pull out the ﬁlter.

4 Shake out the ﬁlter and wash it with hot soapy

water, rinse carefully and leave to air dry.

Caution

■ Do not wash the ﬁlter in washing machine or

dry with a hair dryer.

■ Make sure that the ﬁlter is completely dried

before installing it in the appliance.

5 Place a new ﬁlter in the bracket if required.

6 Replace or change the dust bag.

Clean the exhaust air fan ﬁlter

1 Remove the ﬁlter bracket by pressing on the

release button (on the rear of the appliance).

2 Remove the ﬁlter from ﬁlter bracket.

3 Shake out the ﬁlter and wash with hot soapy

water, rinse carefully and leave to air dry.

Caution

■ Do not wash the ﬁlter in washing machine or

dry with an hair dryer.

■ Make sure that the ﬁlter is completely dried

before installing it in the appliance.

4 Replace all parts carefully to their positions.

Note

■ Dust container ﬁlter shall be replaced every

six months or when required.

■ Exhaust air ﬁlter shall be replaced every six or

nine months or when required.

■ Washing the ﬁlter frequently may cause wear

of the ﬁlter.

INFORMATION ___________________________________

Otros manuales para VCC 4350 A

Tabla de contenidos

Otros manuales de Aspiradora de Grundig

Grundig

Grundig VCH 9731 Manual de usuario

Grundig

Grundig VCC 7070 Manual de usuario

Grundig

Grundig VCH 9732 Manual de usuario

Grundig

Grundig VCC 3870 A Manual de usuario

Grundig

Grundig VCP 4130 Manual de usuario

Grundig

Grundig 01M-GMS2770-2320-02 Manual de usuario

Grundig

Grundig Bodyguard VCC 9450 A Manual de usuario

Grundig

Grundig VCC 4350 A Manual de usuario

Grundig

Grundig VCH 7830 Manual de usuario

Grundig

Grundig VCR 3130 Manual de usuario

Grundig

Grundig VCC 7750 A Manual de usuario

Grundig

Grundig BODYGUARD VCC 4950 C Manual de usuario

Grundig

Grundig VCC 7570 C Manual de usuario

Grundig

Grundig VCC 3650 Manual de usuario

Grundig

Grundig VCH 9930 Manual de usuario

Grundig

Grundig VCR 4230 Manual de usuario

Grundig

Grundig VCH 9632 Manual de usuario

Grundig

Grundig VCP 8931 Manual de usuario

Grundig

Grundig VCH 9829 Manual de usuario

Grundig

Grundig VCH 9130 Manual de usuario

Grundig

Grundig VCP 8931 Manual de usuario

Grundig

Grundig VCC 6670 A Manual de usuario

Grundig

Grundig VCC 5650 Manual de usuario

Grundig

Grundig Bodyguard VCC 9450 A Manual de usuario

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

LG A9 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario
