Grundig MT 6830 Manual de usuario

4 IN 1 BEARD

AND CONTOUR

HAIR TRIMMER

MT 6830

_________________________________________________________

DEUTSCH 4- 16

ENGLISH 17 - 27

FRANÇAIS 28 - 38

ITALIANO 39 - 49

PORTUGUÊS 50 - 60

ESPAÑOL 61 - 71

POLSKI 72 - 82

ČESKY 83 - 93

TÜRKÇE 94 - 104

ΕΛΛΗΝΙΚA 105 - 115

ENGLISH 17

SAFETY_______________________________________________

Please note the following instructions

when using the appliance:

7The appliance is designed for

domestic use only.

7Observe these instructions in

order to prevent damage to the

appliance or danger arising

from improper use. Keep them

in a safe place.

7Never use the appliance in the

bath, shower or over a wash

basin filled with water; nor

should it be operated with wet

hands.

7Do not immerse the appliance in

water or let it come into contact

with water, even during

cleaning.

7Do not drop the appliance.

7Pull out the power supply unit

after use.

7If not already present, for addi-

tional protection it is recommend

to install a residual-current-oper-

ated protective device (RCD)

with a rated residual operating

current not exceeding 30 mA in

the electrical circuit of your bath-

room. Ask your plumber for

advice.

7Never use the appliance if it is

visibly damaged.

7Keep the appliance away from

children.

7Do not open the appliance

under any circumstances. No

warranty claims are accepted

for damage caused by incorrect

handling.

18 ENGLISH

OVERVIEW__________________________________________

See the illustrations on page 2.

Controls

Professional cutting head

made from industrial ceramic

(width 25 mm).

On/off switch.

Charging display (LED). Lights

up red when charging and

green when it is fully charged.

Socket for plugging into the

charging unit or connecting the

power supply unit.

Charging unit.

Turbo speed switch on the

back of the appliance.

Accessories

Trimming attachment for fine

lines (width 14 mm).

Extendable plug-in comb

system suitable for both cutting

widths, with precise trimming

grade display for beard lengths

of 2, 4, 6, 8 and 10 mm.

Shaving attachment with single

blade foil for a smooth shave.

Power supply unit.

Other accessories

1 x moustache comb.

1 x thinning comb.

1 x cleaning brush.

1 x oil for cutting head.

ENGLISH 19

POWER SUPPLY ___________________________________

Operation with

rechargeable batteries

When operating the appliance with

the built-in nickel metal hydride

battery, only use the power unit

supplied for charging.

1Plug the power cord into the

appliance socket and the

power supply unit into the wall

socket.

Notes

7Charge up the batteries completely

before you use them for the first

time or if you have not used them

for a long time.

– The charging display lights

up red when charging and

changes to green when it is

fully charged.

7When switched off, the charging

time is about 8-10 hours. If you

switch on the appliance while it is

charging, charging will stop.

– The charging display

disappears.

7The ambient temperature should

be between 5 °C and 40 °C.

7When fully charged, the appliance

works for around 40 minutes.

It is not advisable to charge the

batteries after every use, especially

if you do not use the appliance for

the full 40 minutes. Only charge

the batteries when they are

completely discharged. This

increases their service life. Do not

charge it every day.

Using the charging unit

1Put socket of the appliance

into the charging unit.

2Plug the power cord into the

socket on the charging unit.

3Plug the power supply unit into

the wall socket.

20 ENGLISH

POWER SUPPLY ___________________________________

Mains operation

(with the power supply

unit)

Check if the mains voltage on the

type plate of the power supply unit

supplied corresponds to your local

mains supply.

The only way to disconnect the

device from the mains is to unplug

the power supply unit.

1Plug the power supply unit into

the socket on the appliance.

2Plug the power supply unit into

the wall socket.

Caution

7When in the bathroom or beside

a water connection, only use the

appliance in battery mode; never

run it from the mains.

ENGLISH 21

OPERATION ________________________________________

Special features

This appliance has four separate

functions:

– Function 1: for precise and

smooth beard trimming at a width

of 25 mm.

– Function 2: for cutting fine lines at

a width of 14 mm.

– Function 3: for beard trimming

with various cutting lengths (2, 4,

6, 8, 10 mm) at widths of 25 mm

or 14 mm.

– Function 4: for close shaving.

Switching on/off

1Press the button to switch on

the appliance.

2If you want to switch to turbo

speed, press and hold down .

3Press the button to switch off

the appliance.

Function 1

Beard trimming

Using the ceramic cutting head

(width 25 mm).

1If required, remove the attach-

ment by pressing down both

thumbs on the front of the

attachment and pushing back.

2Insert the ceramic cutting head

at the back with the guide tab

and press it down with your

thumbs until it clicks into place.

3Place a towel around your neck

and shoulders.

22 ENGLISH

OPERATION ________________________________________

4Loosen the beard hair by

combing the beard in the

direction the hair grows.

Note

7Press and hold down switch to

use the turbo speed for removing

any unwanted hair before you

begin styling.

Function 2

Cutting fine lines

Using the trimming attachment

(width 14 mm).

1If required, remove the attach-

ment by pressing down both

thumbs on the front of the

attachment and pushing back.

2Insert the trimming attachment

at the back with the guide tab

and press it down with your

thumbs until it clicks into place.

ENGLISH 23

3Pull the extendable attachment

from behind, with the combs

over the cutting head and let it

click into the locking tab.

4Adjust the cutting length (2, 4,

6, 8 or 10 mm) by pressing on

the lock under the cutting length

display and then move the

comb to the setting you want.

OPERATION ________________________________________

Function 3

Trimming beards at

certain cutting lengths

Using the extendable attachment .

1If required, remove the attach-

ment by pressing down both

thumbs on the front of the

attachment and pushing back.

2Insert the (width 25 mm) or

(width 14 mm) attachment at

the back with the guide tab and

press it down with your thumbs

until it clicks into place.
